CONREVSMA014

Description
RF connector rpsma fml blkhd rmnt crimp, O-ring, rg174
CategoryThe connector
File Size132KB,1 Pages
ManufacturerConnector City
Environmental Compliance
Download Datasheet View All

CONREVSMA014 Online Shopping

Suppliers Part Number Price MOQ In stock
CONREVSMA014 - - View Buy Now

CONREVSMA014 Overview

RF connector rpsma fml blkhd rmnt crimp, O-ring, rg174

1
2
3
4
D
Description
Body
Pin
Insulation
O Ring
Crimp Ring
Washer
Nut
Material
Brass
Brass
Teflon
Si Rubber
Brass
Brass
Brass
Finish
Nickel
Gold
Teflon
Rubber
Nickel
Nickel
Nickel
RECOMMENDED
MOUNTING HOLE
Ø0.256
(6.50)
0.236
(6.00)
PIN
Ø0.020
(0.50)
CRIMP RING
Ø0.154
(3.90)
D
0.441
(11.20)
Ø0.024
(0.60)
Ø0.049
(1.24)
0.374
(9.50)
SIDE VIEW
1/4-36UNS-2A
THREADS
FLAT 0.228
(5.80)
H0.433
(11.00)
Ø0.102
(2.60)
Ø0.236
(6.00)
WASHER
BACK VIEW
Ø0.402
(10.20)
H0.315
(8.00)
1/4-36UNS-2B
THREADS
NUT
C
C
0.197
(5.00)
0.417
(10.60)
0.083
(2.10)
0.748
(19.00)
B
0.248
(6.30)
FLAT 0.228
(5.80)
0.433
(11.00)
0.020
(0.50)
0.065
(1.65)
B
RECOMMENDED CABLE STRIPPING DIMENSIONS
0.098
(2.50)
0.138
(3.50)
0.177
(4.50)
CONREVSMA014 ASSEMBLY INSTRUCTIONS
1.
2.
3.
Solder the pin to the center conductor.
Insert the pin, center conductor, and insulation into the body.
Wrap the braid around the tail of the body and crimp the ring with a
0.137" hex crimp tool (or one labeled for use with RG-174 cable).
A
Title
RP-SMA FEMALE BULKHEAD MOUNT CABLE
CONNECTOR CITY
RG-174 Cable
A
END CRIMP WITH O-RING FOR RG174 CABLE
Part No.
Dimensions:
CONREVSMA014
INCHES (mm)
Revision:
1.0
Date:
6/1/2006
159 ORT LANE
MERLIN, OR 97532
PH (541)-471-6256
FAX (541)-471-6251
Sheet 1 of 1
