MPX / PX Series
•
Ultra High Surge Current
•
Random (R) and Zero Voltage Switching
•
SCR Output
PRODUCT SELECTION
Control Voltage
3-32 VDC
AVAILABLE OPTIONS
AC OUTPUT SPECIFICATIONS (1)
Description
Operating Voltage (47-63Hz) [Vrms]
Maximum Load Current [Arms]
Minimum Load Current [Arms]
Transient Overvoltage [Vpk]
Maximum Surge Current (16.6ms) [Apk]
Maximum On-State Voltage Drop @ Rated Current [Vpk]
Maximum I²t for fusing (8.3 msec) [A² sec]
Maximum Off-State Leakage Current @ Rated Voltage [mArms]
Minimum Off-State dv/dt @ Maximum Rated Voltage [V/µsec] (2)
Minimum Power Factor (with Maximum Load)
ol
12-280
5
0.06
600
250
1.4
260
4.0
500
0.5
12-280
5
0.06
600
250
1.4
260
4.0
500
0.5
bs
Description
MPX240D5
3-32 VDC
3.0 VDC
1.0 VDC
1500 Ohm
1/2 Cycle
1/2 Cycle
Control Voltage Range
Must Turn On Voltage
Must Turn Off Voltage
Nominal Input Impedance
Maximum Turn-On Time [msec]
Maximum Turn-Off Time [msec]
INPUT SPECIFICATIONS (1)
GENERAL SPECIFICATIONS
Description
Dielectric Strength, Input/Output/Base (50/60Hz)
Minimum Insulation Resistance (@ 500 VDC)
Maximum Capacitance, Input/Output
Ambient Operating Temperature Range
Ambient Storage Temperature Range
Weight (typical)
Encapsulation
O
GENERAL NOTES
1) All parameters at 25°C unless otherwise noted.
2) 2) Off-state dv/dt test method per EIA/NARM standard RS-443, paragraph 13.11.1
3) Voltage Applied for 1 minute.
et
MPX240D5
MPX240D5R
PX240D5
PX240D5R
MPX240D5
MPX240D5R
MPX240D5R
3-32 VDC
3.0 VDC
1.0 VDC
1500 Ohm
20 µs
1/2 Cycle
e
PX240D5
12-280
5
0.06
600
250
1.4
260
4.0
500
0.5
PX240D5R
12-280
5
0.06
600
250
1.4
260
4.0
500
0.5
PX240D5
3-32 VDC
1.0 VDC
3.0 VDC
1500 Ohm
1/2 Cycle
1/2 Cycle
PX240D5R
3-32 VDC
1.0 VDC
3.0 VDC
1500 Ohm
20 µs
1/2 Cycle
Parameters
4000 Vrms
10
9
Ohm
16 pF
-30 to 80°C
-40 to 125°C
0.4 oz. (11g)
Thermally Conductive Epoxy
