Visible Radiant Optical Sensor /Data Sheet
TDK Visible Radiant Optical Sensor is the photo-IC which uses an amorphous
silicone semiconductor technology.
It
is the most suitable for Brightness
Adjustment, Control of the Lighting systems. BCS2015A1 has current-
amplifire in it. BCS2015A1 is for surface mounthing.
Features
• Highly receptive to visible light but not receptive to infrared light (close to
Human eye visibility).
• Accurate illumination measurement can be taken without the use of an
infrared filter.
( Phototransistors and photodiodes that use crystal- silicon semiconductors
typically require this filtering.)
• High output (Built-in current amplifire)
• Surface mounting can be used in lead- free reflow soldering.
• Lead- free, Cadmium-free
BCS2015A1
Application
• Brightness control for LCD, EL and CRT
• Brightness control for Keypads (e. g. Mobile Phones)
• Positioning scanline for Rear Projecton TV
• Exposure adjust for Compact Camera
• Sub exposure adjust for Digital Camera
Glass Substrate
BCS2015A1
Shapes and dimension
Equivalent circuit
+
(1.325)
Photo acceptance area
- Electrode
0.6
0.6
+ Electrode
Dimensions in [mm]
(0.55)
( ) : Typical value
(0.825)
(0.55)
t=0.6(typ.)
0.7(Max.)
1.5
1.2
2
0.5
_
Electrical Characterisic
Item
Output current
100Lux*1
Vop=5V
Operation voltage (Vop)
100Lux*1
Dark current
Vop=5V
Absolute Maximum Ratings
Operation voltage
Reverse voltage
Output current
Optical Characteristic
Spectral sensivty area
Peak of sensivity
Others
Operating temperature
Keep and transfer temperature
Dimensions
Weight
*1 White Fluor Light (color temperature=4200K)
Item
Item
Item
Units
μA
V
nA
Value
Min.
Typ.
6.0
8.0
1.2
---
---
---
Value
Temperature= 25deg.C
Max.
10.0
5.0
10
*Initial value
Temperature= 25deg.C
Units
V
V
mA
8
-1
1
Value
Temperature= 25deg.C
Units
nm
nm
350 to 750
580±20
Value
-20 to 85
-40 to 85
2.0×1.5×0.6t
0.004
51101
Units
deg. C
deg. C
mm
g
*All specifications are subject to change without notice.
