POWER SOLUTION - NIKKOHM
1W to 14W AXIAL LEAD WIRE WOUND RESISTORS
ARW
Features and Applications
Precision wire wound fixed resistor from 0.5W to 10W rating power.
Operating temperature range from –55C to 275C are performed by using strong silicone
resin.
Welding structure and high purity ceramic core assures long life stability.
Strong over load characteristics are fit for applications of industrial power electronics,
industrial measurements, automatic testing, switching power supplies, motor control
electronics, rush current protection in automotive electronics, industrial power supplies.
Dimensions (mm)
E
A
B
C
D
Working
A
B
C
D
E
Voltage
ARW0.5
1.0W(0.5W)
20V
10.0+/-1.5
12.0 Max.
3.3+/-1.0
0.7+/-0.06
37+/-1.0
ARW1
2.0W(1.0W)
50V
12.0+/-1.5
14.0 Max.
4.0+/-1.0
0.8+/-0.06
37+/-1.0
ARW2
3.0W(2.0W)
100V
13.8+/-1.5
15.8 Max.
4.7+/-1.0
0.8+/-0.06
35+/-1.0
ARW3
5.0W(3.0W)
200V
15.7+/-1.5
17.7 Max.
5.9+/-1.0
0.8+/-0.06
35+/-1.0
ARW5
7.0W(5.0W)
400V
22.5+/-1.5
25.4 Max.
8.52+/-1.0
1.0+/-0.06
44+/-1.0
ARW7
10.0W(7.0W)
450V
24.5+/-1.5
26.5 Max.
8.52+/-1.0
1.0+/-0.06
44+/-1.0
ARW-10S
14.0W(10W)
700V
39.8+/-1.5
41.8 Max.
8.52+/-1.0
1.0+/-0.06
36+/-1.0
ARW-10L
14.0W(10W)
800V
46.2+/-1.5
48.2 Max.
10.5+/-1.0
1.0+/-0.06
33+/-1.0
Note: Ratings are shown at max. ambient tem. of 275C, (Rating W) shall be used at 350C max. temperature.
Type
Rating Power
Ordering Information
P/N
ARW1N-10R0F000
ARW3-50RF000
ARW5N-1.2KF000
ARW10S-50K0F000
Type
ARW1
ARW3
ARW5
ARW5
Inductive/Non-inductive
N
N
TC
-
-
-
-
Resistance
10R0
50ohm
1.2Kohm
50Kohm
Tolerance
+/-1%(F)
+/-1%(F)
+/-1%(F)
+/-1%(F)
Additional
000
000
000
000
POWER SOLUTION - NIKKOHM
0.5W to 10W AXIAL LEAD WIRE WOUND RESISTORS
ARW
Specifications
Resistance Ranges
Rating
Working
Tolerance
Power
Voltage
Inductive
Non-inductive
ARW0.5
1W(0.5W)
20V
0.1-3K
0.1-1.5K
ARW1
2W(1.0W)
50V
0.1-8K
0.1-3K
ARW2
3W(2.0W)
100V
0.1-10K
0.1-4K
+/-0.05(A)
+/-0.1(B)
ARW3
5W(3.0W)
200V
0.1-18K
0.1-9K
+/-1.0(F)
ARW5
7W(5.0W)
400V
0.1-35K
0.1-17K
+/-5.0(J)
ARW7
10W(7.0W)
450V
0.1-50K
0.1-25K
ARW10S
14W(10.0W)
700V
0.1-70K
0.1-35K
800V
0.1-100K
0.1-50K
ARW10L
14W(10.0W)
Note: Resistance ranges are shown at tolerance of +/-1%, please call factory for +/-0.1% and +/-0.05%.
Type
Performance
Temperature Coefficient
Load Life
Humidity
Thermal Shock
Short Time Overload
Dielectric
Insulation Resistance
Low Temperature Storage
High Temperature Storage
Mechanical Shock
Vibration
Thermal Strength
Note:
(1) Below 1ohm: +/-90ppm/C, 1ohm to 9.9ohm:
+/-50ppm/C and 10ohms and above: +/-20ppm/C.
(2) Rated Power.
Rated power shall be applied under conditions in
which the ambient temperature is in 25C. (Refer
to right figure)
(3) Rated Voltage
Rated voltage shall be obtained from the following
equation E
2
= P*R, where, E is rating voltage, P is
rating power and R is nominal resistance.
Specifications
20 to 90 ppm/C
+/-(0.5%+0.05ohm)
+/-(0.2%+0.05ohm)
+/-(0.2%+0.05ohm)
+/-(0.2%+0.05ohm)
+/-(0.1%+0.05ohm)
1000Megohm min.
+/-(0.2%+0.05ohm)
+/-(0.5%+0.05ohm)
+/-(0.1%+0.05ohm)
+/-(0.1%+0.05ohm)
+/-(0.1%+0.05ohm)
Derating
%Rating Watts
Conditions
See note(1)
500VAC min.
Dry condition.
100
50
0
-50
25C
275C
0
50 100 150 200 250 300
Ambient Temperature (C)
Materials
Core:
Resistance wire:
Terminal caps:
Leads:
Protection:
Alumina ceramic.
CuNi or NiCr alloy.
Metal cap
Tin plated copper, welded to cap.
Silicone resin.
20030112
