YAGEO CORPORATION
SMD INDUCTOR / BEADS
Multilayer Ferrite
Chip Beads
SB/PB/NB/GB Series
[
SB Series for General Purpose / PB Series for Large Current
NB Series for Data Line, Digital Signals, etc. / GB Series for Medium Current
]
APPLICATIONS
Prevention of high frequency EMI form computers, printers, VCRs, TVs, wireless telephone
and other related equipment.
OUTLINE
PRODUCT IDENTIFICATION
SB
-
CLS Internal No.
Impedance and Tolerance
Packaging Style (*)
Design Code
Product Symbol
Chilisin ferrite chip EMI suppressers provide a powerful means of EMI/RFI attenuation for
electronic equipment. These products are highly produced with the use of magnetic
material and multilayered technology.
These components contain tremendous electrode strength, solder heat resistance and
outstanding solderability. These products are specially designed for flow, reflow and wave
soldering required for surface mounting application.
FEATURES
Unlike conventional beads, these beads do not require wiring: Simply mounts them onto
the PCB to eliminate the EMI/RFI.
Specially designed for surface mounting equipment, available in various size which allows
them to wide range of application and usage.
Best designed and tested to offer high impedance for volume.
SHAPES AND DIMENSIONS
Dimensions : mm
TYPE
Ferrite
Terminal Electrode
A
100505
1.0
±
0.15
1.6
±
0.20
2.0
±
0.20
3.2
±
0.20
3.2
±
0.20
3.2
±
0.20
4.5
±
0.25
4.5
±
0.25
B
0.50
±
0.15
0.80
±
0.15
1.25
±
0.20
1.60
±
0.20
1.60
±
0.20
2.50
±
0.20
1.60
±
0.20
3.20
±
0.20
C
0.5
±
0.15
0.8
±
0.15
0.9
±
0.20
1.1
±
0.20
1.6
±
0.20
1.3
±
0.20
1.6
±
0.20
1.5
±
0.20
D
0.25
±
0.15
0.4
±
0.2
0.5
±
0.3
0.5
±
0.3
0.5
±
0.3
0.5
±
0.3
0.5
±
0.3
0.5
±
0.3
SB/PB/NB
SB/PB/NB/GB 160808
SB/PB/NB/GB 201209
D
D
SB/PB/NB/GB 321611
SB/GB
C
321616
322513
451616
453215
SB/GB
A
B
SB/PB/GB
SB/PB/GB
