KMEBP
Series
Miniature
Bi-Polar
Solvent Proof
105 C
Maximum
Temperature
Actual
Size
MINIATURE -105 C
KMEBP
The KMEBP series capacitors are the bi-polar versions of the KME series and are designed for use in
circuits in which polarity is sometimes reversed or unknown. Please note that these capacitors
cannot withstand an AC application in which the maximum ripple current is exceeded.
The KMEBP series capacitors were developed to withstand HCFC cleaning agents for five minutes
by ultrasonic, vapor or immersion. This solvent proof design allows all circuit board components
to be cleaned together, at the same time, without resorting to more expensive epoxy end-sealed
capacitors. Refer to the Mini-Glossary for recommended cleaning conditions.
Summary of Specifications
Radial lead terminals.
Capacitance range: 0.47 to 6,800µF.
Voltage range: 6.3 to 100VDC.
Operating temperature range: 55 C to 105 C.
Leakage current: 0.06CV or 10µA, whichever is greater, after 1 minute or
0.03CV or 3µA, whichever is greater, after 5 minutes at 20 C.
Standard capacitance tolerance: 20%
Nominal case size (D L): 5 11mm to 18 35.5mm.
Rated lifetime: 1,000 hours at 105 C.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
167
KMEBP Series
KMEBP Specifications
Item
Operating Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
I
I
55 to 105 C
6.3 to 100VDC
0.47 to 6,800 F
20% ( M ) at
20 C, 120Hz
Characteristics
0.06CV or 10 A, whichever is greater, after 1 minute at 20 C.
0.03CV or 3 A, whichever is greater, after 5 minutes at 20 C.
Where I = Leakage current ( A ), C = Nominal capacitance ( F ) and V = Rated voltage ( V )
MINIATURE -105 C
Dissipation Factor ( Tan )
At
20 C, 120Hz
6.3 -10
0.24
16- 25
0.20
35
0.16
50
0.14
63 -80
0.12
100
0.10
Rated Voltage ( V )
Tan
( DF )
KMEBP
When nominal capacitance exceeds 1,000 F, add 0.02 to the values above for each 1,000 F increase.
Low Temperature
Characteristics
At 120Hz, impedance ( Z ) ratio between the
exceed the values given below.
Rated Voltage ( V )
Z ( 25 C ) / Z ( 20 C )
Z ( 40 C ) / Z ( 20 C )
6.3
4
10
10
3
8
25 C or
16
2
6
40 C value and
25
2
4
35
2
3
20 C value shall not
50
2
3
63 -100
2
3
Ripple Current Multipliers
Refer to Section 4 of the
Mini-Glossary for explanation
of Ripple Current Multipliers.
Ambient Temperature ( C )
70 C
2.09
85 C
1.75
105 C
1.00
Frequency (Hz )
Capacitance ( F )
≤
3.3 F
4.7- 33 F
47-1000 F
≥
2200 F
50Hz
0.65
0.75
0.80
0.85
120Hz
1.00
1.00
1.00
1.00
300Hz
1.35
1.25
1.15
1.03
1kHz
1.75
1.50
1.30
1.05
10kHz
2.30
1.75
1.40
1.08
100kHz
2.50
1.80
1.50
1.08
Load Life
The following specifications shall be satisfied when the capacitors are restored to 20 C
after subjecting them to the DC rated voltage for 1,000 hours at 105 C. Polarization shall be
reversed every 250 hours. The sum of DC voltage and peak AC voltage must not exceed the
full rated voltage of the capacitors.
Capacitance change:
≤
25% of initial measured value for
≤
16V
:
≤
20% of initial measured value for
≥
25V
Tan ( DF )
:
≤
150% of initial specified value
Leakage current
:
≤
initial specified value
Shelf Life
The following specifications shall be satisfied when the capacitors are restored to 20 C after
exposing them for 500 hours at 105 C without voltage applied. The rated voltage shall be
applied to the capacitors for a minimum of 30 minutes, at least 24 hours and not more than
48 hours before the measurements.
Capacitance change:
≤
25% of initial measured value for
≤
16V
:
≤
20% of initial measured value for
≥
25V
Tan ( DF )
:
≤
150% of initial specified value
Leakage current
:
≤
initial specified value
Others
Satisfies characteristic W of JIS C5141
168
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
KMEBP Series
Diagram of Dimensions
VB/Radial Lead
Unit: mm
PVC Sleeve
d
D
'
D
F
F
F
F
L
Vent
(Except 5)
L
'
15
MIN.
4
MIN.
5~ 8
10
12.5 ~ 18
MINIATURE -105 C
KMEBP
Gas escape end seal for all case diameters.
