Rear panel feed-through - SM-5EP1N8AQL03 - 1605795
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://download.phoenixcontact.com)
Rear panel feed-through, straight, Screw locking, M40, Number of positions: 2+3+PE, Type of contact: Male
connector, Crimp connection, Axial O-ring, Central fixing, Shielded: Yes, Cable cross section: 12.5 mm...17 mm
The figure shows the 8-pos.
(4+3+PE) product version
Key commercial data
Packing unit
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
1 PCE
576.48 GRM
85366990
Germany
Technical data
General
Note
Type of locking
Coding
Contact connection method
Type of contacts
Number of positions
Contact diameter of power contacts
Nominal current per power contact at 25°C
Contact diameter of signal contacts
Nominal current per signal contact at 25°C
Conductor entry
Mounting type
Order information Order crimp contacts 2 x Ø 2 mm, 4 x Ø 3.6 mm
separately
Screw locking
N
Crimp connection
Male connector
6
3.6 mm
70 A
2 mm
30 A
12.5 mm ... 17 mm
Central fixing
Ambient conditions
11/22/13 Page 1 / 4
https://www.phoenixcontact.com/us/products/1605795
Rear panel feed-through - SM-5EP1N8AQL03 - 1605795
Technical data
Ambient conditions
Ambient temperature
Degree of protection
-20 °C ... 125 °C
IP67
Material
Housing material
Insulator material
Gasket and O-ring material
Turned parts: copper zinc alloy (CuZn), die-cast parts: zinc (GD-Zn)
PA 66
FPM
Specifications according to DIN EN 61984:2001
Installation height max.
Nominal / operating voltage of power contacts
Rated surge voltage of power contacts
Surge voltage category of power contacts
Pollution degree of power contacts
Nominal / operating voltage of signal contacts
Rated surge voltage of signal contacts
Surge voltage category of signal contacts
Pollution degree of signal contacts
3000 m
630 V
6 kV
III
3
250 V
4 kV
III
3
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
272607xx
27260701
27260701
27260701
27260708
27440312
27440312
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC001121
EC001121
EC002635
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
43172015
43201404
43172015
11/22/13 Page 2 / 4
https://www.phoenixcontact.com/us/products/1605795
© Phoenix Contact 2013 - all rights reserved
http://www.phoenixcontact.com
11/22/13 Page 4 / 4
