M35
Vishay
Wet Tantalum Capacitors
Surface Mount, Molded Case
FEATURES
•
Molded surface mountable design
•
Terminations: standard tin/lead (SnPb),
100 % tin (RoHS compliant) available
•
Industry standard ratings
Pb-free
Available
RoHS*
COMPLIANT
•
Model M35 wet tantalum electrolytic chip capacitors
incorporate the advantages of all the varieties of
electrolytic capacitors and eliminate most of the
disadvantages. These units have a 3 V reverse voltage
capability at + 85 °C and a higher ripple current capability
than any other electrolytic type with similar combinations of
capacitance and case size.
PERFORMANCE CHARACTERISTICS
Operating Temperature:
- 55 °C to + 85 °C
(To + 125 °C with voltage derating)
Capacitance Tolerance:
At 120 Hz, + 25 °C. ± 20 %
standard. ± 10 %, ± 5 % available as special.
DC Leakage Current (DCL Max.):
At + 25 °C and above:
Leakage current shall not exceed the values listed in the
Standard Ratings Tables.
Life Test:
Capacitors are capable of withstanding a 2000 h
life test at a temperature of + 85 °C or + 125 °C at the
applicable rated DC working voltage.
Following life test:
1. DCL, measured at + 85 °C rated voltage, shall not be in
excess of the original requirement.
2. The equivalent series resistance shall not exceed 150 %
of the initial requirement.
3. Change in capacitance shall not exceed 10 % from the
initial measurement.
ORDERING INFORMATION
M35
MODEL
C
CASE
CODE
See
Ratings
and
Case
Codes
Table
826
CAPACITANCE
This is
expressed in
picofarads.The
first two digits
are the
significant
figures. The
third is the
number of
zeros to follow.
M
CAPACITANCE
TOLERANCE
K = ± 10 %
M = ± 20 %
125
DC VOLTAGE RATING
AT + 85
°C
This is expressed in V.
To complete the
three-digit block, zeros
precede the voltage
rating. A decimal point
is indicated by an “R”
(6R3 = 6.3 V).
B
TERMNATION AND
PACKAGING
A = 100 % Tin (RoHS
compliant), bulk
B = Std, tin/lead, bulk
C = 100 % Tin,
full 7" reel
D = Tin/lead, 7" reel
E = 100 % Tin,
1/2 reel qty.
F = Tin/lead,1/2 qty.
Z
RELIABILITY
LEVEL
Z = Non-ER
S
TEMP
S = Std.
L
ESR
S = Std.
L = Low
Packaging:
The use of formed plastic trays for packing bulk components is standard. Tape and reel is is available.
DIMENSIONS
in millimeters
T
h
L
W
P
CASE CODE
C
L (MAX.)
19.3
W
6.3 ± 0.3
H
6.8 ± 0.3
P
2.2 ± 0.3
T
W
1.7 ± 0.2
T
H
(MIN.)
3.8
* Pb containing terminations are not RoHS compliant, exemptions may apply.
www.vishay.com
2
For technical questions, contact: wettants@vishay.com
Document Number: 40095
Revision: 22-Jan-08
T
w
H
Wet
Tantalum Capacitors
Surface Mount, Molded Case
RECOMMENDED REFLOW PROFILES
T
p
°C
t
p
T
L
°C
M35
Vishay
TEMPERATURE ( °C)
T
s
MAX. °C
(t
L
)
T
s
MIN. °C
PREHEAT (t
s
)
25 °C
TIME (s)
ALL CASE CODES
TYPE
M 35
T
p
PB free
260 °C
T
P
Sn/Pb
240 °C
t
p
10
T
L
PB free
217 °C
T
L
Sn/Pb
183 °C
T
s
MIN.
PB free
150 °C
T
s
MIN.
Sn/Pb
100 °C
T
s
MAX.
PB free
200 °C
T
s
MAX.
