HOME PHONE NETWORKING
BANDPASS FILTER
Approved by Agere Systems for use with Agere's HomeWire
™
Chipsets
HW3000/HW2000, HW3100/HW2000, and HW3130/HW2000
Includes isolation and EMI filtering
Designed to withstand 235°C peak infrared reflow temperature
Electrical Specifications @ 25°C — Operating Temperature -40°C to +125°C
10M8 PARAMETERS
Insertion Loss
4.75 MHz to 9.25 MHz
Attenuation
1.0 MHz
22.0 MHz
54.0 MHz
Frequency Response (Ripple)
4.75 MHz to 6.25 MHz
8.0 MHz to 9.25 MHz
Return Loss
4.75 MHz to 9.25 MHz
Common to Differential Mode Rejection
4 MHz to 10 MHz
20 MHz
50 MHz
100 MHz
Isolation
MIN
1.2 dB
60 dB
35 dB
50 dB
0.7 dB
0.7 dB
12.0 dB
50 dB
40 dB
40 dB
30 dB
2000 Vrms
MAX
2.2 dB
Mechanical
B6017
.945
24.00
.590 .750
14,99 19,05
.725
18,42
.100
2,54
Schematic
.580
14,73
10MB+ 6
10 MBS
Bandpass
Filter
10MB- 7
GND 8
2 kV
12 RING (-)
B6017
COUNTRY OF ORIGIN
DATE CODE (REV)
.040
18X
1,02
.800
20.32
SUGGESTED PAD LAYOUT
18X 0° 8°
.100
2,54
.018
18X
0,46
.800
20.32
11 TIP (+)
.285
7,24
.007
0,18
.004/0,10
18 SURFACES
20X
.035
0,89
Weight
. . . . . . . . . . . . . .4.5 grams
Tape & Reel
. . . . . . . . . . . .250/reel
Tube
. . . . . . . . . . . . . . . . . .30/tube
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .010
0,25
