SERIES 28
HiPer-D
®
Standard and High-Density Connectors
280-024P right angle PC tail pin connectors with O-ring flange for
rear panel mounting
Right angle printed circuit board HiPer-D® pin connectors feature rugged
one-piece machined aluminum shell and stainless steel shroud for improved
EMI protection. Contacts are non-removable size #20 or #22 PC tail contacts.
Intermateable with standard M24308-type D-Subminiature connectors, the
HiPer-D® features environmental sealing and optional ground springs for improved
resistance to electromagnetic interference. #4-40 threaded mounting holes
simplify panel attachment. Threaded holes on the bottom of connector allow
attachment to circuit board. Contacts are potted with epoxy. Glass-reinforced
thermoset epoxy insulators, fluorosilicone face seal. 1000 VAC, 5 Amps (#22) or 7.5
Amps (#20).
How To Order
Sample Part Number
Basic Part Number
Shell Size-
Contact Arrangement
Shell Finish
Ground Spring
Mating Hardware
PC Tail Length
280-024P
See Shell Size - Contact Arrangements Table
ME
= Electroless Nickel
JF
= Cadmium with Yellow Chromate
Z1
= Passivated Stainless Steel
G
= Supplied with EMI Ground Spring
N
= No Hardware (supplied with #8-32 tapped holes)
G
= Male Guide Pins
A
= .125 (3.18) Tail Length
Mating Hardware
N
No Hardware
#8-32 tapped hole
P
#4-40 Female
Jackposts
Shell
Contacts
Insulators
Potting
Compound
Face Seal and
O-ring
B
Female Guide
Bushings
G
Male Guide Pins
Hardware
MT
= Nickel-PTFE
Z2
= Gold
N
= No Ground Spring
P
= #4-40 Female Jackposts
B
= Female Guide Bushings
B
= .250 (6.35) Tail Length
Materials and Finishes
Aluminum alloy
Copper alloy, 50 microin.
gold plated
Thermoset epoxy
Epoxy
Fluorosilicone rubber
300 series stainless steel
Specifications
Current Rating
Test Voltage
Insulation
Resistance
Operating
Temperature
Ingress Protection
Shock
Vibration, Random
#22 5 AMPS, #20 7.5 AMPS
1000 VAC RMS
5000 megohms minimum
-65° C. to +200° C.
IP 67
300 g.
43.92 g.
B
280-024P
4S37
Z2
N
B
B
Shell Size - Contact Arrangements
Shell Size-
Contact Arr.
1S9
2S15
3S25
4S37
5S50
1H15
2H26
3H44
4H62
5H78
6H104
Contact Size and Qty
#20
9
15
25
37
50
High Density
15
26
44
62
78
104
#22
Standard Density
B-26
Rev. 09.04.02
© 2015 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 28 HiPer-D Catalog
Dimensions in Inches (millimeters) are subject to change without notice.
SERIES 28
HiPer-D
®
Standard and High-Density Connectors
280-024P right angle PC tail pin connectors with O-ring flange for
rear panel mounting
280-024P DIMENSIONS
.084±.002
(2.13±0.05)
A
H
C
D
4-40 UNC 2B TH'D
.150 (3.81) MIN. DEEP TYP 2PL
SEE PCB FOOTPRINTS
REF
R.134
(3.40)
B
E
B
G
F
10° TYP
.318
(8.07)
.262±.003
(6.65±0.08)
PC TAIL LENGTH
± .015 (3.81)
STD DENSITY SIZE #20HD CONTACTS
.030±.002(0.76±0.05)
HI DENSITY SIZE #22D CONTACTS
.020±.002(0.51±0.05)
4-40 UNC 2B TH'D
.150 (3.81) MIN. DEEP TYP 2PL
C
Shell
Size
1
2
3
4
5
6
± .015
1.865
2.200
2.736
3.385
3.289
in
A
± 0.38
47.37
55.88
69.49
85.98
83.54
mm
± .015
.725
.725
.725
.725
.837
in
B
± 0.38
18.42
18.42
18.42
18.42
21.26
mm
C Basic
in.
.984
1.312
1.852
2.500
2.406
mm
24.99
33.32
47.04
63.50
61.11
± .005
.726
1.054
1.594
2.242
2.139
in
D
± 0.13
18.44
26.77
40.49
56.95
54.33
mm
± .005
in
E
± 0.13
mm
F Basic
in
1.424
1.752
2.292
2.940
2.846
mm
36.17
44.50
58.22
74.68
72.29
± .015
in
G
± 0.38
mm
± .015
1.609
1.944
2.480
3.129
3.033
in
H
± 0.38
40.87
49.38
62.99
79.48
77.04
mm
.389
9.88
.389
9.88
.389
9.88
.389
9.88
.501 12.73
.563 14.30
.469 11.91
.469 11.91
.469 11.91
.469 11.91
.581 14.76
.643 16.33
3.383 85.93
.899 22.83
2.500 63.50
2.272 57.71
2.940 74.68
3.127 79.43
NOTES
1. Contacts are factory-installed, non-removable and are potted with epoxy.
2. HiPer-D® connectors are available with a wide variety of materials and finishes. See
About Series 28 HiPer-D® Shell Plating Options
for additional choices . Glenair offers the industry’s widest selection of plating and material choices with no setup charge, no
minimum order quantity and no schedule impact.
3. For panel cutout dimensions, refer to
Panel Cutouts and Printed Circuit Board Footprints.
4. For printed circuit board mounting dimensions, refer to
Panel Cutouts and Printed Circuit Board Footprints.
5. HiPer-D® connectors meet the requirements of MIL-DTL-24308 and are intermateable with standard M24308-type D-Subminiature
connectors with corresponding contact arrangements and type.
6. Additional electrical, mechanical and environmental specifications are listed in
HiPer-D® Product Specification.
© 2015 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 28 HiPer-D Catalog
Dimensions in Inches (millimeters) are subject to change without notice.
B-27