Sn/Pb
150 °C
t
s
PB free
60 to 150
t
s
Sn/Pb
60 to 90
t
L
60
MOUNTING:
Due to size and weight of these capacitors, we recommended that a supplemental mounting restraint we used in printed circuit
board attachment in addition to the reflowed solder.
One on recommendation is t use an adhesive such as defined in the J-STD-001DS.
This is the Space Application Electronic Hardware Addendum to J-STD-001(Requirements for Solder Electrical and Electronic
Assemblies).
STANDARD RATINGS
CAP
(µF)
CASE
CODE
PART NUMBER*
MAX. ESR MAX. IMP.
AT
AT
+ 25 °C
- 55 °C
MAX. DCL (µA)
AT
+ 25 °C
+ 85 °C
MAX. CAPACITANCE CHANGE
(%) AT
- 55 °C
- 40
- 40
- 64
- 40
- 40
- 60
- 32
- 36
- 40
- 55
- 24
- 28
- 35
- 44
- 16
- 20
- 25
- 40
+ 85 °C
+ 10.5
+ 14
+ 13
+ 10.5
+ 14
+ 13
+ 10.5
+ 14
+ 14
+ 13
+ 10.5
+ 14
+ 12
+ 13
+8
+ 10.5
+ 12
+ 12
+ 125 °C
+ 12
+ 16
+ 16
+ 12
+ 16
+ 16
+ 12
+ 16
+ 16
+ 16
+ 12
+ 16
+ 16
+ 16
+9
+ 12
+ 15
+ 15
MAX.
RIPPLE
40 kHz
rms
820
960
1000
820
900
1000
820
855
900
900
780
820
900
900
715
800
850
850
30
68
220
25
56
180
20
47
120
150
15
33
82
100
10
22
56
68
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
6 WVDC AT + 85 °C . . . 4 WVDC AT + 125 °C
M35C306(1)006(2)ZS(5)
4.0
100
1.0
2.0
M35C686(1)006(2)ZS(5)
3.2
60
1.0
2.0
M35C227(1)006(2)ZS(5)
3.0
36
2.0
9.0
8 WVDC AT + 85 °C . . . 5 WVDC AT + 125 °C
M35C256(1)008(2)ZS(5)
4.0
100
1.0
2.0
M35C566(1)008(2)ZS(5)
3.3
59
1.0
2.0
M35C187(1)008(2)ZS(5)
3.0
45
2.0
9.0
10 WVDC AT + 85 °C . . . 7 WVDC AT + 125 °C
M35C206(1)010(2)ZS(5)
4.0
120
1.0
2.0
M35C476(1)010(2)ZS(5)
3.7
90
1.0
2.0
M35C127(1)010(2)ZS(5)
3.2
54
2.0
6.0
M35C157(1)010(2)ZS(5)
3.0
54
2.0
9.0
15 WVDC AT + 85 °C . . . 10 WVDC AT + 125 °C
M35C156(1)015(2)ZS(5)
4.4
155
1.0
2.0
M35C336(1)015(2)ZS(5)
4.0
90
1.0
2.0
M35C826(1)015(2)ZS(5)
3.9
72
2.0
6.0
M35C107(1)015(2)ZS(5)
3.9
72
2.0
9.0
25 WVDC AT + 85 °C . . . 15 WVDC AT + 125 °C
M35C106(1)025(2)ZS(5)
5.3
220
1.0
2.0
M35C226(1)025(2)ZS(5)
4.2
140
1.0
2.0
M35C566(1)025(2)ZS(5)
4.3
90
2.0
6.0
M35C686(1)025(2)ZS(5)
4.3
90
2.0
9.0
For technical questions, contact: wettants@vishay.com
Document Number: 40095
Revision: 22-Jan-08
www.vishay.com
3
M35
Vishay
STANDARD RATINGS
CAP
(µF)
CASE
CODE
PART NUMBER*
Wet
Tantalum Capacitors
Surface Mount, Molded Case
MAX. ESR MAX. IMP.
