Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 5279/15C

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Pair

1

2

3

4

5

c) Pair

(1) Twists:

2) Cable Assembly

a) Twists:

b) Orientation:

c) Core Wrap

3) Shield:

a) Drain Wire

b) Braid

4) Jacket

a) Color(s)

b) Ripcord

Color

WHITE-BLACK

WHITE-BROWN

WHITE-RED

WHITE-ORANGE

WHITE-YELLOW

15 X 1 PAIR

24 (7/32) AWG Tinned Copper

0.010" Wall, Nom. PVC, Semi Rigid

Alpha Wire Color Code B

Pair

6

7

8

9

10

Color

WHITE-GREEN

WHITE-BLUE

WHITE-VIOLET

WHITE-SLATE

BLACK-BROWN

Pair

11

12

13

14

15

Color

BLACK-RED

BLACK-ORANGE

BLACK-YELLOW

BLACK-GREEN

BLACK-BLUE

0.024

0.044

2/Cond Cabled Together

9.6 Twists/foot (min)

15 Components Cabled

3.0 Twists/foot (min)

Components to be arranged from INSIDE

LAYER to OUTSIDE LAYER

Nonwoven Polyester Tape, 25% Overlap, Min.

A/P/A Tape, 25% Overlap, Min.

24 (7/32) AWG Tinned Copper

Tinned Copper,70% Coverage, Min.

0.032" Wall, Nom.,PVC

0.429 (0.452 Max.)

Slate, Black, Yellow, Orange, Blue, Green, Red, Sand Beige, White

1 End 810 Denier Nylon

ALPHA WIRE-* P/N 5279/15C 15PR 24 AWG

XTRAGUARD(R) 1 SHIELDED (UL) TYPE CM 105C OR AWM

c) Print

2464 80C 300V OR AWM 21894 105C 300V SUN RES 60C

OIL VW-1 --- LLXXXXXX CSA 105C TYPE CMG FT4

CE ROHS (SEQ FOOTAGE)

* = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

Applicable Specifications

1) UL

a) Component 1

b) Overall

AWM/STYLE 10002

AWM/STYLE 21894

SUN RES

60C OIL

AWM/STYLE 2464

CM

VW-1

2) CSA International

CMG

FT4

3) IEC

EN 60332-1 Flame Behavior

EN 60332-2 Flame Behavior

4) CE:

EU Low Voltage Directive 2014/35/EC

105°C

80°C / 300 VRMS

105°C

105°C / 300 VRMS

Environmental

1) CE: EU Directive 2011/65/EU(RoHS2):

This product complies with European Directive 2011/65/EU (RoHS Directive) of the European

Parliament and of the Council of 8 June 2011and the amending Directive 2015/863/EU of 4 June

2015 . No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web

site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

Exempt from warning labels based on the Consent Judgment. Please see Alpha's CA Prop 65

Statement for more information.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

4) Sunlight Resistance

Electrical Properties

1) Voltage Rating

2) Mutual Capacitance

3) Ground Capacitance

4) Characteristic Impedance

5) Inductance

6) Conductor DCR

7) OA Shield DCR

-35 to 105°C

10X Cable Diameter

116 Lbs, Maximum

Yes

(For Engineering purposes only)

300 VRMS

23.1 pF/ft @1 kHz, Nominal

42 pF/ft @1 kHz, Nominal

82 Ω

0.19 µH/ft, Nominal

26 Ω/1000ft @20°C, Nominal

2.6 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 500 FT

c) 100 FT

d) Bulk(Made-to-order)

Flange x Traverse x Barrel (inches)

24 x 14 x 12 Continuous length

18 x 12 x 8 Continuous length

12 x 10 x 5 Continuous length

[Spool dimensions may vary slightly]

www.alphawire.com

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742)

Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure their accuracy at the time of publication, information and specifications

described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not

ensure product availability.

Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or

implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,

even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out

of or in connection with the use, or inability to use, the information or specifications described herein.

ALPHA WIRE - CONFIDENTIAL AND PROPRIETARY

Notice to persons receiving this document and/or technical information. This document is confidential and is the exclusive property of ALPHA WIRE,

and is merely on loan and subject to recall by ALPHA WIRE at any time. By taking possession of this document, the recipient acknowledges and

agrees that this document cannot be used in any manner adverse to the interests of ALPHA WIRE, and that no portion of this document may be

copied or otherwise reproduced without the prior written consent of ALPHA WIRE. In the case of conflicting contractual provisions, this notice shall

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: 5279/15C

5279/15C , RoHS-Compliant Commencing With 8/1/2005 Production

Note: all colors and put-ups

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive (commonly known as RoHS 2), with regards to restrictions of the use of certain hazardous

substances used in the manufacture of electrical and electronic equipment. This certification extends to amending Directive 2015/863/EU which

expanded the list of restricted substances to 10 items (commonly known as RoHS 3) The reader is referred to these Directives for the specific

definitions and extents of the Directives. No Exemptions are required for RoHS Compliance on this item. Additionally, Alpha certifies that the listed

part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-2014.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

Bis(2-ethylhexyl) phthalate (DEHP)

Butyl benzyl phthalate (BBP)

Dibutyl phthalate (DBP)

Diisobutyl phthalate (DIBP)

0.1% by weight (1000 ppm)

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire:

Dave Watson, Director of Engineering & QA

Alpha Wire

711 Lidgerwood Ave.

Elizabeth, NJ 07207

Tel: 1-908-925-8000

11/1/2017
