MP5420DM-LF-Z amplifier basic information:
MP5420DM-LF-Z is an OPERATIONAL AMPLIFIER. The commonly used packaging method is TSSOP,
MP5420DM-LF-Z amplifier core information:
The minimum operating temperature of MP5420DM-LF-Z is -40 °C and the maximum operating temperature is 85 °C. Its peak reflow temperature is 260°C and its maximum average bias current is 2 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the MP5420DM-LF-Z has a nominal slew rate of 45 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the MP5420DM-LF-Z gain becomes 0.707 times the low-frequency gain is 14000 kHz.
The nominal supply voltage of MP5420DM-LF-Z is 5 V, and its corresponding nominal negative supply voltage is -5 V. The input offset voltage of MP5420DM-LF-Z is 20000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)
Related dimensions of MP5420DM-LF-Z:
The width of MP5420DM-LF-Z is: 4.4 mm and the length is 5 mm. MP5420DM-LF-Z has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 0.65 mm. Total pins: 14
MP5420DM-LF-Z amplifier additional information:
Its temperature grade is: INDUSTRIAL. And its humidity sensitivity level is: 2. MP5420DM-LF-Z is not Rohs certified. It does not contain lead. The corresponding JESD-30 code is: R-PDSO-G14.
The corresponding JESD-609 code is: e3. The packaging code of MP5420DM-LF-Z is: TSSOP. MP5420DM-LF-Z packaging materials are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. MP5420DM-LF-Z package pin formats are: SMALL OUTLINE.
Its terminal forms are: GULL WING. The maximum seat height is 1.2 mm.
MP5420DM-LF-Z amplifier basic information:
MP5420DM-LF-Z is an OPERATIONAL AMPLIFIER. The commonly used packaging method is TSSOP,
MP5420DM-LF-Z amplifier core information:
The minimum operating temperature of MP5420DM-LF-Z is -40 °C and the maximum operating temperature is 85 °C. Its peak reflow temperature is 260°C and its maximum average bias current is 2 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the MP5420DM-LF-Z has a nominal slew rate of 45 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the MP5420DM-LF-Z gain becomes 0.707 times the low-frequency gain is 14000 kHz.
The nominal supply voltage of MP5420DM-LF-Z is 5 V, and its corresponding nominal negative supply voltage is -5 V. The input offset voltage of MP5420DM-LF-Z is 20000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)
Related dimensions of MP5420DM-LF-Z:
The width of MP5420DM-LF-Z is: 4.4 mm and the length is 5 mm. MP5420DM-LF-Z has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 0.65 mm. Total pins: 14
MP5420DM-LF-Z amplifier additional information:
Its temperature grade is: INDUSTRIAL. And its humidity sensitivity level is: 2. MP5420DM-LF-Z is not Rohs certified. It does not contain lead. The corresponding JESD-30 code is: R-PDSO-G14.
The corresponding JESD-609 code is: e3. The packaging code of MP5420DM-LF-Z is: TSSOP. MP5420DM-LF-Z packaging materials are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. MP5420DM-LF-Z package pin formats are: SMALL OUTLINE.
Its terminal forms are: GULL WING. The maximum seat height is 1.2 mm.
| Parameter Name | Attribute value |
| Is it lead-free? | Lead free |
| Is it Rohs certified? | conform to |
| Maker | Monolithic Power Systems |
| Parts packaging code | TSSOP |
| package instruction | TSSOP, |
| Contacts | 14 |
| Reach Compliance Code | compliant |
| ECCN code | EAR99 |
| Factory Lead Time | 8 weeks |
| Amplifier type | OPERATIONAL AMPLIFIER |
| Maximum average bias current (IIB) | 2 µA |
| Nominal Common Mode Rejection Ratio | 85 dB |
| Maximum input offset voltage | 20000 µV |
| JESD-30 code | R-PDSO-G14 |
| JESD-609 code | e3 |
| length | 5 mm |
| Humidity sensitivity level | 2 |
| Negative supply voltage upper limit | -11 V |
| Nominal Negative Supply Voltage (Vsup) | -5 V |
