SLCC (CNP)
www.vishay.com
Vishay Sfernice
Hermetic, 50 Mil Pitch, Leadless Chip Thin Film Resistor Networks
FEATURES
• High stability ultrafilm (0.05 % at 1000 h at
+ 70 °C under Pn)
• Custom available (CNP)
• Low noise < - 35 dB
• SMD
• Hermetic package
Actual Size
• Leadless chip carrier
• 10
to 100 k
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
Capable of meeting the characteristics of MIL-PRF-83401
these networks are available in a wide range of resistance
values: several standard configurations are presented with
the SLCC series.
SCHEMATIC
SLCC 20 A03
1 kΩ to 100 kΩ
13 12 11 10 9
14
15
16
17
18
19 20 1 2 3
8
7
6
5
4
14
15
16
17
18
19 20 1
2 3
SLCC 20 A06
1 kΩ to 100 kΩ
13 12 11 10 9
8
7
6
5
4
SLCC 20A
(10 Isolated Resistors)
10
Ω
to 100 kΩ
13 12 11 10 9
14
15
16
17
18
19 20 1 2 3
8
7
6
5
4
14
15
16
17
18
SLCC 20B
(19 Resistors + 1 Common Point)
10
Ω
to 100 kΩ
13 12 11 10 9
8
7
6
5
4
19 20 1 2 3
Gold Terminals
Option: Tin/silver plating: 076
Notes
• For values outside ohmic range please consult Vishay Sfernice
• For custom networks a specific part number is used CNPxxxx. Please consult Vishay Sfernice
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
SLCC (CNP)
SIZE
3535
RESISTANCE
RANGE
10 to 100K
POWER
POWER
RATING PER RATING PER
RESISTOR
(1)
PACKAGE
(1)
W
W
0.050
0.500
ABSOLUTE
TOLERANCE
(2)
±%
0.1, 0.5, 1, 2, 5
RATIO
TOLERANCE
±%
(2)
ABSOLUTE
TCR
(3)
± ppm/°C
25
RATIO
TCR
(4)
± ppm/°C
2, 5
0.1, 0.25, 0.5, 1
Notes
(1)
at + 70 °C
(2)
Tighter specs on request
(3)
at - 55 °C to 155 °C
(4)
± 2 ppm/°C typical, 5 ppm/°C maximum at - 55 °C to 155 °C
Revision: 29-Aug-12
Document Number: 60014
1
For technical questions, contact:
sferthinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
SLCC (CNP)
www.vishay.com
Vishay Sfernice
SPECIFICATIONS
0.05 %
< 0.1 ppm/V
100 V
DC
on
R
- 35 dB typical
0.1 μV/°C
< 50 ppm
1 year at + 25 °C
CONDITIONS
1000 h at + 70 °C under Pn
PERFORMANCES
TEST
Stability (R ratio)
Voltage coefficient
Working voltage
Noise
Thermal EMF
Shelf life stability
CLIMATIC SPECIFICATIONS
Operating temperature range
Storage temperature range
- 55 °C to + 155 °C
- 55 °C to + 155 °C
DIMENSIONS
in millimeters [inches]
B
SLCC-20A06
1K
D
max.
G
typ.
R typ.
20 Pin
A
B
C
D
E
F
Index
Corner
Terminal
#1
1.27 [0.050]
8.89 [0.350]
8.89 [0.350]
1.96 [0.077]
0.635 [0.025]
1.27 [0.050]
1.02 [0.040]
0.508 [0.020]
Terminal #1
Indicator
C
PACKAGING
Tape and reel 250 pieces per tape.
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: SLCC20A03-10KF005
AO
F
A
typ.
F
G
H
E
typ.
H
S
L
C
C
2
0
A
0
VALUE
3
-
1
0
TOL.
K
F
T
0
0
5
OPTION
Leave blank
if no option
GLOBAL MODEL
SLCC20
SCHEMATIC
A
B
A03
A06
PACKAGING
T:
Tape and reel
Blank: Tube
Decimal
R, K or M
B
(0.1 %
D
(0.5 %
F
(1.0 %
G
(2.0 %
J
(5.0 %
0.1 %)
0.25 %)
0.5 %)
1.0 %)
1.0 %)
For custom specification:
CNP
GLOBAL MODEL
1186
REFERENCE
Reference is assigned by Vishay Sfernice
Revision: 29-Aug-12
Document Number: 60014
2
For technical questions, contact:
sferthinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
