XOSM-573
www.vishay.com
Vishay Dale
Surface Mount Oscillator
FEATURES
•
•
•
•
•
•
•
•
Size: 7.0 x 5.0 x 1.9 (mm)
Miniature package
Tri-state enable/disable
TTL/HCMOS compatible
Tape and reel
I
R
re-flow
3.3 V input voltage
Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
The XOSM-573 series is an ultra miniature package clock
oscillator with dimensions 7.0 mm x 5.0 mm x 1.9 mm. It is
mainly used in portable PC and telecommunication devices
and equipment
STANDARD ELECTRICAL SPECIFICATIONS
PARAMETER
Frequency range
Frequency
stability
(1)
T
OPR
T
STG
V
DD
SYMBOL
F
O
CONDITION
-
all conditions
-
-
-
25 °C ± 3 °C
1.500 MHz to 20.000 MHz
Supply current
I
DD
20.001 MHz to 50.000 MHz
50.001 MHz to 67.000 MHz
67.001 MHz to 100.000 MHz
Output symmetry
Rise/fall time
Sym
t
r
/t
f
V
OH
V
OL
t
s
at ½ V
DD
1.500 MHz to 50.000 MHz
50.001 MHz to 80.000 MHz
80.001 MHz to 100.000 MHz
Output voltage
Output load
Start-up time
Pin 1, tri-state function
-
-
-
-
-
VALUE
1.500 MHz to 100.000 MHz
± 25 ppm, ± 50 ppm, ± 100 ppm
0 ºC to 70 ºC
- 40 ºC to + 85 ºC (option)
- 55 ºC to + 125 ºC
3.3 V ± 10 %
± 5 ppm
10 mA max.
20 mA max.
30 mA max.
55 mA max.
40 %/60 % (45 %/55 % option)
6 ns
4 ns
2 ns
90 % V
DD
min.
10 % V
DD
max.
2 TTL or 15 pF
10 ms max.
pin 1 = H or open (output active at pin 3)
pin 1 = L (high impedance at pin 3)
Operating temperature range
Storage temperature range
Power supply voltage
Aging (first year)
Note
(1)
Include: 25 ºC tolerance, operating temperature range, input voltage change, aging, load change, shock and vibration
DIMENSIONS
in inches [millimeters]
0.055 [1.40]
typ.
0.276 ± 0.008
[7.0 ± 0.2]
0.079
[2.0]
#4
#1
PIN
#1
#2
#3
#4
CONNECTION
TRI-STATE/NC
GND
OUTPUT
V
DD
0.2 [5.08]
typ.
0.200
[5.08]
0.071
[1.8]
#3
0.197 ± 0.008
[5.0 ± 0.2]
#2
0.165
[4.20]
0.075 [1.90]
max.
0.102 [2.60]
typ.
0.047 [1.20]
typ.
Note
• A 0.01 μF bypass capacitor should be placed between V
DD
(pin 4) and GND (pin 2) to minimize power supply line noise
Revision: 14-Nov-12
Document Number: 35051
1
