HFI 120
H-N xxxx
H-NM xxx
Key features:
LSZH, flame retardant cores
Discontinued product:
600V/120
o
C
Voltage rating:
600/1000V
Test voltage:
3000V
Temperature range:
-40
o
C / +120
o
C
Flame retardant
Low Smoke Zero Halogen (LSZH)
RoHS Compliant
Also referred to as:
N xxxx
NM xxxx
Habia Cable regretfully notifies its customers of the discontinuation of our HFI 120 compound and its
associated products. This applies to all new designs with immediate effect. The change-over process for
existing designs will be slower and our sales engineers will be pleased to discuss the options for replacement
products with our customers on a case-by-case basis.
2
Equipment Wires
Wire construction:
Conductor: H-N xxxx:
H-NM xxx:
Insulation: Extruded HFI 120
Tin Plated Copper (TPC), AWG sizes
Tin Plated Copper (TPC), Metric sizes
Order reference (550ccZZZZ):
Prefix: 550 + colour code: cc
(e.g. 00, see below)
+ size: ZZZZ
(e.g. 3007, see table)
00
Black
11
Brown
22
Red
33
Orange
44
Yellow
55
Green
66
Blue
77
Violet
88
Grey
99
White
29
Pink
45
Yw/Gn
Size
Description
H-N 3007
H-N 2807
H-N 2619
H-N 2419
H-N 2219
H-NM 0,5
H-N 2019
H-NM 0,75
H-N 1819
H-NM 1,0
H-N 1619
H-NM 1,5
H-N 1419
H-NM 2,5
H-N 1237
AWG
30
28
26
24
22
-
20
-
18
-
16
-
14
-
12
CSA
mm
2
0,06
0,09
0,16
0,24
0,38
0,50
0,60
0,75
0,96
1,00
1,23
1,50
1,87
2,50
2,98
stranding
7 x 0,10
7 x 0,13
19 x 0,10
19 x 0,13
19 x 0,16
16 x 0,20
19 x 0,20
24 x 0,20
19 x 0,25
32 x 0,20
19 x 0,29
30 x 0,25
19 x 0,36
50 x 0,25
37 x 0,32
Conductor
resistance
Ω/km
354,30
223,80
131,60
83,30
52,20
40,10
32,00
26,70
20,40
20,00
15,80
13,70
10,00
8,21
2,20
wire Ø
0,30
0,38
0,48
0,60
0,76
0,88
0,96
1,05
1,21
1,20
1,36
1,52
1,70
2,00
2,20
core Ø
0,70
0,78
0,88
1,00
1,16
1,28
1,36
1,45
1,60
1,60
1,86
2,00
2,21
2,45
2,74
Finished Wire
tolerance
±0,07
±0,07
±0,07
±0,07
±0,07
±0,07
±0,07
±0,10
±0,10
±0,10
±0,10
±0,10
±0,10
±0,10
±0,10
weight
g/m
0,9
1,2
1,9
2,7
4,0
5,2
6,2
7,5
9,5
9,5
12,0
14,8
18,5
24,0
29,0
Electrical
amps at 40
o
C
3
4
5
7
10
12
13
15
18
18
22
25
30
35
41
Order reference
550cc3007
550cc2807
550cc2619
550cc2419
550cc2219
550cc0050
550cc2019
550cc0075
550cc1819
550cc0100
550cc1619
550cc0150
550cc1419
550cc0250
550cc1237
De-rating Factors for Current Rating
Temperature de-rating (
o
C)
Multicore de-rating factor
10
1.22
2
1.00
20
1.15
3
0.88
30
1.08
4
0.80
40
1.00
6
0.69
50
0.92
8
0.62
60
0.84
10
0.59
70
0.75
12
0.55
80
0.65
16
0.51
90
0.54
20
0.48
100
0.42
24
0.43
110
0.28
28
0.41
-
-
32
0.39
-
-
36
0.38
-
-
40
0.36
Note:
All dimensions in mm and ±4% unless stated
Date:
2011-01-27
Created:
CJV
Approved: TN
Reference:
EQ_N_11
Data provided indicates nominal values unless stated otherwise and is only valid for reference purposes at the time of publication and is subject to change without prior notice.
www.habia.com
world class cable solutions
