7030 POWER INDUCTORS
High-Reliability Power Inductors
MS514PYA
■
High temperature materials allow operation in ambient
temperatures up to 155°C
■
Passes vibration testing to 80 G and shock testing to 1000 G
■
Tin-lead (Sn-Pb) termination for the best possible board
adhesion
■
High current and very low DCR
■
Soft saturation makes them ideal for VRM/VRD applications.
Core material
Composite
Terminations
Tin-lead (63/37) over copper.
Weight
0.83 – 0.86 g
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C to
+155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Tape and reel packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
250 per 7″reel
Plastic tape: 16 mm wide, 0.35 mm thick, 12 mm pocket spacing,
3.0 mm pocket depth
Inductance
2
±20% (µH)
0.16
0.30
0.60
1.0
1.5
2.2
2.7
3.3
4.7
5.6
6.8
8.2
DCR (mOhms)
3
typ
max
1.15
1.26
1.75
1.92
3.00
3.30
4.55
5.00
7.60
8.36
13.70
15.07
15.70
17.30
19.50
21.45
25.20
27.72
30.25
33.30
38.70
42.57
44.30
48.73
SRF (MHz)
4
min
typ
126
158
81
101
58
72
50
63
41
51
32
40
29
36
23
29
17
21
14
17
12
15
10
13
Irms
(A)
6
Isat
5
(A) 20°C rise 40°C rise
60.0
18.7
24.4
41.0
15.8
20.7
36.0
13.5
17.3
28.0
12.1
16.4
23.5
8.9
11.3
18.0
7.5
9.7
12.8
6.7
8.6
12.3
6.0
7.5
12.0
5.2
6.8
11.5
4.0
5.5
10.7
3.3
5.1
10.2
2.2
4.4
Part number
1
MS514PYA161MSZ
MS514PYA301MSZ
MS514PYA601MSZ
MS514PYA102MSZ
MS514PYA152MSZ
MS514PYA222MSZ
MS514PYA272MSZ
MS514PYA332MSZ
MS514PYA472MSZ
MS514PYA562MSZ
MS514PYA682MSZ
MS514PYA822MSZ
Irms
Testing
Irms
testing was performed on a
0.060″ thick pcb with 4 oz. copper
traces optimized to minimize
additional temperature rise.
Temperature rise is highly
dependent on many factors
including pcb land pattern,
trace size, and proximity to
other components. Therefore
temperature rise should be
verified in application conditions.
1. When ordering, please specify
testing
code:
MS514PYA822MSZ
Testing: Z
= COTS
H
= Group A screening per Coilcraft CP-SA-10001
N
= Group A screening per Coilcraft CP-SA-10004
2. Inductance tested at 100 kHz, 0.1 Vrms using an Agilent/HP 4192A.
3. DCR measured using a micro-ohmmeter.
4. SRF measured using an Agilent/HP 4395A or equivalent.
5. Typical dc current at which the inductance drops 30% from its value without current.
6. Typical current that causes the specified temperature rise from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
Document MS863-1 Revised 06/12/13
1102 Silver Lake Road
Cary, IL 60013
Phone 800-981-0363
Fax 847-639-1508
Email cps@coilcraft.com
www.coilcraft-cps.com
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specifications subject to change without notice.
Please check our web site for latest information.
© Coilcraft, Inc. 2013
