High Precision / High Voltage Resistors
Type HV Series
Type HV Series
Characteristics -
Electrical
Type
HV-55
HV-60
HV-65
HV-70
HV-80
HV-100
The CGS HV Series has a close
dimension ceramic core with thick film
bonded to the core at temperatures
in excess of 750°C. Oxygen free tin
plated copper wire leads are welded to
a silver plated 90-10 copper cap that is
press fitted to the resistor. A unique
coating formula provides a high
reliability, high precision, high voltage
thick film resistor.
Power Rating
@ 70°C
(W)
0.5W
1.0W
2.0W
3.0W
3.0W
5.0W
Voltage
Rating
(VDC)
750V
1500V
2500V
5000V
7500V
15000V
Resistance
Range
(Ohms)
100K ~ 1G5
250K ~ 4G0
300K ~ 10G
500K ~ 15G
500K ~ 20G
750K ~ 30G
Resistance
Tolerance
(%)
Temperature
Coefficient
(ppm)
All Types
<±25ppm from 0°C to +70°C
<±50ppm from -15°C to +105°C
<±100ppm from -55°C to +125°C
All Types
0.5, 1.0, 2.0,
5.0, 10.0
Characteristics -
Environmental
Load life (1000 hours rated voltage @70°C):
Overload (1.5 times rated voltage for 10 seconds):
Moisture Resistance (no load polar):
Thermal Shock:
Shelf Life (1 year at 25°C):
Dielectric Strength:
±0.1%, maximum ±0.5%
±0.1%, maximum ±0.5%
±0.2%, maximum ±0.5%
±0.1%, maximum ±0.3%
±0.1%, maximum ±0.25%
±0.1%, maximum ±0.25%
Key Features
I
I
I
I
I
I
Derating Curve
100
80
Rated Load (%)
60
40
20
0
-60
-40
-55°C
-20
0
20
40
60
80
100
120
140
Ambient Temperature (°C)
70°C
0.25 Watts to 5 Watts
100K to 30 Gigohm Range
TCR from ±25 PPM
±0.5% to ±10% Tolerance
Flame Proof Coating
Special Coatings for High
Humidity
Dimensions
Style
HV55
HV60
HV65
HV70
HV80
HV100
D Max.
2.54
3.81
4.34
6.48
8.64
8.64
L
7.34
10.29
15.75
21.21
24.51
46.10
d
0.64
0.81
0.81
0.81
0.81
0.81
l
38.0
38.0
38.0
38.0
38.0
38.0
How to Order
HV100
Common Part
HV55
HV60
HV65
HV70
HV80
HV100
10K
Resistance Value
See Above for Value
Range Available
J
Tolerance
D - 0.5%
F - 1.0%
G - 2.0%
J - 5.0%
K - 10.0%
L
Pack Style
L - Loose
B - Bandoliered
Literature No. 1773234
Issued: 04-05
Dimensions are shown for
reference purposes only.
Dimensions are in millimetres
unless otherwise specified.
Specifications subject to
change.
www.tycoelectronics.com
passives.tycoelectronics.com
