D-Subminiature
.590 Footprint PCB Mount
ALL PLASTIC
RIGHT ANGLE MALE PINS
FOR PCB MOUNTING
LR49571
E60980
P
HYSICAL
P
ROPERTIES
I
NSULATION
M
ATERIAL
:
Glass filled thermoplastic
rated UL 94V-0
C
OLOR
:
Black
C
ONTACTS
:
High strength copper alloy
D
URABILITY
:
Up to 500 insertions and withdrawals
without degradation of performance, dependent
upon contact plating thickness selected
E
LECTRICAL
P
ROPERTIES
O
PERATING
V
OLTAGE
:
600 VDC (sea level)
C
URRENT
R
ATING
:
5 Amperes
C
ONTACT
R
ESISTANCE
:
10 milliohms max.
@ rated current
I
NSULATION
R
ESISTANCE
:
5000 megohms minimum
D
IELECTRIC
W
ITHSTANDING
V
OLTAGE
:
1000 VAC minimum
E
NVIRONMENTAL
P
ROPERTIES
T
EMPERATURE
R
ATING
:
-55˚C TO 125°C
Ordering Information
NUMBER
CATALOG NUMBER BY MOUNTING STYLE
OF
BASIC CONNECTOR
ROUND STANDOFF
FLUSH INSERT
CONTACTS
W/THRU HOLES
4-40 THREAD
4-40 THREAD
9
15
25
37
H2M09RA29A
H2M15RA29A
H2M25RA29A
H2M37RA29A
H2M09RA29B
H2M15RA29B
H2M25RA29B
H2M37RA29B
H2M09RA29C
H2M15RA29C
H2M25RA29C
H2M37RA29C
DIMENSIONS
LATCH W/STANDOFF
& 4-40 THREADED INSERT
H2M09RA29J
H2M15RA29J
H2M25RA29J
H2M37RA29J
A
1.224
1.552
2.092
2.740
B
.984
1.312
1.852
2.500
C
.666
.994
1.534
2.183
D
.624
.952
1.492
2.140
Add suffix S for metal snap latches and P for plastic. See page 416 for descriptions. Not available on basic connector.
Suffix T = shipped in tubes.
Thomas & Betts Electronics/OEM Division Tel: 901-252-5000 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in millimeters (inches).
