3-1649327-4: DescriptionPOWER/SIGNAL RELAY, SPST, MOMENTARY, 0.008A (COIL), 48VDC (COIL), 400mW (COIL), 12A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT; CategoryMechanical and electronic products relay; File Size172KB，2 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

3-1649327-4 Overview

POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.008A (COIL), 48VDC (COIL), 400mW (COIL), 12A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT

3-1649327-4 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
body width	12.7 mm
body height	15.7 mm
Body length or diameter	29 mm
Maximum coil current (DC)	0.008 A
Coil operating voltage (DC)	33.6 V
Coil power	400 mW
Coil release voltage (DC)	4.8 V
Coil resistance	5520 Ω
Maximum coil voltage (DC)	48 V
Coil/Input Power Type	DC
Maximum contact current (AC)	12 A
Maximum contact current (DC)	12 A
Contact/Output Power Type	AC/DC
Manufacturer's serial number	1649327
Installation features	THROUGH HOLE-STRAIGHT MOUNT
physical size	29mm x 12.7mm x 15.7mm
Guideline	UL; VDE
Relay action	MOMENTARY
Relay function	SPST
Relay type	POWER/SIGNAL RELAY
surface mount	NO
Termination type	SOLDER
Base Number Matches	1
