Metallized Polyester
Film Capacitors
F
EATURES
•
•
•
EMPE
Series
(Box type)
MERITEK
•
Non-inductive construction
Self-healing properties
High moisture resistance
Good solderability
S
PECIFICATIONS
1. Operating temperature:
2.
3.
4.
5.
6.
Capacitance range:
Capacitance tolerance:
Rated voltage:
Dissipation factor:
Insulation resistance:
-40
o
C to +85
o
C
0.01μF to 6.8μF
±5%(J), ±10%(K), ±20%(M)
100VDC, 250VDC, 400VDC, 630VDC
1.0% max. at 1KHz, 25
o
C
>30000MΩ (C
≤
0.33μF)
>10000MΩ
• μF
(C > 0.33μF)
P
ART
N
UMBERING
S
YSTEM
Meritek Series
Capacitance
Code
( pF )
( nF )
(
μF
)
101
100
---
---
102
1,000
1
0.001
103
10,000
10
0.01
104
100,000
100
0.1
EMPE
474
J
2E
are constructed with metallized polyester
film dielectric, tinned copper leads, plastic casing,
and epoxy resin for sealing. They are suitable for
filtering, bypassing,
blocking, and coupling/
decoupling.
EMPE are ideal for use in data
processing and telecommunication equipment, as
well as automatic control systems.
0.5
EMPE
105
1000
1
106
10
W
0.5
T
Tolerance
Code
Tolerance (%)
J
±5
K
± 10
M
± 20
H
6.0
P
0.5
0
1
d
Rated Voltage
Code
Voltage
2A
100
2E
250
2G
400
2J
630
Tape & Reel / Tape & Ammo available for lead space < 10 mm
Please contact factory for part number
Dimensions in millimeters (mm)
RV
CASE
100VDC
250VDC
400VDC
630VDC
CASE
CAP(
μF
)
0.010
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
C1
C1
C1
C1
C2
D1
D2
D3
E2
E2
E4
F1
F2
C1
C1
C2
D1
D2
D2
E2
E2
E4
F1
F2
D1
D1
D2
E1
E2
E3
E4
F1
F2
C2
C2
C2
C2
D2
D2
E2
E3
F1
F2
C1
C1
C1
C1
C2
C1
C2
C3
D1
D2
D3
D4
E1
E2
E3
E4
F1
F2
F3
13.0
13.0
13.0
18.0
18.0
18.0
18.0
26.5
26.5
26.5
26.5
32.0
32.0
32.0
9.0
11.0
12.0
11.0
12.0
13.5
14.5
15.0
16.5
17.5
19.0
20.0
22.0
30.0
4.0
5.0
6.0
5.0
6.0
7.5
8.5
6.0
7.0
8.5
10.0
11.0
13.0
15.0
10.0
10.0
10.0
15.0
15.0
15.0
15.0
20.0
20.0
20.0
20.0
27.5
27.5
27.5
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
DIM.
W
H
T
P±1
dØ
Custom sizes and lead spacing available upon request
Custom values and tolerances available upon request
Specifications are
subject to change without notice.
rev.6a
