HMC687LP4
/
687LP4E
v04.0509
BiCMOS MMIC MIXER W/ INTEGRATED
LO AMPLIFIER, 1.7 - 2.2 GHz
Features
High input iP3: +35 dBm
8 dB Conversion Loss @ 0 dBm LO
Optimized for High side LO input
Upconversion & Downconversion Applications
Adjustable supply Current
24 Lead 4x4mm sMT Package: 16mm
2
Typical Applications
The HMC687LP4(e) is ideal for:
• Cellular/3G & LTe/WiMAx/4G
10
Mixers - siNGLe & DOUBLe BALANCeD - sMT
• Basestations & repeaters
• GsM, CDMA & OFDM
• Transmitters and receivers
Functional Diagram
General Description
The HMC687LP4(e) is a high dynamic range passive
MMiC mixer with integrated LO amplifier in a 4x4 sMT
QFN package covering 1.7 to 2.2 GHz. excellent input
iP3 performance of +35 dBm for down conversion is
provided for 3G & 4G GsM/CDMA applications at an
LO drive of 0 dBm. With an input 1 dB compression
of +23 dBm, the rF port will accept a wide range of
input signal levels. Conversion loss is 8 dB typical.
The DC to 500 MHz iF frequency response will sat-
isfy GsM/CDMA transmit or receive frequency plans.
The HMC687LP4(e) is optimized for high side LO
frequency plans and is pin for pin compatible with the
HMC685LP4(e) which is a 1.7 - 2.2 GHz converter
optimized for low side LO.
T
A
= +25° C, IF = 200 MHz, LO = 0 dBm, Vcc = Vcc1, 2, 3 = +5V, G_Bias = +2.5V*
Nominal supply
Parameter
Frequency range, rF
Frequency range, LO
Frequency range, iF
Conversion Loss
Noise Figure (ssB)
LO to rF isolation
LO to iF isolation
rF to iF isolation
iP3 (input)
1 dB Compression (input)
LO Drive input Level (Typical)
supply Current icc total
22
22
31
8
8
30
29
42
35
23
-3 to +3
120
145
Min.
icc = 120 mA
Typ.
Max.
1.7 - 2.2
1.7 - 2.4
DC - 500
10.5
8
8
32
29
42
34
22
-3 to +3
100
8
8
34
31
42
32
20
-3 to +3
70
icc = 100 mA
Typ.
icc = 70 mA
Typ.
Units
GHz
GHz
MHz
dB
dB
dB
dB
dB
dBm
dBm
dBm
mA
Electrical Specifications,
* Unless otherwise noted all measurements performed as downconverter with high side LO & IF = 200 MHz.
Information furnished by Analog Devices is believed to be accurate and reliable. However, no
For price, delivery, and to place orders: Analog Devices,
For price, delivery and to
for its use, nor for any infringements of patents or
Corporation, 20 Alpha Road, Chelmsford, MA 01824
Inc.,
responsibility is assumed by Analog Devices
place orders: Hittite Microwave
other
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106
rights of third parties that may result from its use. Specifications subject to change without notice. No
Phone: 978-250-3343
Fax: 978-250-3373
Order On-line at www.hittite.com
Phone: 781-329-4700 • Order online at www.analog.com
license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
Application Support: Phone: 1-800-ANALOG-D
Trademarks and registered trademarks are the property of their respective owners.
Application Support: Phone: 978-250-3343 or apps@hittite.com
10 - 1
