HV9113P Overview

Switching converters, voltage regulators and controllers hvcmos 120v 1% ref

HV9113P Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Supertex
Parts packaging code	DIP
package instruction	DIP, DIP14,.3
Contacts	14
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	120 V
Minimum input voltage	10 V
Nominal input voltage	48 V
JESD-30 code	R-PDIP-T14
JESD-609 code	e0
length	19.304 mm
Number of functions	1
Number of terminals	14
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	0.01 A
Nominal output voltage	4 V
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP14,.3
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	4.318 mm
Maximum supply current (Isup)	1 mA
surface mount	NO
Switch configuration	SINGLE
Maximum switching frequency	3000 kHz
technology	BICMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.62 mm

Preview

Download Datasheet

View All

HV9113

High-Voltage Current-Mode PWM Controller

Features

►

10 to 120V input voltage range

Current-mode control

High efﬁciency

Up to 1.0MHz internal oscillator

Internal start-up circuit

Low internal noise

99% maximum duty cycle

General Description

The Supertex HV9113 is a BiCMOS/DMOS single-output,

pulse width modulator IC intended for use in high-speed,

high-efﬁciency switch mode power supplies. It provides all the

functions necessary to implement a single-switch current mode

PWM, in any topology, with a minimum of external parts.

Because the HV9113 utilizes Supertex’s proprietary BiCMOS/

DMOS technology, it requires less than one tenth of the operating

power of conventional bipolar PWM ICs, and can operate at

more than twice their switching frequency. The dynamic range

for regulation is also increased, to approximately 8 times that

of similar bipolar parts. It starts directly from any DC input

voltage between 10 and 120VDC, requiring no external power

resistor. The output stage is push-pull CMOS and thus requires

no clamping diodes for protection, even when signiﬁcant lead

length exists between the output and the external MOSFET. The

clock frequency is set with a single external resistor.

Accessory functions are included to permit fast remote shutdown

(latching or nonlatching) and under voltage shutdown.

For similar ICs intended to operate directly from up to 450VDC

input, please consult the data sheets for the HV9120 and

HV9123.

For detailed circuit and application information, please refer to

application notes AN-H13 and AN-H21 to AN-H24.

Applications

►

DC/DC converters

Distributed power systems

ISDN equipment

PBX systems

Modems

Functional Block Diagram

COMP

DISCHARGE

OSC

OUT

Error

Amplifier

–

OSC

VREF

–

Modulator

Comparator

To VDD

REF

GEN

–

Current Limit

Comparator

OUTPUT

-VIN

BIAS

VDD

+VIN

Current

Sources

Internal

Circuits

1.2V

VDD

SENSE

–

8.1V

8.6V

Undervoltage

Comparator

SHUTDOWN

RESET

Pre-regulator/Startup

●

1235 Bordeaux Drive, Sunnyvale, CA 94089

●

Tel: 408-222-8888

●

www.supertex.com
