FEATURES AND SPECIFICATIONS
Features and Benefits
n
n
n
n
n
Sizes 2 to 16 circuits
High voltage
Rising cage pressure clamp
130
o
C operating rating
High flammability rating
Electrical
Voltage: 600V
Maximum Current: 20 Amp
Insulation Resistance:
>5000
Gigaohms
8.0 mm (.315”) Pitch
Beau Eurostyle®
Fixed Blocks
39950
High Voltage
Mechanical
Max. Tightening Torque: 8 in. lbs, .90 Nm
Operating Temperature: 130
o
C
Wire Strip Length: 1/4” or 6mm
Physical
Reference Information
UL :
CSA:
File No. E48521
Guide No. XCFR2
File No. 025562
Insulator: Polymide UL94V-0, Black
Screws: Steel
Screw Plating: Zinc chromate
Pressure Clamp: Brass
Pressure Clamp Plating: Nickel
Contacts: Copper Alloy
Contact Plating: Bright Tin Dip
Wire Range: 12 to 22 AWG, 2.5 to 0.5mm
2
CATALOG DRAWING (FOR REFERENCE ONLY)
RECOMMENDED PTH PATTERN
4.39
.173”
Diameter
3.56
.140”
8.00
.315”
6.68
.263”
2.41
.095”
4.39
.173”
2.72
.107”
16.00
.630”
Diameter
1.47
.058”
FRONT
5.69
.224”
5.99
.236”
2.72
.107”
4.06
.160”
21.84
.86”
A
C
1.78
.070”
3.56
.140”
15.49
.610”
7.49
.295”
ORDERING INFORMATION AND DIMENSIONS
Part Number *
Order #
Engineering #
39950-0103
950503
39950-0104
950504
39950-0105
950505
39950-0106
950506
39950-0107
950507
39950-0108
950508
39950-0109
950509
39950-0110
950510
39950-0111
950511
39950-0112
950512
39950-0113
950513
39950-0114
950514
39950-0115
950515
39950-0116
950516
# of
Circuits
3
4
5
6
7
8
9
10
11
12
13
14
15
16
A
in
.63
.94
1.26
1.58
1.89
2.20
2.52
2.84
3.15
3.46
3.78
4.10
4.41
4.72
mm
16.0
24.0
32.0
40.0
48.0
56.0
64.0
72.0
80.0
88.0
96.0
104.0
112.0
120.0
in
.98
1.29
1.61
1.92
2.24
2.55
2.87
3.18
3.50
3.81
4.13
4.44
4.76
5.07
B
mm
24.9
32.8
40.9
48.8
56.9
64.8
72.9
80.8
88.9
96.8
104.9
112.8
120.9
128.8
* Consult factory for sequential numbering and special marking
