DIMENSIONS
in inches [millimeters]
L
TW
H
TH Min.
W
P
CASE CODE
A
B
C
D
E
P
EIA SIZE
3216-18
3528-21
6032-28
7343-31
7343-43
2012-12
L
0.126 ± 0.008
[3.2 ± 0.20]
0.138 ± 0.008
[3.5 ± 0.20]
0.236 ± 0.012
[6.0 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
0.079 ± 0.20
[2.0 ± 0.008]
W
0.063 ± 0.008
[1.6 ± 0.20]
0.110 ± 0.008
[2.8 ± 0.20]
0.126 ± 0.012
[3.2 ± 0.30]
0.170 ± 0.012
[4.3 ± 0.30]
0.170 ± 0.012
[4.3 ± 0.30
0.049 ± 0.008
[1.25 ± 0.2]
H
0.063 ± 0.008
[1.6 ± 0.20]
0.075 ± 0.008
[1.9 ± 0.20]
0.098 ± 0.012
[2.5 ± 0.30]
0.110 ± 0.012
[2.8 ± 0.30]
0.158 ± 0.012
[4.0 ± 0.30]
0.047 Max.
[1.2 Max.]
P
0.031 ± 0.012
[0.80 ± 0.30]
0.031 ± 0.012
[0.80 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.020 ± 0.008
[0.52 ± 0.20]
TW
0.047 ± 0.004
[1.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.095 ± 0.004
[2.4 ± 0.10]
0.095 ± 0.004
[2.4 ± 0.10]
0.047 ± 0.004
[1.2 ± 0.10]
T
H
(Min.)
0.028
[0.70]
0.028
[0.70]
0.039
[1.0]
0.039
[1.0]
0.039
[1.0]
0.012
[0.3]
* Pb containing terminations are not RoHS compliant, exemptions may apply
www.vishay.com
1
For technical questions, contact: tantalum@vishay.com
Document Number: 40002
Revision: 16-May-06
293D
Solid Tantalum Chip Capacitors
TANTAMOUNT
®
, Commercial, Surface Mount
RATINGS AND CASE CODES
µF
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
P
A/P
A/P
A/P
A/B/P
A/B
A/BC
A/B/C
A/B/C
B/C/D
B/C/D
B/C/D
C/D/E
D/E
D/E
E
P
P
A/P
A/P
A/B/P
A/B/P
A/B/C/P
A/B/C
A/B/C
A/B/C
B/C/D
B/C/D
B/C/D
C/D/E
C/D/E
D/E
E
P
A
A/P
A/P
A/B/P
A/B/P
A/B/C
A/B/C
A/B/C
B/C/D
B/C/D
B*/C/D
C/D
D/E
D/E
E
A
A
A/B
A/B
A/B
A/B/C
A/B/C
B/C
B/C/D
B/C/D
C/D
D
D/E
D*/E
A
A
A
A/B
A/B
A/B/C
A/B/C
B/C
B/C/D
B/C/D
C/D
D/E
D/E
E
A
A
A/B
A/B
A/B
A*/B/C
A/B/C
B/C
B/C/D
C/D
D
D/E
E
4V
Std.
6.3 V
Std.
10 V
Std.
16 V
Std.
20 V
Std.
25 V
Std.
35 V
Std.
A
A
A
A
A/B
A/B
A/B
B/C
B/C
B/C
C/D
C/D
C/D
D/E
D/E
50 V
Std.
A
A/B
A/B
A/B
A/B/C
B/C
B/C
B/C
C/D
C/D
D
D/E
D/E
Vishay Sprague
* Preliminary values, contact factory for availability.
