Accessory: Power supply/Output connection cable (2 m)
Included with the controller.
A
Mounting screws (M3 x 8L)
(Accessory)
Power supply/Output connection cable
ZS-26-A
Waterproof seal
(Accessory)
Panel mount adapter
Panel
Front protective cover + Panel mount
B
Front protective cover
Waterproof seal
(Accessory)
Mounting screws (M3 x 8L)
(Accessory)
Panel mount adapter
Panel
Option
When only optional parts are required, order with the part numbers listed below.
Description
Panel mount adapter
Front protective cover
Front protective cover +
Panel mount adapter
Part no.
ZS-26-B
ZS-26-01
ZS-26-C
ZS-26-D
Waterproof seal, screws included
48 conversion adapter
Note
Waterproof seal, screws included
48 conversion adapter
This adapter is used to
mount Series PSE200 on
the panel fitting of Series
PS100.
Order panel mount adapter separately.
Connector
ZS-26-E (4 pcs. per set)
16-3-6
Multi-channel Controller
Specifications
Model
Output specification
Power supply voltage
Current consumption
Power supply voltage for sensor
Power supply current for sensor
Sensor input
No. of inputs
Input protection
Hysteresis
Hysteresis mode
Window comparator mode
No. of outputs
Maximum load current
Switch output
Maximum load voltage
Residual voltage
Output protection
Response time
Anti-chattering function
Repeatability
Setting/Display accuracy
Display
Indication light
Auto shift input
Auto identification
Enclosure
Resistance
function
Note 2)
Note 1)
Series
PSE200
PSE200
PSE201
NPN open collector
PNP open collector
12 to 24 VDC
±10%,
Ripple (p-p) 10% or less (With power supply polarity protection)
55 mA or less (Current consumption for sensor is not included.)
[Power supply voltage] –1.5 V
40 mA maximum (100 mA maximum for the total power supply current when 4 sensors are input.)
1 to 5 VDC (Input impedance: Approx. 800 kΩ)
4 inputs
With excess voltage protection (Up to 26.4 V)
Variable
3-digit fixed
5 outputs (CH1: 2 outputs, CH2 to 4: 1 output)
80 mA
30 VDC (With NPN)
1 V or less (With load current of 80 mA)
With short circuit protection
5 ms or less
With anti-chattering function, Response time selection: 20 ms, 160 ms, 640 ms
±0.1%
F.S. or less
±0.5%
F.S.
±1
digit or less (at ambient temperature of 25°
±3°C)
For measured value display: 4-digit, 7-segment indicator, Display color: Yellow
For channel display: 1-digit, 7-segment indicator, Display color: Red
Red (Lights up when output is ON.)
Non-voltage input (Reed or Solid state), Input 10 ms or more, Independently controllable auto shift function ON/OFF
With auto identification function
Front face: IP65, Other: IP40
Operating: 0° to 50°C, Stored: –10° to 60°C (No freezing or condensation)
Operating/Stored: 35 to 85% RH (No condensation)
10 to 500 Hz at whichever is smaller of 1.5 mm amplitude or 98 m/s
2
acceleration, in X, Y, Z directions for 2 hrs. each (De-energized)
980 m/s
2
in X, Y, Z directions, 3 times each (De-energized)
±0.5%
F.S. or less based on 25°C
Power supply/Output connection: 8P connector, Sensor connection: 4P connector
Enclosure: PBT; Display: Transparent nylon; Back rubber cover: CR
Approx. 60 g (Power supply/output connecting cable not included)
ZSE
ISE
PSE
Z
I
SE3
PS
Z
I
SE
1
2
ZSP
ISA2
IS
ZSM
PF2
IF
Data
Ambient temperature range
Ambient humidity range
Vibration resistance
Impact resistance
Temperature characteristics
Connection
Material
Weight
Applicable pressure sensor
Regulating pressure range
kPa
MPa
Set pressure
resolution
Note 3)
PSE530
(F
or high pressure)
PSE531
(For vacuum)
PSE532
(F
or low pressure)
PSE533
(F
or compound pressure)
–0.1 to 1 MPa
—
0.001
0.01
0.01
0.1
—
10 to –101 kPa
0.1
—
0.001
0.001
0.01
1
–10 to 101 kPa
0.1
—
0.001
0.001
0.01
—
–101 to 101 kPa
0.1
—
0.001
0.001
0.02
1
kgf/cm
2
bar
psi
mmHg
—
0.1
—
0.1
InHg
Note 1) If the Vcc and 0 V side of the sensor input connector are short circuited, the inside of the controller will be damaged.