| Number of functions | 4 |
| Number of terminals | 14 |
| Maximum operating temperature | 85 °C |
| Minimum operating temperature | -40 °C |
| Package body material | PLASTIC/EPOXY |
| encapsulated code | TSSOP |
| Package shape | RECTANGULAR |
| Package form | SMALL OUTLINE |
| Peak Reflow Temperature (Celsius) | 260 |
| Certification status | Not Qualified |
| Maximum seat height | 1.2 mm |
| Nominal slew rate | 45 V/us |
| Supply voltage upper limit | 11 V |
| Nominal supply voltage (Vsup) | 5 V |
| surface mount | YES |
| Temperature level | INDUSTRIAL |
| Terminal surface | Matte Tin (Sn) |
| Terminal form | GULL WING |
| Terminal pitch | 0.65 mm |
| Terminal location | DUAL |
| Maximum time at peak reflow temperature | 40 |
| Nominal Uniform Gain Bandwidth | 14000 kHz |
| width | 4.4 mm |
| Base Number Matches | 1 |
| MP5420DM-LF-Z | MP5420DM-LF | MP5220DK-LF-Z | MP5120DJ-LF-Z | |
|---|---|---|---|---|
| Description | Operational Amplifier, 4 Func, 20000uV Offset-Max, PDSO14, ROHS COMPLIANT, MO153AB-1, TSSOP-14 | IC OPAMP HS RRO 14TSSOP | Operational Amplifier, 2 Func, 20000uV Offset-Max, PDSO8, ROHS COMPLIANT, MO-187AA, MSOP-8 | Operational Amplifier, 1 Func, 20000uV Offset-Max, PDSO5, ROHS COMPLIANT, MO-193AA, TSOT-23, 5 PIN |
| Is it lead-free? | Lead free | Lead free | Lead free | Lead free |
| Is it Rohs certified? | conform to | conform to | conform to | conform to |
| package instruction | TSSOP, | , | TSSOP, | VSSOP, |
| Reach Compliance Code | compliant | compliant | compliant | compliant |
| Factory Lead Time | 8 weeks | 23 weeks 1 day | 8 weeks | 8 weeks |
| Base Number Matches | 1 | 1 | 1 | 1 |
| Maker | Monolithic Power Systems | Monolithic Power Systems | Monolithic Power Systems | - |
| Parts packaging code | TSSOP | - | TSSOP | TSOT |
| Contacts | 14 | - | 8 | 6 |
| ECCN code | EAR99 | - | EAR99 | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER | - | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER |
| Maximum average bias current (IIB) | 2 µA | - | 2 µA | 2 µA |
| Nominal Common Mode Rejection Ratio | 85 dB | - | 85 dB | 85 dB |
| Maximum input offset voltage | 20000 µV | - | 20000 µV | 20000 µV |
| JESD-30 code | R-PDSO-G14 | - | S-PDSO-G8 | R-PDSO-G5 |
| JESD-609 code | e3 | - | e3 | e3 |
| length | 5 mm | - | 3 mm | 2.9 mm |
| Humidity sensitivity level | 2 | - | 1 | 1 |
| Negative supply voltage upper limit | -11 V | - | -11 V | -11 V |
| Nominal Negative Supply Voltage (Vsup) | -5 V | - | -5 V | -5 V |
| Number of functions | 4 | - | 2 | 1 |
| Number of terminals | 14 | - | 8 | 5 |
| Maximum operating temperature | 85 °C | - | 85 °C | 85 °C |
| Minimum operating temperature | -40 °C | - | -40 °C | -40 °C |
| Package body material | PLASTIC/EPOXY | - | PLASTIC/EPOXY | PLASTIC/EPOXY |
| encapsulated code | TSSOP | - | TSSOP | VSSOP |
| Package shape | RECTANGULAR | - | SQUARE | RECTANGULAR |
| Package form | SMALL OUTLINE | - | SMALL OUTLINE | SMALL OUTLINE |
| Peak Reflow Temperature (Celsius) | 260 | - | 260 | 260 |
| Certification status | Not Qualified | - | Not Qualified | Not Qualified |
| Maximum seat height | 1.2 mm | - | 1.1 mm | 1 mm |
| Nominal slew rate | 45 V/us | - | 45 V/us | 45 V/us |
| Supply voltage upper limit | 11 V | - | 11 V | 11 V |
| Nominal supply voltage (Vsup) | 5 V | - | 5 V | 5 V |
| surface mount | YES | - | YES | YES |
| Temperature level | INDUSTRIAL | - | INDUSTRIAL | INDUSTRIAL |
| Terminal surface | Matte Tin (Sn) | - | Matte Tin (Sn) | Matte Tin (Sn) |
| Terminal form | GULL WING | - | GULL WING | GULL WING |
| Terminal pitch | 0.65 mm | - | 0.65 mm | 0.95 mm |
| Terminal location | DUAL | - | DUAL | DUAL |
| Maximum time at peak reflow temperature | 40 | - | 40 | 40 |
| Nominal Uniform Gain Bandwidth | 14000 kHz | - | 14000 kHz | 14000 kHz |
| width | 4.4 mm | - | 3 mm | 1.6 mm |
