TECHNICAL BULLETIN TB-3064
ESD Survey Kit
Operation and Maintenance
Description
Made in the
United States of America
The Desco ESD Survey Kit is used for measuring,
verifying, and qualifing products for used in the
ESD Protected Area. The kit includes the following
instruments:
•
Digital Surface Resistance Meter
to measure
resistance point-to-point (Rtt) or surface to ground
(Rtg) in accordance with ESD Association Standard
ANSI/ESD S4.1.
AC Outlet Analyzer
to confirm that an outlet’s
wiring is correct and the path to earth ground via the
equipment grounding conductor (the green wire) is
intact.
Low Resistance Tester
to measure the resistance
of grounding paths of banana jacks and other
equipment.
Field Meter/Ionization Test Kit
to measure static
fields and to measure offset voltage (balance) and
charge decay of ionization equipment.
Training Paddle Set
to demonstrate the creation of
static charges and the functionality of ESD control
products.
•
•
•
Figure 1. Desco
50568
ESD Survey Kit, North America,
120VAC
•
The ESD Survey Kit is available in two models:
Item
50569
Region
Asia
Voltage
120VAC
220VAC
50568
North America
Figure 2. Desco
50569
ESD Survey Kit, Asia, 220VAC
DESCO WEST
- 3651 Walnut Avenue, Chino, CA 91710 • (909) 627-8178
DESCO EAST
- One Colgate Way, Canton, MA 02021-1407 • (781) 821-8370 • Website:
Desco.com
TB-3064
Page 1 of 3 January 2017
© 2017 DESCO INDUSTRIES, INC.
Employee Owned
Per ANSI/ESD S20.20 section 6.1.3.1 Compliance
Verification Plan Requirement “A Compliance
Verification Plan shall be established to ensure the
organization’s compliance with the requirements of the
Plan. Formal audits or certifications shall be conducted
in accordance with a Compliance Verification Plan
that identifies the requirements to be verified, and the
frequency at which those verifications must occur. Test
equipment shall be selected to make measurements of
appropriate properties of the technical requirements that
are incorporated into the ESD program plan.”
6.1.3.2. Compliance Verification Plan Guidance “In
addition to internal audits, external audits (Organization
and supplier of ESDS items) should be performed
to ensure compliance with planned requirements.
Verifications should include routine checks of the
Technical Requirements in the Plan. The frequency of
verification checks should be based on the control item
usage, its durability and associated risk of failure.”
This clearly states the necessity of having the means
to perform regular surveys at your facility. The ESD
Survey Kit will enable you to do this.
The ESD Program Standard ANSI/ESD S20.20 can be
downloaded here:
https://www.esda.org/standards/esda-documents/
50569 ESD SURVEY KIT, ASIA, 220VAC
Qty
1
1
1
1
1
1
Item
Description
Technical
Bulletin
TB-3062
TB-2099
TB-3070
TB-3041
-
-
19787
Digital Surface Resistance
Meter Kit
98131
AC Outlet Analyzer and
Wrist Strap Tester, Asia,
220VAC
19249
Low Resistance Tester
19493
Ionization Test Kit
-
-
Training Paddle Set
Heavy Duty Carrying Case
Packaging
Qty
1
1
1
1
1
1
Item
50568 ESD SURVEY KIT, NORTH AMERICA, 120VAC
Description
Technical
Bulletin
TB-3062
TB-2099
Figure 3. Extendable handle on the carrying case
TB-3070
TB-3041
-
-
19787
Digital Surface Resistance
Meter Kit
98132 AC Outlet Analyzer and
Wrist Strap Tester, North
America, 120VAC
19249
Low Resistance Tester
19493
Ionization Test Kit
-
-
Training Paddle Set
Heavy Duty Carrying Case
Specifications
Weight
Dimensions
28 lbs (13 kg)
22.0" x 13.8" x 9.0"
(56 cm x 35 cm x 23 cm)
DESCO WEST
- 3651 Walnut Avenue, Chino, CA 91710 • (909) 627-8178
DESCO EAST
- One Colgate Way, Canton, MA 02021-1407 • (781) 821-8370 • Website:
Desco.com
TB-3064
Page 2 of 3
© 2017 DESCO INDUSTRIES, INC.
Employee Owned
Kasuga
KSD-4000
Body
Potential Meter (sold separately)
Probe for Kasuga Meter
(sold separately)
Digital Static
Field Meter
50005
Concentric
Ring Probe
(sold separately)
Digital Surface
Resistance Meter
Ionization
Test Kit
Charging Unit
Low
Resistance
Tester
5 lbs
Electrode
Accessory
Compartment
Batteries
5 lbs
Electrode
AC Outlet
Analyzer
Training
Paddles
Figure 4. Item compartments