Note 2) Auto identification function comes with “Series PSE53 ” pressure sensor only. Other SMC series (PSE510 and PSE520) are not equipped with this
function.
Note 3) For controllers with unit display switching function. (Either of SI units, [kPa] or [MPa], will be the set unit for those controllers without unit switching
function.)
16-3-7
Series
PSE200
Dimensions
PSE200 & PSE201
40
6
MPa
kPa
40.1
6.5
18.7
Connector
(option)
OUT2
1
2
3
4
PRESSURE
SET
MADE IN JAPAN
ZZ
Sensor connector (4P x 4)
PIN no.
Terminal
DC (+)
IN (1 to 5 V)
DC (–)
N.C.
Power supply/Output connector (8P)
Power supply/Output connection cable (Included)
PIN no.
Terminal
DC (+)
DC (–)
CH1_OUT1
CH1_OUT2
CH2_OUT1
CH3_OUT1
CH4_OUT1
Auto shift input
Pin no.
8 Yellow : Auto shift input
7 Green : CH4_OUT1
6 Red
: CH3_OUT1
5 Gray : CH2_OUT1
4 White : CH1_OUT2
3 Black : CH1_OUT1
2 Blue : DC (–)
1 Brown : DC (+)
2000
16-3-8
4321
36.8
OUT1
CH
PSE200
Connector (Option)
Multi-channel Controller
Dimensions
Front protective cover + Panel mount
53
47
42.4
9.4
(2)
Series
PSE200
ZSE
ISE
MPa
kPa
PSE
46.4
Z
I
OUT1
OUT2
1
2
3
4
CH
SE3
PRESSURE
SET
PS
Panel mount adapter
Front protective cover
Waterproof seal
Panel
Z
I
SE
1
2
ZSP
ISA2
IS
ZSM
48 conversion adapter + Panel mount
48
6
2
1.5
MPa
kPa
PF2
IF
OUT1
OUT2
1
2
3
4
CH
PRESSURE
SET
Data
Panel mount adapter
Waterproof seal
48 conversion adapter
55 or more
+0.1
37.5
-0.2
Panel
55 or more
Panel fitting dimension
Applicable panel thickness: 0.5 to 8 mm
16-3-9
Series
PSE530/200
Descriptions
4-digit display
Displays
the
measured
pressure value, content for
each setting, and error code.
MPa
kPa
Unit display
The selected unit lights up. Use
unit labels for units other than
MPa and kPa.
Switch output display
Displays the output status of
OUT1 (CH1 to CH4), OUT2
(CH1 only).
Lights up when it is ON.
OUT1
OUT2
1
2
3
4
CH
Unit labels
kgf/cm
2
bar PSI inHg mmHg
Channel display
Displays the selected channel.
UP button
Use this button to change the
mode or set value.
PRESSURE
SET
DOWN button
Use this button to change the
mode or set value.
SET button
Use this button to set the mode
or set value.
Error Code & Solution
LED display
Contents
Excess current is
flowing into the
switch output of
OUT1.
Excess current is
flowing into the
switch output of
OUT2.
Pressure is applied
to a pressure sensor
during the reset
operation (a zero
point adjustment) as
follows:
When compound
pressure is used:
±
2.5% F.S. or more.
When pressure other
than compound
pressure is used:
±5%
F.S. or more.
∗
After displaying for
2 seconds, it will
return to the
measuring mode.
Internal Circuit and Connection
PSE200-(M)
• NPN open collector 5 outputs + Auto shift 1 input specification
DC (+) (Brown)
DC (+)
Sensor input: +1 to 5 VDC
DC (–)
N.C.
DC (+)
Sensor input: +1 to 5 VDC
DC (–)
N.C.
DC (+)
Sensor input: +1 to 5 VDC
DC (–)
Solution
Shut off the power
supply. After
eliminating the
output factor that
caused the excess
current, turn the
power supply back
on.
Load
Load
Load
1.2 k
7.3 k
Auto shift input (Yellow)
CH1_OUT1 (Black)
Main circuit
Load
Load
+12 to 24 VDC
CH1_OUT2 (White)
CH2_OUT1 (Gray)
CH3_OUT1 (Orange)
CH4_OUT1 (Pink)
+
–
Bring the pressure
back to atmospheric
pressure and use
the reset function
(zero point
adjustment) again.
N.C.
DC (+)
Sensor input: +1 to 5 VDC
DC (–)
N.C.
DC (–) (Blue)
PSE201-(M)
• PNP open collector 5 outputs + Auto shift 1 input specification
