CV2
Features
SMD Aluminum Electrolytic Capacitors
‧
3 ~ 10φ, 85
℃
, 2,000 hours assured
‧
Chip type large capacitance capacitors
‧
Designed for surface mounting on high density PC board.
‧
RoHS Compliance
SPECIFICATIONS
Items
Operating Temperature Range
Capacitance Tolerance
Leakage Current (at 20℃)
Dissipation Factor
(Tanδat 120Hz, 20℃)
Low Temperature
Characteristics (at 120Hz)
Performance
-40℃ ~ +85℃
±20%
I = 0.01CV or 3 (μA) whichever is greater (after 2 minutes)
Where, C= rated capacitance in
μF.
V = rated DC working voltage in V.
Rated Voltage
Tanδ(max)
4
0.42
6.3
0.28
10
0.24
16
0.20
25
0.14
35
0.12
50
0.10
63
0.10
100
0.10
(at 120Hz, 20℃)
Impedance ratio shall not exceed the values given in the table below.
Rated Voltage
4
6.3
10
16
25
35
7
4
3
2
2
2
Impedance Z(-25℃)/Z(+20℃)
Ratio
Z(-40℃)/Z(+20℃)
15
8
5
4
3
3
Test Time
Capacitance Change
Dissipation Factor
Leakage Current
50
2
3
63
2
3
100
2
3
Load Life Test
2,000 Hrs
Within
±20%
of initial value (4WV:±30%)
Less than 200% of specified value (4WV:±300%)
Within specified value
* The above specifications shall be satisfied when the capacitors are restored to 20℃after the rated voltage
applied for 2,000 hrs at 85℃.
Shelf Life Test
Test time: 1,000 hrs; other items are the same as those for the load life test.
Freq.(Hz)
V.DC(V)
50
0.8
0.8
0.8
0.7
120
1.0
1.0
1.0
1.0
1K
1.15
1.25
1.35
1.35
10K up
1.25
1.40
1.50
1.50
Ripple Current &
Frequency Multipliers
Under 16
25 ~ 35
50 ~ 63
100
Other Standards
JIS C 5101-1, -18
DIAGRAM OF DIMENSIONS
LEAD SPACING AND DIAMETER
φD
3
4
5
6.3
6.3
8
8
10
10
L
5.3±0.2
5.3±0.2
5.3±0.2
5.3±0.2
7.7±0.3
6.5±0.3
10±0.5
10±0.5
10.3±0.5
A
3.3
4.3
5.3
6.6
6.6
8.4
8.4
10.4
10.4
B
3.3
4.3
5.3
6.6
6.6
8.4
8.4
10.4
10.4
C
1.5
2.0
2.3
2.7
2.7
3.4
3.0
3.3
3.3
W
0.45 ~ 0.75
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.7 to 1.1
0.7 to 1.1
0.7 to 1.1
Unit: mm
P±0.2
0.8
1.0
1.5
2.0
2.0
2.3
3.1
4.7
4.7
