TBJ Series
COTS-Plus
This series features:
• CWR11 form factor in Standard and
Extended ratings.
• Low ESR Ratings (Cases A through E).
• Extended Case size (E) for ratings to
470 µF.
• Weibull Reliability Grading and Surge
Test options.
All ratings in this series offer the
advantages of molded body/compliant
termination construction, polarity,
capacitance and voltage marking. The
molded construction is compatible with
a wide range of SMT board assembly
processes including wave or reflow
solder, conductive epoxy or compres-
sion bonding techniques.
CASE DIMENSIONS:
millimeters (inches)
L
W
Code
A
EIA
Code
3216-18
3528-21
6032-28
7343-31
7343-43
7361-38
L±0.20 (0.008)
3.20 (0.126)
3.50 (0.138)
6.00 (0.236)
7.30 (0.287)
7.30 (0.287)
7.30 (0.287)
W+0.20 (0.008)
–0.10 (0.004)
1.60 (0.063)
2.80 (0.110)
3.20 (0.126)
4.30 (0.169)
4.30 (0.169)
6.10 (0.240)
H+0.20 (0.008)
–0.10 (0.004)
1.60 (0.063)
1.90 (0.075)
2.60 (0.102)
2.90 (0.114)
4.10 (0.162)
3.45±0.30
(0.136±0.012)
W1 ±0.20
(0.008)
1.20 (0.047)
2.20 (0.087)
2.20 (0.087)
2.40 (0.094)
2.40 (0.094)
3.10 (0.120)
A+0.30 (0.012)
–0.20 (0.008)
0.80 (0.031)
0.80 (0.031)
1.30 (0.051)
1.30 (0.051)
1.30 (0.051)
1.40 (0.055)
S Min.
1.10 (0.043)
1.40 (0.055)
2.90 (0.114)
4.40 (0.173)
4.40 (0.173)
4.40 (0.173)
H
B
C
D
A
S
A
W
1
E
V
MARKING (Military
(Brown marking on gold body)
MARKING
(Brown marking on gold body)
Polarity stripe (+)
“J” for “JAN” Brand
Capacitance Code
Rated Voltage
Manufacturer’s ID
Polarity Stripe (+)
Capacitance Code
Rated Voltage
Manufacturer’s ID
Lot Number
HOW TO ORDER
TBJ
Type
D
Case
Size
227
Capacitance
Code
pF code:
1st two digits
represent
significant
figures 3rd digit
represents
multiplier
(number of zeros
to follow)
*
Capacitance
Tolerance
M = ±20%
K = ±10%
J = ±5%
006
Voltage
Code
004 = 4Vdc
006 = 6Vdc
010 = 10Vdc
016 = 16Vdc
020 = 20Vdc
025 = 25Vdc
035 = 35Vdc
050 = 50Vdc
C
Standard or
Low ESR
Range
C = Std ESR
L = Low ESR
#@
Qualification/
Reliability
# = Inspection Level
S = Std. Conformance
L = Group A
@ = Failure Level
Weibull:
B = 0.1%/1000 hrs.
C = 0.01%/ 1000 hrs.
(90% conf.)
Comm: Z = Non ER
00
++
Packaging
B = Bulk
R = 7" T&R
S = 13" T&R
TECHNICAL SPECIFICATIONS
Technical Data:
Capacitance Range:
Capacitance Tolerance:
Rated Voltage: (V
R
)
Category Voltage: (V
C
)
Surge Voltage: (V
S
)
Temperature Range:
Unless otherwise specified, all technical
0.1 µF to 1000 µF
±5%; ±10%; ±20%
4
6
10
16
2.7
4
7
10
5.2
8
13
20
3.4
5
8
12
-55°C to +125°C
Termination
Surge Test
Finish
Option
09 = Gold Plated
00 = None
08 = Hot Solder
23 = 10 cycles,
Dipped
+25°C
07 = 100% Tin
24 = 10 cycles,
00 = Solder Fused
-55°C &
+85°C
45 = 10 cycles,
-55ºC &
+85ºC
before
Weibull
data relate to an ambient temperature of 25°C
85°C:
125°C:
85°C:
125°C:
20
13
26
16
25
17
32
20
35
23
46
28
50
33
65
40
82
TBJ Series
COTS-Plus
CAPACITANCE AND RATED VOLTAGE, V
R
(VOLTAGE CODE) RANGE
(LETTER DENOTES CASE SIZE)
Capacitance
µF
Code
0.10
104
0.15
154
0.22
224
0.33
334
0.47
474
0.68
684
1.0
105
1.5
155
2.2
225
3.3
335
4.7
475
6.8
685
10
106
15
156
22
226
33
336
47
476
68
686
100
107
150
157
220
227
330
337
470
477
680
687
1000
108
1500
158
2200
228
Released codes
(M tolerance only)
4V (G)
6V (J)
Rated voltage DC (V
R
) to 85ºC
10V (A)
16V (C)
20V (D)
25V (E)
A
A
A/B
A/B
A/B
A
A/B/C
B
A/C/D
A/B/C/D
D
E
A
A
A
A/B
A/B
A/B
A/B/C
A/B/C
B/C
C/D
B/C/D
C/D
D
C/D
E
(M)
E /V
V*
A
A
A
A/B
A/B
A/B
A/B/C
A/B/C
B/C
A/B/C/D
C/D
C/D
C/D
D
(M)
/E
D
D
(M)
/E/V*
E
(M)
/V*
A
A
A
A/B
A/B
A/B
A/B/C
B/C
B/C
B/C/D
C/D
C/D
D
D/E
D
(M)
/V*
V*
A
A
A
A/B
B
B
A/B/C
B/C
B/C
B/C/D
C/D
C/D
D
D/E
V*
V*
A
A
A/B
A/B
A/B
A/B/C
B/C
A/B/C
B/C/D
C/D
D
C/D
D/E
D
(M)
V*
V*
35V (V)
A
A
A
A
A
(M)
/B
A
(M)
/B
A/B
A/B/C
B/C
B/C
B/C/D
C/D
C/D
C/D
D/E
D
M)
/V*
V*
50V (T)
A
(M)
/B
A
A
(M)
/B
B
A/C
A/C
A
(M)
/C
C/D
D
D
D
D
D
V*
D/V*
*Parts are not available on C level
