Embedded Power for
Business-Critical Continuity
AD8024N3L-001
78 Watts
Total Power:
Input Voltage:
# of Outputs:
78 Watts
90 - 264 Vac
Single
Rev. 10.01.10_151
AD8024N3L-001
1 of 2
Special Features
• CE Mark EMC & LVD
• Universal AC input
• Fully regulated output
• Overcurrent, Overvoltage and
Thermal protection
• Constant voltage
• High efficiency
• High MTBF
• IEC320 AC receptacle, 3 pin
(type C14)
• Built in EMI filter
• (CISPR 22 Class B)
• AC Input fuse
• Complies with CeC IV and
Energy Star Requirement
Electrical Specifications
Input
Input ra nge:
Frequency:
Input current:
Efficiency:
EMI/RFI:
Safety ground
leakage current:
90 - 264 Vac (wide range)
47 - 63 Hz
2 A maximum
84% typical
FCC Part 15, Subpart B Class B & EN55022 (CISPR 22) Class B
0.5 mA maximum@ 50/60 Hz, 264 Vac input
Output
Maximum Power (Po):
Hold-up time:
Overcurrent protection:
Thermal protection:
Cable/connector:
78 W
10 ms. minimum at full load @ 115 Vac
Output short circuit protection auto recover
Overload protection @ 110 - 120% above maximum rating
Internally protected; output will latch off
DC cable length 2.5 mm center plug
DC plug center +v
DC plug outer -v
Environmental Specifications
Operating temperature:
Storage temperature:
Electromagnetic susceptibility:
0° to +40 °C ambient
-40 °C to +70 °C
Designed to meet EN61000-4-2, -3, -4, level 2;
EN61000-4-5, Level 4; EN61000-3-3
Operating; non-condensing 5% to 90% RH
> 300,000 hours at full load and 25 °C ambient conditions
Safety
• UL:
UL 60950-1
• CSA:
CSA-C22.2 no.60950-1
• NEMKO: EN/IEC60950-1
• CB:
Certificate and report
Humidity:
MTBF demonstrated:
Embedded Power for
Business-Critical Continuity
Ordering Information
Model
Number
Maximum
Power
Output
Voltage
Maximum
Peak Load
1
Regulation
2
Load
Ripple
P/P (PARD)
3
AD8024N3L-001
80 W
24 Vdc
3.25 A
4.16 A
± 5%
< 400 mV
1. Peak current lasting < 4 seconds with a maximum 10% duty cycle.
2. At 25 ºC including initial tolerance, line voltage, load currents and output voltages adjusted to factory
settings.
3. Peak-to-peak with 20 MHz bandwidth and 10 µF (tantalum capacitor) in parallel with a 0.1 µF capacitor at rated
line voltage and load ranges.
Americas
5810 Van Allen Way
Carlsbad, CA 92008
USA
Telephone: +1 (760) 930 4600
Facsimile: +1 (760) 930 0698
Rev. 10.01.10_151
AD8024N3L-001
2 of 2
Europe (UK)
Mechanical Drawing
REFER TO O/P CABLE DRAWING
Waterfront Business Park
Merry Hill, Dudley
West Midlands, DY5 1LX
United Kingdom
Telephone: +44 (0) 1384 842 211
Facsimile: +44 (0) 1384 843 355
Asia (HK)
62”
(1575)
5.87”
(149.0)
1.76”
44.6
14/F, Lu Plaza
2 Wing Yip Street
Kwun Tong, Kowloon
Hong Kong
Telephone: +852 2176 3333
Facsimile: +852 2176 3888
3.13”
(79.6)
For global contact, visit:
www.Emerson.com/EmbeddedPower
techsupport.embeddedpower@
emerson.com
While every precaution has been taken to ensure
accuracy and completeness in this literature, Emerson
Network Power assumes no responsibility, and disclaims
all liability for damages resulting from use of this
information or for any errors or omissions.
AC POWER ADAPTER
Emerson Network Power.
The global leader in enabling
business-critical continuity.
AC Power
Connectivity
DC Power
Embedded Computing
Embedded Power
Monitoring
Outside Plant
Power Switching & Controls
Precision Cooling
Racks & Integrated Cabinets
Services
Surge Protection
EmersonNetworkPower.com
Emerson Network Power and the Emerson
Network Power logo are trademarks and
service marks of Emerson Electric Co.
©2010 Emerson Electric Co.
MODEL LABEL
1.76” (H) x 3.13” (W) x 5.87” (L)
44.0 mm (H) x 79.6 mm (W) x 149.0 mm (L)
AC Input Connector: IEC320, C14
AC Input power cord sold separately
Notes:
1. Specifications subject to change without notice.
2. All dimensions in inches (mm), tolerance is
±
0.02” (±0.5 mm)
3. Warranty: 2 year
4. Weight: 0.91 lb./ 0.41 kg
5. AC input power cord sold separately.
6. Specifications at factory settings at 115 Vac input,
25 °C unless otherwise stated