MARKING
MARKING
Indicates
Lead (Pb)-free
Voltage
Capacitance
µF
Polarity
Band
Capacitance Code,
pF
Indicates
Lead (Pb)-free
X
X
Vishay
Sprague
Logo
V 104L
22
XX
10L
2
Vishay
Sprague
Logo
Polarity Band
Voltage
Code
Capacitance
Code
Polarity Band
Voltage
Code
Date Code
"P" Case Size
"A" Case Size
"B, C, D, E" Case
Sizes
Document Number: 40002
Revision: 16-May-06
For technical questions, contact: tantalum@vishay.com
www.vishay.com
2
293D
Vishay Sprague
Solid Tantalum Chip Capacitors
TANTAMOUNT
®
, Commercial, Surface Mount
STANDARD/EXTENDED RATINGS
CAPACITANCE
(µF)
2.2
3.3
3.3
4.7
4.7
6.8
6.8
10
10
10
15
15
15
22
22
22
33
33
33
47
47
47
68
68
68
100
100
100
150
150
150
220
220
220
330
330
470
470
680
1.0
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
6.8
10
10
10
15
15
15
22
22
22
33
33
33
47
47
Max. ESR
Max. DF
MAX. DC
AT + 25 °C
AT + 25 °C
LEAKAGE
CASE CODE
PART NUMBER
100 kHz
120 Hz
AT + 25 °C
(Ohms)
(%)
(µA)
4 WVDC AT + 85 °C, SURGE = 5.2 V . . . 2.7 WVDC AT + 125 °C, SURGE = 3.4 V
P
293D225X_004P2T_E3
0.5
8
12
A
293D335X_004A2_E3
0.5
6
7.6
P
293D335X_004P2_E3
0.5
8
12
A
293D475X_004A2_E3
0.5
6
6.3
P
293D475X_004P2_E3
0.5
8
6.0
A
293D685X_004A2_E3
0.5
6
5.5
P
293D685X_004P2_E3
0.5
10
6.0
A
293D106X_004A2_E3
0.5
6
5.1
B
293D106X_004B2_E3
0.5
6
3.5
P
293D106X_004P2_E3
0.5
10
6.0
A
293D156X_004A2_E3
0.6
6
3.4
B
293D156X_004B2_E3
0.6
6
2.9
P
293D156X_004P2_E3
0.6
6
N/A
A
293D226X_004A2_E3
0.9
6
2.9
B
293D226X_004B2_E3
0.9
6
2.5
C
293D226X_004C2_E3
0.9
6
1.8
A
293D336X_004A2_E3
1.3
6
2.9
B
293D336X_004B2_E3
1.3
6
2.0
C
293D336X_004C2_E3
1.3
6
1.8
A
293D476X_004A2_E3
1.9
14
2.5
B
293D476X_004B2_E3
1.9
6
1.9
C
293D476X_004C2_E3
1.9
6
1.8
B
293D686X_004B2_E3
2.7
6
1.9
C
293D686X_004C2_E3
2.7
6
1.4
D
293D686X_004D2_E3
2.7
6
0.8
B
293D107X_004B2_E3
4.0
8
1.8
C
293D107X_004C2_E3
4.0
6
0.8
D
293D107X_004D2_E3
4.0
6
0.7
B
293D157X_004B2_E3
6.0
14
1.6
C
293D157X_004C2_E3
6.0
12
0.7
D
293D157X_004D2_E3
6.0
8
0.6
C
293D227X_004C2_E3
8.8
8
0.7
D
293D227X_004D2_E3
8.8
8
0.6
E
293D227X_004E2_E3
8.8
8
0.5
D
293D337X_004D2_E3
13.2
8
0.6
E
293D337X_004E2_E3
13.2
8
0.5
D
293D477X_004D2_E3
18.8
10
0.6
E
293D477X_004E2_E3
18.8
10
0.5
E
293D687X_004E2_E3
27.2
12
0.5
6.3 WVDC AT + 85 °C, SURGE = 8 V . . . 4 WVDC AT + 125 °C, SURGE = 5 V
P
293D225X_6R3P2_E3
0.5
8
12
P
293D225X_6R3P2_E3
0.5
8
12
A
293D225X_6R3A2_E3
0.5
6
7.6
P
293D225X_6R3P2_E3
0.5
8
12
A
293D335X_6R3A2_E3
0.5
6
6.3
P
293D335X_6R3P2_E3
0.5
8
12
A
293D475X_6R3A2_E3
0.5
6
5.5
P
293D475X_6R3P2_E3
0.5
8
6.0
A
293D685X_6R3A2_E3
0.5
6
5.0
B
293D685X_6R3B2_E3
0.5
6
3.4
P
293D685X_6R3P2_E3
0.5
10
6.0
A
293D106X_6R3A2_E3
0.6
6
3.4
B
293D106X_6R3B2_E3
0.6
6
2.9
P
293D106X_6R3P2_E3
0.6
10
6.0
A
293D156X_6R3A2_E3
0.9
6
2.9
B
293D156X_6R3B2_E3
0.9
6
2.5
C
293D156X_6R3C2_E3
0.9
6
1.8
A
293D226X_6R3A2_E3
1.3
6
2.9
B
293D226X_6R3B2_E3
1.3
6
2.0
C
293D226X_6R3C2_E3
1.3
6
1.8
A
293D336X_6R3A2_E3
2.0
14
2.5
B
293D336X_6R3B2_E3
2.0
6
1.9
C
293D336X_6R3C2_E3
2.0
6
1.5
B
293D476X_6R3B2_E3
2.8
6
1.9
C
293D476X_6R3C2_E3
2.8
6
1.4
Max. RIPPLE
100 kHz
Irms
(Amps)
0.02
0.10
0.02
0.11
0.06
0.12
0.06
0.12
0.16
0.06
0.15
0.17
N/A
0.16
0.18
0.25
0.16
0.21
0.25
0.17
0.21
0.25
0.21
0.28
0.43
0.22
0.37
0.46
0.23
0.40
0.50
0.40
0.50
0.57
0.50
0.57
0.50
0.57
0.57
0.02
0.02
0.10
0.02
0.11
0.02
0.12
0.06
0.12
0.16
0.06
0.15
0.17
0.06
0.16
0.18
0.25
0.16
0.21
0.25
0.17
0.21
0.27
0.21
0.28
* For 10 % tolerance, specify “9”; for 20 % tolerance, change to “0”.
www.vishay.com
3
For technical questions, contact: tantalum@vishay.com
Document Number: 40002
Revision: 16-May-06
