CR02AM-4

Description
LOW POWER USE PLANAR PASSIVATION TYPE
CategoryAnalog mixed-signal IC    Trigger device
File Size68KB,5 Pages
ManufacturerMitsubishi
Websitehttp://www.mitsubishielectric.com/semiconductors/
Download Datasheet Parametric Compare View All

CR02AM-4 Overview

LOW POWER USE PLANAR PASSIVATION TYPE

CR02AM-4 Parametric

Parameter NameAttribute value
MakerMitsubishi
Parts packaging codeTO-92
package instructionCYLINDRICAL, O-PBCY-W3
Contacts3
Reach Compliance Codeunknow
ECCN codeEAR99
ConfigurationSINGLE
Maximum DC gate trigger current0.1 mA
Maximum DC gate trigger voltage0.8 V
JEDEC-95 codeTO-92
JESD-30 codeO-PBCY-W3
Maximum leakage current0.1 mA
On-state non-repetitive peak current10 A
Number of components1
Number of terminals3
Maximum on-state current300 A
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeROUND
Package formCYLINDRICAL
Certification statusNot Qualified
Maximum rms on-state current0.47 A
Off-state repetitive peak voltage200 V
Repeated peak reverse voltage200 V
surface mountNO
Terminal formWIRE
Terminal locationBOTTOM
Trigger device typeSCR
MITSUBISHI SEMICONDUCTOR
〈THYRISTOR〉
CR02AM
LOW POWER USE
PLANAR PASSIVATION TYPE
CR02AM
OUTLINE DRAWING
φ5.0
MAX
4.4
Dimensions
in mm
2
VOLTAGE
CLASS
TYPE
NAME
3
1
12.5 MIN
1
CATHODE
2
ANODE
3
GATE
CIRCUMSCRIBE
CIRCLE
φ0.7
1.25 1.25
1.3
5.0 MAX
0.47
0.3
10
0.4
0.1
0.01
6
6
0.1
0.23
3 2 1
• I
T (AV)
........................................................................ 0.3A
• V
DRM
.................................................... 200V/300V/400V
• I
GT
......................................................................... 100µA
JEDEC : TO-92
APPLICATION
Solid state relay, leakage protector, fire alarm, timer, ringcounter, electric blankets, strobe flasher,
other general purpose control applications
MAXIMUM RATINGS
Symbol
V
RRM
V
RSM
V
R (DC)
V
DRM
V
D (DC)
Parameter
Repetitive peak reverse voltage
Non-repetitive peak reverse voltage
DC reverse voltage
Repetitive peak off-state voltage
DC off-state voltage
V1
V1
Voltage class
4
200
300
160
200
160
6
300
400
240
300
240
8
400
500
320
400
320
Symbol
I
T (RMS)
I
T (AV)
I
TSM
I
2t
P
GM
P
G (AV)
V
FGM
V
RGM
I
FGM
T
j
T
stg
Parameter
RMS on-state current
Average on-state current
Surge on-state current
I
2t
for fusing
Peak gate power dissipation
Average gate power dissipation
Peak gate forward voltage
Peak gate reverse voltage
Peak gate forward current
Junction temperature
Storage temperature
Weight
Typical value
Conditions
Commercial frequency, sine half wave, 180° conduction, T
a
=30°C
60Hz sine half wave 1 full cycle, peak value, non-repetitive
Value corresponding to 1 cycle of half wave 60Hz, surge on-state
current
Ratings
–40 ~ +125
–40 ~ +125
3.9 MAX
Unit
V
V
V
V
V
Unit
A
A
A
A
2
s
W
W
V
V
A
°C
°C
g
V1.
With Gate-to-cathode resistance R
GK
=1kΩ
Sep.2000