Ø
D
Ø
D
'
max.
For optional lead configurations and tape and ammo
packaging, refer to the beginning of the Miniature section.
5
6.3
8
10, 12.5
16, 18
0.5
0.5
Ø
D 0.5
Ø
D 0.5
Ø
D 0.5
Ø
D
Ø
D
L
'
max.
L 1.5
L 1.5
L 1.5
L 1.5
L 1.5
Ø
d
0.5
0.5
0.6
0.6
0.8
F 0.5
2.0
2.5
3.5
5.0
7.5
Part Numbering System for KMEBP Series
KMEBP
100
VB
3R3
M
6X11
LL
When ordering, always specify complete catalog number for KMEBP Series.
Lead Length: LL is Standard.
Case Code: See Case Sizes in Tables.
Capacitance Tolerance: M = 20%
Capacitance Value: Expressed in Microfarads. The first two digits are
significant figures, and the third digit indicates the number of zeros
for capacitance of 100 F or more. R indicates the decimal point for
capacitance less than 100 F (e.g. R33 = .33 F; 3R3 = 3.3 F;
33R = 33 F; 331 = 330 F; 332 = 3,300 F; 333 = 33,000 F ).
Lead Configuration: VB = Radial Lead Terminals.
DC Rated Voltage: Expressed in Volts (e.g. 100 = 100WVDC).
Series Name: Indicates Basic Capacitor Design.
Standard Voltage Ratings - VB/Radial Lead
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
Part Number
Nominal
Case Size*
D L ( mm )
Maximum ESR
(
Ω
) at
20 C, 120Hz
Maximum
Ripple Current
( mA rms) at
105 C, 120Hz
185
260
460
820
1,110
1,430
1,830
54
90
150
240
6.3 Volts
8 Volts Surge
330
470
1,000
2,200
3,300
4,700
6,800
47
100
220
330
KMEBP6.3VB331M8X11LL
KMEBP6.3VB471M10X12LL
KMEBP6.3VB102M10X20LL
KMEBP6.3VB222M12X25LL
KMEBP6.3VB332M16X25LL
KMEBP6.3VB472M16X31LL
KMEBP6.3VB682M18X35LL
KMEBP10VB47RM5X11LL
KMEBP10VB101M6X11LL
KMEBP10VB221M8X11LL
KMEBP10VB331M10X16LL
8
10
10
12.5
16
16
18
5
6.3
8
10
11.5
12.5
20
25
25
31.5
35.5
11
11
11.5
16
1.205
0.846
0.398
0.196
0.141
0.106
0.083
8.464
3.978
1.808
1.205
10 Volts
13 Volts Surge
*
The case sizes in table are with no sleeve, refer to diagram for case sizes with sleeve.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
169
KMEBP Series
Standard Voltage Ratings - VB/Radial Lead
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
Part Number
Nominal
Case Size*
D L ( mm )
Maximum ESR
(
Ω
) at
20 C, 120Hz
Maximum
Ripple Current
( mA rms) at
105 C, 120Hz
290
510
910
1,200
1,520
40
49
195
265
345
605
1,070
1,400
56
67
110
215
320
380
670
1,140
30
51
86
160
290
350
465
805
7
10
15
18
22
37
63
77
105
190
340
460
590
20
24
40
68
98
130
225
405
535
680
10 Volts
13 Volts Surge
470
1,000
2,200
3,300
4,700
22
33
220
330
470
1,000
2,200
3,300
33
47
100
220
330
470
1,000
2,200
10
22
47
100
220
330
470
1,000
0.47
1.0
2.2
3.3
4.7
10
22
33
47
100
220
330
470
3.3
4.7
10
22
33
47
100
220
330
470
KMEBP10VB471M10X16LL
KMEBP10VB102M12X20LL
KMEBP10VB222M16X25LL
KMEBP10VB332M16X31LL
KMEBP10VB472M18X35LL
KMEBP16VB22RM5X11LL
KMEBP16VB33RM5X11LL
KMEBP16VB221M10X12LL
KMEBP16VB331M10X16LL
KMEBP16VB471M10X20LL
KMEBP16VB102M12X25LL
KMEBP16VB222M16X31LL
KMEBP16VB332M18X35LL
KMEBP25VB33RM6X11LL
KMEBP25VB47RM6X11LL
KMEBP25VB101M8X11LL
KMEBP25VB221M10X16LL
KMEBP25VB331M12X20LL
