ALUMINUM ELECTROLYTIC CAPACITORS
VR
Miniature Sized
series
Approved by Reliability Center for Electronic
Component, Japan-Certification No. RCJ-03-22C
VZ
High
Temperature
One rank smaller case sizes than VX series.
VR
Smaller
VK
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Performance Characteristics
– 40 ~ + 85˚C (6.3V ~ 400V), – 25˚C ~ + 85˚C (450V)
6.3 ~ 450V
0.1 ~ 33000µF
± 20% at 120Hz, 20˚C
Rated voltage
(
V)
Leakage Current
6.3
~
100V
After 1 minute's application of rated voltage, leakage current
is not more than 0.03CV or 4 (µA), whichever is greater.
After 2 minutes' application of rated voltage, leakage current
is not more than 0.01CV or 3 (µA), whichever is greater.
160
~
450V
After 1 minute's application of rated voltage,
CV < 1000
:1
=
0.1CV
+
40µA or less
=
After 1 minute's application of rated voltage,
CV > 1000
:1
=
0.04CV
+
100 (µA) or less
Measurement frequency : 120Hz, Temperature : 20˚C
tan
δ
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
Rated voltage
(
V)
6.3
10
16
25
35
tan
δ
(MAX.)
0.28
0.24
0.20
0.16
0.14
Rated voltage
(
V)
Impedance ratio
Z– 25˚C / Z
+
20˚C
ZT / Z20 (MAX.)
Z– 40˚C / Z
+
20˚C
50
0.12
50
2
3
63
2
3
63
0.10
100
2
3
100
0.08
160
~
315 350
~
450
0.20
0.25
400
6
10
450
15
Measurement frequency : 120Hz
Stability at Low Temperature
6.3
5
12
10
4
10
16
3
8
25
2
5
35
2
4
160
~
200 250
~
350
3
4
4
8
Endurance
After 2000 hours' application of rated voltage
at 85˚C,capacitors meet the characteristic
requirements listed at right.
Capacitance change
tan
δ
Leakage current
Within ±20% of initial value
200% or less of initial specified value
Initial specified value or less
Shelf Life
Marking
After leaving capacitors under no load at 85˚C for 1000 hours, they meet the specified value for
endurance characteristics listed above.
Printed with white color letter on black sleeve.
Radial Lead Type
Sleeve (P.E.T.)
φd
Type numbering system (Example : 10V 330
µ
F)
1
2
3
4
5
6
7
8
9 10 11 12
UVR 1 A 3 3 1 MED
MAX
Configuration
P
±0.5
φD
+
Capacitance tolerance (±20%)
Rated Capacitance (330µF)
Rated voltage (10V)
Pressure
relief vent
(φ6.3up)
L
+
MAX
Series name
15
MIN
4
MIN
Type
Configuration
φD
P
φd
4
1.5
0.45
0.5
5
2.0
0.5
0.5
6.3
2.5
0.5
0.5
8
3.5
0.6
0.5
10
5.0
0.6
0.5
12.5
5.0
0.6
0.5
16
7.5
0.8
0.5
18
7.5
0.8
0.5
20
10.0
1.0
0.5
22
10.0
1.0
1.0
25
12.5
1.0
1.0
φ
D
4
5
6.3
8 · 10
12.5 ~ 18
20 ~ 25
Pb free lead finishing
Pb free PET sleeve
Sn-Pb lead finishing
PVC sleeve contain Pb
DD6
DD
ED
PD
HD
RD
DA6
DA
EA
PA
HA
RA
(L 20) 1.5
(L 20) 2.0
Please contact to us if other configurations are required.
Please refer to page 19, 20, 21 about the formed or taped product spec.
Please refer to page 3 for the minimum order quantity.
Dimension table in next page.