AT
AT
+ 25 °C
- 55 °C
MAX. DCL (µA)
AT
+ 25 °C
+ 85 °C
MAX. CAPACITANCE CHANGE
(%) AT
- 55 °C
- 16
- 20
- 23
- 38
- 20
- 22
- 16
- 24
- 29
- 16
- 24
- 24
- 16
- 20
- 19
- 16
- 16
- 17
- 16
-16
-14
+ 85 °C
+8
+ 10.5
+ 12
+ 12
+ 10.5
+ 12
+5
+8
+ 10
+5
+8
+ 10
+5
+8
+ 10
+7
+7
+ 10
+7
+7
+ 10
+ 125 °C
+ 12
+ 12
+ 15
+ 15
+ 12
+ 14
+6
+9
+ 12
+6
+9
+ 12
+6
+9
+ 12
+8
+8
+ 12
+8
+8
+ 12
MAX.
RIPPLE
40 kHz
rms
640
780
800
800
660
820
580
715
700
525
625
700
525
610
600
505
565
800
415
520
700
8
15
47
56
15
39
5
10
33
4
8.2
27
3.5
6.8
22
2.5
4.7
10
1.7
3.6
6.8
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
30 WVDC AT + 85 °C . . . 20 WVDC AT + 125 °C
M35C805(1)030(2)ZS(5)
6.6
275
1.0
2.0
M35C156(1)030(2)ZS(5)
6.2
175
1.0
2.0
M35C476(1)030(2)ZS(5)
5.2
100
2.0
6.0
M35C566(1)030(2)ZS(5)
5.2
100
2.0
9.0
35 WVDC AT + 85 °C . . . 22 WVDC AT + 125 °C
M35C156(1)035(2)ZS(5)
6.2
175
0.75
1.5
M35C396(1)035(2)ZS(5)
4.1
61
2.0
6.0
50 WVDC AT + 85 °C . . . 30 WVDC AT + 125 °C
M35C505(1)050(2)ZS(5)
8.0
400
1.0
2.0
M35C106(1)050(2)ZS(5)
6.4
250
1.0
2.0
M35C336(1)050(2)ZS(5)
5.0
135
2.0
9.0
60 WVDC AT + 85 °C . . . 40 WVDC AT + 125 °C
M35C405(1)060(2)ZS(5)
9.3
550
1.0
2.0
M35C825(1)060(2)ZS(5
6.6
275
1.0
2.0
M35C276(1)060(2)ZS(5
5.0
144
3.0
12
75 WVDC AT + 85 °C . . .50 WVDC AT + 125 °C
M35C355(1)075(2)ZS(5)
9.5
650
1.0
2.0
M35C685(1)075(2)ZS(5)
6.8
300
1.0
2.0
M35C226(1)075(2)ZS(5)
5.1
157
3.0
12
100 WVDC AT + 85 °C . . . 65 WVDC AT + 125 °C
M35C255(1)100(2)ZS(5)
10.6
950
1.0
2.0
M35C475(1)100(2)ZS(5
8.5
500
1.0
2.0
M35C106(1)100(2)ZS(5
5.9
200
3.0
12
125 WVDC AT + 85 °C . . . 85 WVDC AT + 125 °C
M35C175(1)125(2)ZS(5)
15.6
1250
1.0
2.0
M35C365(1)125(2)ZS(5)
10.0
600
1.0
2.0
M35C685(1)125(2)ZS(5)
11.7
300
3.0
12
Notes:
1. Capacitance tolerance: K, M
2. Termination/packaging: (see Ordering Information)
3. Reliability level: Z = non-ER
4. Temperature: S = STD
5. ESR: S = STD, L = Low (1/2 standard ESR value)
PERFORMANCE CHARACTERISTICS OF M35 CAPACITORS
ELECTRICAL CHARACTERISTICS
ITEM
Operating temperature range
Capacitor tolerance
Capacitance change (maximum)
ESR
AC ripple current
DCL (maximum leakage current)
Impedance (maximum)
Reverse voltage
PERFORMANCE CHARACTERISTICS
- 55 °C to + 125 °C
± 20 %, ± 10 % at 120 Hz
Limits per the Standard Ratings Table. Measured per requirements of MIL-PRF--39006
Surge voltage
Life test
Reverse voltage shall be in accordance with MIL-PRF-39006/22.
