Customer Specification

PART NO. 85612CY

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Print

(2) Color(s)

Cond

1

2

3

Color

RED #1

RED #2

RED #3

Cond

5

6

7

Color

RED #5

RED #6

RED #7

Cond

9

10

11

Color

RED #9

RED #10

RED #11

1 X 12 COND

16 (168(7x24)/38) AWG Bare Copper

0.022" Wall, Nom. PVC

0.067

0.111

ALPHANUMERIC NUMBERS - 1-ONE ALTERNATING AND

INVERTED

4

RED #4

8

RED #8

12

YELLOW/GREEN/GR

EEN

c) Cabling

(1) Twists:

(2) Orientation:

(3) Core Wrap

d) Jacket

(1) Color(s)

(2) Jacket Separator

2) Shield

3) Jacket

a) Color(s)

b) Jacket Separator

12 COND Cabled

2.7 Twists/foot (min)

Components to be arranged from INSIDE

LAYER to OUTSIDE LAYER

REMAY Tape, 25% Overlap, Min.

0.030" Wall, Nom.,PVC, Oil Resistant

BLACK

Tissue Tape, 25% Overlap, Min.

Tinned Copper BRAID Shield,85% Coverage,

Min.

0.060" Wall, Nom.,PVC, Oil Resistant

BLACK

Tissue Tape, 25% Overlap, Min.

ALPHA WIRE-* P/N 85612CY 12C 16 AWG

XTRAGUARD(R) CONTINUOUS FLEX CONTROL CABLE

RU AWM 2587 CONSTANT FLEXING --- LLXXXXXX

0.697+/- 0.039

0.543+/- 0.026

c) Print

CSA AWM I/II A/B FT1 90C 600V

CE ROHS (SEQ FOOTAGE)

* = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

Applicable Specifications

1) UL

a) Component 1

b) Overall

2) CSA International

AWM/STYLE 10012

AWM/STYLE 2587

AWM I/II A/B

FT1

3) Other

4) CE:

VDE 0472, Section 803 Oil Test

EU Low Voltage Directive 2014/35/EC

90°C / 600 VRMS

Environmental

1) CE: EU Directive 2011/65/EU(RoHS2):

This product complies with European Directive 2011/65/EU (RoHS Directive) of the European

Parliament and of the Council of 8 June 2011and the amending Directive 2015/863/EU of 4 June

2015 . No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web

site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

Exempt from warning labels based on the Consent Judgment. Please see Alpha's CA Prop 65

Statement for more information.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

Electrical Properties

1) Voltage Rating

2) Capacitance

3) Ground Capacitance

4) Inductance

5) Conductor DCR

6) OA Shield DCR

-40 to 90°C(static), -5 to 90°C (dynamic)

8X Cable Diameter(static), 8X Cable Diameter(dynamic)

269 Lbs, Maximum

(For Engineering purposes only)

600 V

RMS

50 pF/ft @1 kHz, Nominal Conductor to Conductor

90 pF/ft @1 kHz, Nominal

0.18 µH/ft, Nominal

4 Ω/1000ft @20°C, Nominal

1.68 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 500 FT

c) 100 FT

Flange x Traverse x Barrel (inches)

36 x 14 x 12 Continuous length

24 x 14 x 12 Continuous length

16 x 11 x 8 Continuous length

[Spool dimensions may vary slightly]
