YTT-120-01-G-5 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> YTT-120-01-G-5

YTT-120-01-G-5: DescriptionBoard Connector, 100 Contact(s), 5 Row(s), Male, Straight, 0.079 inch Pitch, Solder Terminal, Locking, Black Insulator, ROHS COMPLIANT; CategoryThe connector The connector; File Size434KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

YTT-120-01-G-5 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	YTT-120-01-G-5	-	-	View	Buy Now

YTT-120-01-G-5 Overview

Board Connector, 100 Contact(s), 5 Row(s), Male, Straight, 0.079 inch Pitch, Solder Terminal, Locking, Black Insulator, ROHS COMPLIANT

YTT-120-01-G-5 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1623905491
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Factory Lead Time	2 weeks
YTEOL	8.7
Other features	FLEXYZ
body width	0.395 inch
subject depth	0.079 inch
body length	1.58 inch
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (20) OVER NICKEL (50)
Contact completed and terminated	Gold (Au) - with Nickel (Ni) barrier
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
DIN compliance	NO
Filter function	NO
IEC compliance	NO
Insulator color	BLACK
insulator material	LIQUID CRYSTAL POLYMER
JESD-609 code	e4
MIL compliance	NO
Plug contact pitch	0.079 inch
Match contact row spacing	0.079 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	5
Number of rows loaded	5
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	2.0066 mm
Plating thickness	20u inch
Terminal length	0.097 inch
Terminal pitch	2 mm
Termination type	SOLDER
Total number of contacts	100

Preview

Download Datasheet

View All

F-218 SUPPLEMENT

YTT–110–01–G–Q

YTT–120–04–L–5

YTT–116–04–T–6

(2.00 mm) .0787"

YTT SERIES

HIGH-DENSITY TERMINAL STRIP

SPECIFICATIONS

For complete specifications

see www.samtec.com?YTT

Insulator Material:

Black Liquid Crystal

Polymer

Terminal Material:

Phosphor Bronze

Operating Temp Range:

-55 °C to +105 °C with Tin;

-55 °C to +125 °C with Gold

Plating:

Sn or Au over

50 µ" (1.27 µm) Ni

RoHS Compliant:

Yes

Lead–Free Solderable:

Wave only

Mates with:

YTQ, YTS, YTE

Choice of 4, 5 and 6

rows on (2.00 mm)

.0787" pitch

OTHER

SOLUTIONS

(2.00 mm)

.0787"

Paste In Hole (PIH) processing.

Contact Samtec ASP Group.

RECOGNITIONS

For complete scope of

recognitions see

www.samtec.com/quality

FILE NO. E111594

(2.00 mm)

.0787"

Through-hole

YTT

Note:

Some lengths, styles and

options are non-standard,

non-returnable.

NO. PINS

PER ROW

LEAD

STYLE

Specify

LEAD

STYLE

from

chart

PLATING

OPTION

ROW

OPTION

OTHER

OPTIONS

02 thru 50

LEAD

STYLE

–01

–04

= 20 µ" (0.51 µm)

Gold on

contact area,

Gold flash on tail

–G

= Four Row

–Q

–5

–6

–“XXX”

= Polarized

Position

Specify

position of

omitted pin

= Five Row