KMEBP25VB471M12X20LL
KMEBP25VB102M16X25LL
KMEBP25VB222M18X35LL
KMEBP35VB10RM5X11LL
KMEBP35VB22RM6X11LL
KMEBP35VB47RM8X11LL
KMEBP35VB101M10X16LL
KMEBP35VB221M12X20LL
KMEBP35VB331M12X20LL
KMEBP35VB471M12X25LL
KMEBP35VB102M16X31LL
KMEBP50VBR47M5X11LL
KMEBP50VB1R0M5X11LL
KMEBP50VB2R2M5X11LL
KMEBP50VB3R3M5X11LL
KMEBP50VB4R7M5X11LL
KMEBP50VB10RM6X11LL
KMEBP50VB22RM8X11LL
KMEBP50VB33RM8X11LL
KMEBP50VB47RM10X12LL
KMEBP50VB101M10X20LL
KMEBP50VB221M12X25LL
KMEBP50VB331M16X25LL
KMEBP50VB471M16X31LL
KMEBP63VB3R3M5X11LL
KMEBP63VB4R7M6X11LL
KMEBP63VB10RM6X11LL
KMEBP63VB22RM8X11LL
KMEBP63VB33RM10X12LL
KMEBP63VB47RM10X16LL
KMEBP63VB101M12X20LL
KMEBP63VB221M16X25LL
KMEBP63VB331M16X31LL
KMEBP63VB471M18X35LL
10
12.5
16
16
18
5
5
10
10
10
12.5
16
18
6.3
6.3
8
10
12.5
12.5
16
18
5
6.3
8
10
12.5
12.5
12.5
16
5
5
5
5
5
6.3
8
8
10
10
12.5
16
16
5
6.3
6.3
8
10
10
12.5
16
16
18
16
20
25
31.5
35.5
11
11
12.5
16
20
25
31.5
35.5
11
11
11.5
16
20
20
25
35.5
11
11
11.5
16
20
20
25
31.5
11
11
11
11
11
11
11.5
11.5
12.5
20
25
25
31.5
11
11
11
11.5
12.5
16
20
25
31.5
35.5
0.846
0.398
0.196
0.141
0.106
15.068
10.045
1.507
1.005
0.705
0.332
0.166
0.121
10.045
7.053
3.315
1.507
1.005
0.705
0.332
0.166
26.52
12.055
5.643
2.652
1.205
0.804
0.564
0.265
493.723
232.05
105.477
70.318
49.372
23.205
10.548
7.032
4.937
2.321
1.055
0.703
0.494
60.273
42.319
19.89
9.041
6.027
4.232
1.989
0.904
0.603
0.423
MINIATURE -105 C
KMEBP
16 Volts
20 Volts Surge
25 Volts
32 Volts Surge
35 Volts
44 Volts Surge
50 Volts
63 Volts Surge
63 Volts
79 Volts Surge
*
The case sizes in table are with no sleeve, refer to diagram for case sizes with sleeve.
170
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
KMEBP Series
Standard Voltage Ratings - VB/Radial Lead
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
Part Number
Nominal
Case Size*
D L ( mm )
Maximum ESR
(
Ω
) at
20 C, 120Hz
Maximum
Ripple Current
( mA rms) at
105 C, 120Hz
16
89
105
140
245
435
570
80 Volts
100 Volts Surge
2.2
22
33
47
100
220
330
0.47
1.0
2.2
3.3
4.7
10
22
33
47
100
220
KMEBP80VB2R2M5X11LL
KMEBP80VB22RM10X16LL
KMEBP80VB33RM10X16LL
KMEBP80VB47RM10X20LL
KMEBP80VB101M12X25LL
KMEBP80VB221M16X31LL
KMEBP80VB331M18X35LL
KMEBP100VBR47M5X11LL
KMEBP100VB1R0M5X11LL
KMEBP100VB2R2M6X11LL
KMEBP100VB3R3M6X11LL
KMEBP100VB4R7M6X11LL
KMEBP100VB10RM8X11LL
KMEBP100VB22RM10X16LL
KMEBP100VB33RM12X20LL
KMEBP100VB47RM12X20LL
KMEBP100VB101M16X25LL
KMEBP100VB221M18X35LL
5
10
10
10
12.5
16
18
5
5
6.3
6.3
6.3
8
10
12.5
12.5
16
18
11
16
16
20
25
31.5
35.5
11
11
11
11
11
11.5
16
20
20
25
35.5
90.409
9.041
6.027
4.232
1.989
0.904
0.603
352.66
165.75
75.341
50.227
35.266
16.575
7.534
5.023
3.527
1.658
0.753
MINIATURE -105 C
100 Volts
125 Volts Surge
8
12
20
25
30
50
97
140
170
300
510
KMEBP
*
The case sizes in table are with no sleeve, refer to diagram for case sizes with sleeve.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
171
Energy Infrastructure?
京公网安备 11010802033920号
EEWORLD
