SHEET 1 OF 1
12.70
[.500 in]
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
11.43
[.450 in]
ON
2-3, 5-6
NONE
OPEN
ON
2-1, 5-4
FLAT
ISOMETRIC
2
5
POS. 1
25
~
POS. 3
5.08
[.200 in]
7.52
[.296 in]
1.44
[.057 in]
n
[.105 in]
2.67
1
3
4
6
1/4-40 UNS-2A
.51
[.020 in]
CIRCUIT: DPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: SILVER
5. RATING: 2Amps@ 250VAC
5Amps@ 120VAC or 28VDC
6. ELECTRIC LIFE: 40,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10. DENOTES CRITICAL PARAMETER.
11. 2002/95/EC (ROHS) COMPLIANT
E-SWITCH
MARKING ON
OPPOSITE SIDE
4
4.70
[.185 in]
.76
[.030 in]
5
6
8.89
[.350 in]
12.85
[.506 in]
6
EPOXY SEAL
3
1.52
[.060 in]
1.19
[.047 in]
2.03
[.080 in]
4.83
[.190 in]
3.96
1.98
[.078 in] [.156 in]
A
REV
16760
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
12/18/06
DATE
TN
BY
TITLE
SCALE
100DP1T2B9M1QE
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
12/18/2006
TN
T121142
A
