ALUMINUM ELECTROLYTIC CAPACITORS
GK
HH
PC Board Mounting Type
series
(Through 100V only)
Higher C/V products.
Plentiful line-up from
φ35 ×
63 to
φ40 ×
100mm.
Auxiliary terminals provided to assure anti-vibration performamance.
GK
HH
Specifications
Item
High C/V
GU
Performance Characteristics
Category
Temperature Range
Rated
Voltage Range
Rated
Capacitance Range
Capacitance Tolerance
Leakage Current
–
40 ~ +105°C (16 ~ 250V) ,
–
25 ~ +105°C (400V)
16 ~ 400V
560 ~ 68000µF
± 20% at 120Hz, 20°C
I
3 CV
(µA) (After 5 minutes' application of rated voltage) [C : Capacitance(µF) , V : Voltage(V)]
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage(V)
tan
δ
(MAX.)
tan
δ
16
0.60
25
0.50
35
0.40
50
0.35
16 ~ 250
4
15
63
0.30
80
0.30
400
8
—
100
0.25
160
0.20
200
0.15
250
0.15
400
0.30
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage(V)
Impedance ratio
ZT/Z20 (MAX.)
Z
–
25°C/ Z+20°C
Z
–
40°C/ Z+20°C
Endurance
After an application of DC voltage(in the range of rated
DC voltage even after over-lapping the specified ripple
current) for 2000 hours at 105°C, capacitors meet
the characteristic requirements
listed
at right.
After leaving capacitors under no load at 105°C for
1000 hours, they meet the requirements listed
at right.
Printed with white color letter on black sleeve.
Capacitance change
tan
δ
Leakage current
Capacitance change
tan
δ
Leakage current
Within ± 20% of initial value
200% or less of initial specified value
Initial specified value or less
Within ±15% of initial value
150% or less of initial specified value
Initial specified value or less
Shelf Life
Marking
Drawing
For all of
φ35mm
products and for 63mmL or shorter with
φ40mm.
Bottom plate
(code HH only)
+1MAX.
Type numbering system (Example : 200V 2700
µ
F)
1
2
3
4
5
6
7
8
9
10 11 12
±
0.1
Sleeve (P.E.T.)
B
C
BLANK
A
BLANK
(PC board hole dimensions)
4-φ 2
L GK 2 D 2 7 2 M EH D
Case dia. code
Configuration
Capacitance tolerance (± 20%)
φ
D
35
40
Rated Capacitance (2700µF)
Rated voltage (200V)
Code
C
D
30
°
30
°
φD
22.5
±
0.1
L± 2
Pressure relief vent
6.3± 1
Series name
Type
Configuration
(PC board hole dimensions)
D
BLANK
D
BLANK
B
BLANK
Bottom plate
For 63mmL or
(code HH only)
Bottom plate
(code HH only)
longer with
φ40mm.
C
Sleeve (P.E.T.)
Sleeve (P.E.T.)
+1MAX.
30
°
B
BLANK
C
(PC board hole dimensions)
5 -φ 2
±
0.1
Pb-free terminal
Pb-free PET sleeve (Black)
Sn-Pb finished terminal
PVC sleeve (containing Pb) (Dark Brown)
EL
HL
5 -φ 2
±
0.1
30
°
30
°
30
°
30
°
Please contact to us if other configurations are required.
+1MAX.
φD
A
BLANK
30
°
φD
25.0
±
0.1
25.0
±
0.1
L± 2
Pressure relief vent
L± 2
Pressure relief vent
6.3± 1
6.3± 1
A
BLANK
Notes:
As blank terminals are not insulated from capacitor element,
they shall be mounted on independent lands.
Frequency coefficient of rated ripple current
Frequency (Hz)
016
~ 100V
Coeff. 160 ~ 250V
400V
50
0.88
0.85
0.88
60
0.90
0.88
0.90
120
1.00
1.00
1.00
1k
1.15
1.15
1.10
10k~
1.15
1.20
1.15
Minimum order quantity : 50pcs.
Dimension table in next page.
CAT.8100T
