FEATURES
Standardized case sizes
-
High ripple current
–
Multiple case sizes
APPLICATIONS
Bypass
–
Coupling
–
Filtering
–
De-coupling
Operating Temperature
Range
Capacitance Tolerance
WVDC
Surge Voltage
SVDC
WVDC
Dissipation
Factor
Tan
δ
-55°C to +105°C
+20% at 120 Hz, 20°C
6.3
7.9
6.3
.22
10
13
10
.19
16
20
16
.16
25
32
25
.14
35
44
50
63
63
79
100
125
Leakage Current
Low
Temperature
Stability
Impedance
Ratio
(120 Hz)
35
50
63
100
.12
.1
.08
.08
Add .02 for every 1000uF above 1000uF
6.3 to 100 WVDC
1 Minutes
2 Minutes
.03CV or 4uA,
.01CV or 3uA,
Whichever is greater
Whichever is greater
WVDC
-25°C to +20°C
-40°C to +20°C
6.3
2
3
10
2
3
16
2
3
25
2
3
35
2
3
50
2
3
63
2
3
100
2
3
Load Life
Shelf Life
Ripple Current Multipliers
5000 hours at 105°C with rated WVDC and ripple current applied
(4000 hrs for D=10, 3000 Hrs for D=8, 2000 Hrs for D<6.3)
Capacitance Change
<25% of initial measured value
Dissipation Factor
<150% of maximum specified value
Leakage Current
>100% of maximum specified value
1000 hours at 105°C with no voltage applied
Capacitance Change
<25% initial measured value
Dissipation Factor
<200% of maximum specified value
Leakage Current
>100% of maximum specified value
Frequency (Hz)
Temperature (°C)
Capacitance
50
120
1k
10k
100k
+105
+85
+70
C<33
.45
.55
.75
.91
1.0
1.0
1.41
1.65
33<C<330
.6
.7
.85
.95
1.0
1.0
1.41
1.65
330<C<1000
.65
.75
.9
.98
1.0
1.0
1.41
1.65
C>1000
.75
.8
.95
1.0
1.0
1.0
1.41
1.65
D
5
6.3
S
2.0
2.5
d
0.5
0.5
L
1
=L+1.5mm Max.
D
1
=D+0.5mm Max.
S
1
=S+0.5 mm
8
3.5
0.6
10
5.0
0.6
12.5
5.0
0.6
16
7.5
0.8
18
7.5
0.8
mm
