SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
SC
Chip type, Standard
Series
Solvent Proof
WV≦100V
・Chip
type higher capacitance in larger case size
・Designed
for surface mounting on high density PC board
・Applicable
to automatic insertion machine using carrier tape
・Complied
to the RoHS directive
Item
Operating temperature range
Leakage current max.
Capacitance tolerance
Dissipation factor max.
(at 120Hz, 20°
C)
Characteristics
-40 ~ +85°
C
WV≦100 I = 0.01CV or 3μ whichever is greater (after 2 minutes)
A
WV≧160 I = 0.04CV + 100μ
A(after 1 minutes)
±20%
at 120Hz, 20°
C
4
6.3
10
16
25
35
50
63 100 160 200 250 400 450
tanδ 0.35 0.28 0.20 0.16 0.13 0.12 0.09 0.12 0.12 0.20 0.20 0.20 0.25 0.25
(0.40) (0.35) (0.24) (0.20) (0.16) (0.15) (0.12)
( ) : Small size between two size in dimension table and over the 6.3×5.8(ØD×L)
WV
Low temperature characteristics
(Impedance ratio at 120Hz)
Load life
(after application of the rated
voltage for 2000 hours at 85°
C)
Shelf life (at 85°
C)
WV
Z-25°
C/Z+20°
C
Z-40°
C/Z+20°
C
Leakage current
Capacitance change
tanδ
4
6
12
6.3
5
10
10
4
8
16
3
6
25
2
4
35 ~ 100 160 ~ 250 400 ~ 450
2
3
6
6
10
3
Less than specified value
Within
±20%
of initial value (Small size :
±25%)
Less than 200% of the specified value
After 1000 hours no load test, leakage current, capacitance and tanδ
are same as load life value.
The following specifications shall be satisfied when the capacitors are restored to 20°
C
after exposing them at 250° for 30 seconds.
C
CHIP TYPES
Resistance to soldering heat
Leakage current
Capacitance change
tanδ
Less than specified value
Within
±10%
of initial value
Less than specified value
Unit : mm
＋
Positive
●
DRAWING
(Ø4, Ø5, Ø6.3×5.3mmL)
0.4 max.
Capacitance
Series Code
Plastic plateform
0.3 max.
＋
C±0.2
※Voltage
－
－
Negative
※Voltage
mark for
6.3V is 6
(Ø6.3,Ø8×6.2)
5.3±0.2
B±0.2
R
E±0.2
27
6V
Lot No.
ØD×L
4×5.3
5×5.3
6.3×5.8
6.3×7.7
8×6.2
8×10
10×10
12.5×13.5
16×16.5
16×21.5
18×16.5
18×21.5
(Ø12.5~18)
W
4.8
5.8
7.1
A
2.4
3.3
2.9
3.2
4.6
5.6
5.6
6.6
6.6
B
4.3
5.3
6.6
6.6
8.3
8.3
10.3
12.8
16.8
16.8
18.8
18.8
C
4.3
5.3
6.6
6.6
8.3
8.3
10.3
12.8
16.8
16.8
18.8
18.8
E
1.0
1.4
2.2
2.2
2.3
3.1
4.5
4.5
6.5
6.5
6.5
6.5
R
0.5~0.8
0.5~0.8
0.5~0.8
0.5~0.8
0.5~0.8
0.8~1.1
0.8~1.1
1.1~1.4
1.1~1.4
1.1~1.4
1.1~1.4
1.1~1.4
ØD±0.5
(Ø8×10, Ø10×10)
V
V
W±0.2
49
SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
SC
series
●
DIMENSIONS & MAXIMUM PERMISSIBLE RIPPLE CURRENT
μ
F
2.2
3.3
4.7
10
22
33
47
68
100
220
330
470
6.3×5.8
6.3×5.8
8×6.2
8×10
10×10
10×10
31
46
96
117
140
6.5×5.8
6.3×5.8
8×6.2
8×10
8×10
10×10
10×10
29
35
40
77
10×10
10×10
100
10×10
10×10
90
WV
63
100
160
200
250
400
450
10×10
10×10
85
100
100 12.5×13.5 115 12.5×13.5 115
16×16.5
140
16×16.5
140
100 12.5×13.5 150 12.5×13.5 150
16×16.5
300
100 12.5×13.5 240 12.5×13.5 260
130 12.5×13.5 260
155
16×16.5 400
16×16.5 500
16×21.5
590
18×16.5
16×16.5 350
16×16.5 415
16×21.5
18×16.5
505
16×21.5
280
18×16.5
18×21.5 350
16×21.5
275
18×16.5
18×21.5 345
16×16.5 340
16×21.5
18×16.5
415
160 12.5×13.5 350
18×21.5 490
12.5×13.5 370 12.5×13.5 420
12.5×13.5 550
16×16.5 680
18×21.5 850
16×21.5
18×16.5
18×21.5
665
825
18×21.5 590
Ripple current (mA r ms) at 85° 120Hz
C,
Case size
Ø
D
X
L (mm)
CHIP TYPES
