Corcom Product Guide
AC Feedthrough Capacitors – Class Y2
Catalog: 1654001
Issue Date: 08.2010
AFC Series
Component Recognized by
UL to US and Canadian Requirements
AFC Series
• AC feedthrough capacitors
• Current ratings from 10 to 300A
• Designed to meet the very stringent safety
requirements of EN132400 class Y2 including
the 5000V pulse test
• Custom versions available
Specifications
Rated Voltage (max):
Rated Frequency:
Rated Current:
Test Voltage (two seconds):
Capacitor Class (EN132400):
Pulse Test (EN132400):
250 VAC
50/60 Hz
10 to 300A
5000 VDC
Designed to meet Y2
5000V Peak
Ordering Information
10 AFC6 – A
Filter ID
See Table
AFC Series Screw Terminals
Current Rating
(in A)
Insulation Resistance (within 1 minute):
For C < 0.33µF, R> 15000MΩ
For C > 0.33µF, RC(MΩ*µF)>5000s
Operating Ambient Temperature Range
(at rated current Ir):
10 to 200A: -40°C to +60°C
250 & 300A: -40°C to +40°C
Category Temperature Range:
Current Derating Above Ambient:
10-200A: For temperature,
θ Iθ
=
IR
√(85-
θ
)/25
250 & 300A: For temp.,
θ Iθ
=
IR
√(85-
θ
)/45
Climatic Category:
MTBF:
40/85/21
> 10 million hours typical
UL94V-0
-40°C to +85°C
Filter Options / Specifications
Filter ID
A
B
C
F
G
H
K
N
P
Value (nF)
2.2
4.7
10
33
47
100
220
470
1000
Max. Leakage
Current (mA)*
0.21
0.44
0.94
3.1
4.4
9.4
21
44
94
*@250VAC 60 Hz
Insulating Materials Flammability Rating:
Case & Terminal Material:
Nickel Plated Brass
234
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
tycoelectronics.com/help
corcom.com
Corcom Product Guide
AC Feedthrough Capacitors – Class Y2
(continued)
Catalog: 1654001
Issue Date: 08.2010
AFC Series
Case Style
Resin Fill
T1 (Terminal thread)
T2 (Mounting thread)
Case Dimensions
A
Part No.
10AFC6-A
10AFC6-B
± .04
1
B
± .02
0.5
C
± .08
2
D
± .04
1
E
± .08
2
F
(max)
B
C
D
E
F
16AFC6-B
16AFC6-C
16AFC6-G
A
T1 – Terminal Thread
Part No.
10AFC6-A/B
16AFC6-B/C/G/H
20AFC6-B
32AFC6-B/C/F/G/H
63AFC6-C/G/H
100AFC6-G/H/K/N
200AFC6-H/K/N/P
250AFC6-H/K/N/P
300AFC6-H/K/N/P
Thread
M3
M4
M6
M8
M10
M12
M16
Torque
max. in.lb.
4
11
22
44
71
97
177
16AFC6-H
20AFC6-B
32AFC6-B
32AFC6-C
32AFC6-F
32AFC6-G
32AFC6-H
63AFC6-C
63AFC6-G
63AFC6-H
T2 – Mounting Thread
Part No.
10AFC6-A/B
16AFC6-B/C/G
20AFC6-B
32AFC6-B/C/G/F
16AFC6-H
32AFC6-H
63AFC6-C/G/H
100AFC6-G/H
100AFC6-K/N
200AFC6-H/K
200AFC6-N/P
Thread
M10 x 1
100AFC6-G
100AFC6-H
Torque
max. in.lb.
27
100AFC6-K
200AFC6-H
200AFC6-K
200AFC6-N
200AFC6-P
250AFC6-H
250AFC6-K
M12 x 1
35
M16 x 1
62
250AFC6-N
250AFC6-P
300AFC6-H
300AFC6-K
300AFC6-N
300AFC6-P
M20 x 1
89
M24 x 1
124
2.24
57
2.48
63
2.95
75
3.03
77
2.48
63
2.48
63
2.95
75
3.03
77
3.78
96
3.78
96
4.45
113
4.57
116
5.24
133
5.12
130
5.79
147
5.83
148
6.30
160
5.83
148
0.59
15
0.79
20
0.79
20
0.98
25
0.79
20
0.79
20
0.79
20
0.98
25
0.98
25
0.98
25
1.26
32
1.50
38
1.50
38
1.50
38
2.13
54
2.13
54
2.13
54
2.13
54
0.71
18
0.71
18
1.18
30
1.18
30
0.71
18
0.71
18
1.18
30
1.18
30
1.18
30
1.18
30
1.30
33
1.30
33
1.97
50
1.30
33
1.97
50
1.65
42
2.13
54
1.65
42
0.39
10
0.47
12
0.47
12
0.55
14
0.47
12
0.47
12
0.47
12
0.55
14
0.55
14
0.55
14
0.63
16
0.75
19
0.75
19
0.75
19
0.75
19
0.75
19
0.75
19
0.75
19
0.63
16
0.71
18
0.71
18
0.71
18
0.71
18
0.71
18
0.71
18
0.71
18
1.02
26
1.02
26
1.26
32
1.26
32
1.26
32
1.57
40
1.57
40
1.81
46
1.81
46
1.81
46
0.51
13
0.67
17
0.67
17
0.87
22
0.67
17
0.67
17
0.67
17
0.87
22
0.87
22
0.87
22
1.06
27
1.06
27
1.06
27
1.06
27
1.57
40
1.57
40
1.57
40
1.57
40
5
Feedthrough Filters and Capacitors
M27 x 1.5
142
235
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
tycoelectronics.com/help
corcom.com
Corcom Product Guide
AC Feedthrough Capacitors – Class Y2
(continued)
Catalog: 1654001
Issue Date: 08.2010
AFC Series
Available Part Numbers
10AFC6-A
10AFC6-B
16AFC6-B
16AFC6-C
16AFC6-G
16AFC6-H
20AFC6-B
32AFC6-B
32AFC6-C
32AFC6-F
32AFC6-G
32AFC6-H
63AFC6-C
63AFC6-G
63AFC6-H
100AFC6-H
100AFC6-H
100AFC6-K
100AFC6-N
200AFC6-H
200AFC6-K
200AFC6-N
200AFC6-P
250AFC6-H
250AFC6-K
250AFC6-N
250AFC6-P
300AFC6-H
300AFC6-K
300AFC6-N
300AFC6-P
Performance Data
Typical Insertion Loss
Filter
ID
A
B
C
F
G
H
K
N
P
0.01
-
-
-
-
-
-
-
6
10
— Line to Ground in 50 Ohm circuit
Frequency – MHz
0.3
1
-
-
-
-
-
3
4
12
6
15
11
20
18
27
22
33
30
40
0.03
-
-
-
-
-
2
4
9
15
0.1
-
-
-
-
2
5
11
16
22
10
8
14
21
30
34
40
45
33
42
100
38
43
45
48
50
65
85
90
90
1000
45
60
70
90
90
90
90
90
90
236
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
tycoelectronics.com/help
corcom.com