Units are capable of withstanding 3 V in reverse at + 85 °C for 125 h
Surge voltage shall be in accordance with MIL-PRF-39006
The DC rated surge voltage is the maximum voltage to which the capacitors should be subjected
under any conditions. This includes transients and peak ripple at the highest line voltage. The
surge voltage is 115 % of rated DC working voltage.
The capacitors shall be capable of withstanding a 2000 h life test at 85 °C at rated voltage.
www.vishay.com
4
For technical questions, contact: wettants@vishay.com
Document Number: 40095
Revision: 22-Jan-08
M35
Vishay
Wet
Tantalum Capacitors
Surface Mount, Molded Case
ENVIRONMENTAL CHARACTERISTICS
ITEM
Hermeticity
Moisture resistance
Altitude/barometric Pressure
(reduced)
CONDITION
MIL-PRF-39006
MIL-PRF-39006
COMMENTS
The internal component has been tested to be compliant to the
hermeticity requirements of MIL-PRF-39006/22.
The internal component has been tested to be compliant to the
moisture resistance requirements of MIL-PRF-39006/22.
The internal component has been tested to be compliant to the
altitude or reduced barometric pressure requirements of
MIL-PRF-39006/22 (150 000 feet)
MIL-PRF-39006
MECHANICAL CHARACTERISTICS
ITEM
Thermal shock
Shock
Vibration (high frequency)
Vibration (random)
Resistance to solder heat
CONDITION
MIL-STD-202, Method 107, A
MIL-STD-202, Method 213
MIL-STD-202, Method 204
MIL-STD-202, Method 214
MIL-STD-202, Method 210
COMMENTS
Per MIL-PRF-39006, 5 cycles
Per MIL-PRF-39006, 500 g
Per MIL-PRF-39006, 80 g
Per MIL-PRF-39006, 53.79 g
The capacitor must withstand solder dipping of the terminals
at 260 °C for 10 s. The capacitor must not be visibly damaged and
the electrical characteristics must not be affected.
The terminations must be solderable per the requirements of
MIL-PRF-55365 para. 4.10
The part marking shall include Vishay name, trademark,
capacitance, voltage, date code and lot symbol.
Solderability
Part markings
Weight
(typical) in g
ANSI J-STD-002
MIL-STD-1285
2.5
PAD DIMENSIONS
in inches [mm]
A
D
C
CASE CODE M35
C
A (MIN.)
[19.3]
B
B (NOM.)
[12.3]
C
C (NOM.)
[3.5]
D (NOM.)
[3.0]
STANDARD PACKAGING QUANTITY
SERIES
M35
CASE CODE
C
QUANTITY (PCS/REEL)
7" REEL
100
1/2 REEL
50
www.vishay.com
5
For technical questions, contact: wettants@vishay.com
Document Number: 40095
Revision: 22-Jan-08
Legal Disclaimer Notice
Vishay
Disclaimer
All product specifications and data are subject to change without notice.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf
(collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein
or in any other disclosure relating to any product.
Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any
information provided herein to the maximum extent permitted by law. The product specifications do not expand or
otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed
therein, which apply to these products.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document or by any conduct of Vishay.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless
otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such
applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting
from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding
products designed for such applications.
Product names and markings noted herein may be trademarks of their respective owners.
Document Number: 91000
Revision: 18-Jul-08
www.vishay.com
1
京公网安备 11010802033920号
EEWORLD
