Military Designation :
M55310/21
Package Type :
Flat Packs (FP)
Pin Connections
Vcc
13
GND
10
OUT
11
CASE
10
ITP
7, 16
Logic Levels
Stability Options
TTL
Please Click on MIL-PRF-55310 Specifications button.
Assurance Level
Class B
Electrical Specifications **
Dash Frequency
No
Range
01
02
03
11
12
13
21
22
23
1.0 MHz to 5.0 Mhz
1.0 MHz to 5.0 Mhz
1.0 MHz to 5.0 Mhz
5.0 MHz to 2.0 Mhz
5.0 MHz to 20.0 Mhz
5.0 MHz to 20.0 Mhz
20.0 MHz to 60.0 Mhz
20.0 MHz to 60.0 Mhz
20.0 MHz to 60.0 Mhz
Max. Input
Current*
70 mA
70 mA
70 mA
30 mA
30 mA
30 mA
65 mA
65 mA
65 mA
Rise/Fall
Time
15 ns (max)
15 ns (max)
15 ns (max)
15 ns (max)
15 ns (max)
15 ns (max)
5 ns (max)
5 ns (max)
5 ns (max)
Duty Cycle
40 to 60%
40 to 60%
40 to 60%
40 to 60%
40 to 60%
40 to 60%
40 to 60%
40 to 60%
40 to 60%
Aging
(per year)
± 10 ppm
± 10 ppm
± 10 ppm
± 10 ppm
± 10 ppm
± 10 ppm
± 10 ppm
± 10 ppm
± 10 ppm
* Maximum input current for no load condition. Actual configuration of TTL loads must be added to determine power supply requirements.
** Load (max.) = 10 TTL. A TTL Load is defined as: 1.6 mA sink, 0.04 mA source, and
2 pF capacitance.
M55310/21
Q-TECH
51774
M55310/21-xxxx
FREQ.
.120
3.05
MAX.
.060 / .045
1.52 / 1.14
.010
.254
.625
.050
1.27
10
15.88
SQ.
.500
12.70
MIN.
11
.450
11.43
1
.015
.381
20
Upper dimensions in inches, lower dimensions
in millimeters. Unless otherwise specified,
tolerances are .005”(.127mm).
Detailed mechanical drawings avaliable by request.
