MC Power Series
BOOSTCAP
®
Ultracapacitors
p
>
Series: MC Power
Round, Terminal Type
Ultra low internal resistance
Ultra low internal resistance
Highest power performance available
Highest power performance available
Lowest RC time constant
Lowest RC time constant
Features:
» 2.7 Volt Operating Voltage
» Ultra low internal resistance
» Over 1 million duty cycles
» Highest power performance available
» Lowest RC time constant
» Threaded terminal or weldable post versions
>
Applications:
» Hybrid drive trains
» Automotive subsystems
» Transportation
» Rail system power
>
Overview:
The Power-type ultracapacitor product line gives customers in the automotive and transportation sector a
much wider range of choices to meet their energy storage and power delivery requirements.
The cells are specifically engineered for hybrid vehicle drive trains, automotive subsystems and other heavy
duty applications that require the lowest equivalent series resistance (ESR) and highest efficiency avail-
able.
In addition to meeting or exceeding demanding automotive and transportation application requirements for
both watt-hours of energy storage and watts of power delivery per kilogram, all of these products will per-
form reliably for more than one million discharge-recharge cycles.
The proprietary architecture and material science on which BOOSTCAP® products are based enable contin-
ued leadership in controlling costs, flexibility in product offerings and allow application specific performance
tailoring. The cells operate at 2.7 volts, enabling them to store more energy and deliver more power per unit
volume than any other commercially available ultracapacitor products.
*Beginning January 1, 2007, the BCAP2600 will be replaced by the BCAP3000.
We will not be accepting orders after November 15, 2006 for BCAP2600 Cells.
Please contact Maxwell technologies for more information.
MC Power Series
BOOSTCAP
®
Ultracapacitors
|
Page 1
| Doc. # 1009361 | Rev. 4 |
MC Power Series
BOOSTCAP
®
Ultracapacitors
>
MC Power Series Specifications:
Item
Operating Temperature Range
Storage Temperature Range
Rated Voltage
Capacitance Tolerance
Resistance Tolerance
Temperature Characteristics
Capacitance Change
Internal Resistance
Capacitance Change
Internal Resistance
Shelf Life
Performance
-40 °C to +65 °C
-40 °C to +70 °C
2.7 V DC
+20% / -5%
Max.
Within ± 5% of initial measured value at 25 °C ( at -40 °C)
Within 150% of initial measured value at 25 °C (at -40 °C)
Within 20% of initial specified value
Within 60% of initial specified value
After 1500 hours application of rated voltage at 65 °C
Endurance
After 1500 hours storage at 65 °C without load shall meet specification for endurance
After 10 years at rated voltage and 25 °C
Capacitance Change
Internal Resistance
Within 30% of initial specified value
Within 150% of initial specified value
Life Test
Cycle Test
Capacitors cycled between specified voltage and half rated voltage under constant
current at 25 °C (1 million)
Capacitance Change
Internal Resistance
Within 30% of initial specified value
Within 150% of initial specified value
>
MC Power Product Specifications:
Part Number
BCAP0650 P270
BCAP1200 P270
BCAP1500 P270
BCAP2000 P270
BCAP2600 P270*
BCAP3000 P270
Capacitance
(F)
650
1200
1500
2000
2600
3000
ESR, DC
(mohm)
0.80
0.58
0.47
0.35
0.31
0.29
ESR, 1khz
(mohm)
0.60
0.44
0.35
0.26
0.23
0.24
Ic
(mA)
1.5
2.7
3.0
4.2
5.2
5.2
*Beginning January 1, 2007, the BCAP2600 will be replaced by the BCAP3000.
We will not be accepting orders after November 15, 2006 for BCAP2600 Cells.
Please contact Maxwell technologies for more information.
Rth
(C/W)
6.5
5.3
4.5
3.8
3.0
3.2
Isc
(A)
3500
3750
3900
4300
4800
4800
Emax
(Wh/kg)
3.29
4.05
4.75
5.06
5.72
5.52
Pmax
(W/kg)
15,100
13,800
16,200
17,500
17,200
13,800
>
MC Power Product Properties:
Maxwell Part No.
BCAP0650 P270
BCAP1200 P270
BCAP1500 P270
BCAP2000 P270
BCAP2600 P270*
BCAP3000 P270
Pd
(W/kg)
5,400
5,000
5,800
6,200
6,100
5,400
|
Page 2
| Doc. # 1009361 | Rev. 4 |
MC Power Series
BOOSTCAP
®
Ultracapacitors
MC Power Series
BOOSTCAP
®
Ultracapacitors
>
Dimensions:
Post Version
Part Number
BCAP0650 P270 T04
BCAP1200 P270 T04
BCAP1500 P270 T04
BCAP2000 P270 T04
BCAP2600 P270 T04
BCAP3000 P270 T04
Vol
(I)
0.211
0.294
0.325
0.373
0.439
0.475
Mass
(kg)
0.20
0.30
0.32
0.40
0.46
0.55
Size (mm)
L
44.5
74.0
85.0
102.0
138.0
138.0
H
14.0
14.0
14.0
14.0
14.0
14.0
D
60.0
60.0
60.0
60.0
57.7
60.0
Product dimensions and specifications may change without notice. Please contact Maxwell Technologies
directly for any technical specifications critical to application.
>
Mounting Recommendations:
Do not reverse polarity.
Maximum torque for M12 screw terminals are 10Nm.
Cells are designed to be connected into series or parallel strings.
Clean terminals before mounting.
Worldwide Headquarters
MAxweLL TeCHnOLOgies
9244 Balboa Avenue • san Diego, 92123 CA, UsA
PHOne:
+(1) 858 503 3300
FAx:
+(1) 858 503 3301
eMAiL:
info@maxwell.com
European Office
MAxweLL TeCHnOLOgies sA
CH-1728 Rossens • switzerland
PHOne:
+41 (0) 26 411 85 00
FAx:
+41 (0) 26 411 85 05
eMAiL:
info@maxwell.com
www.maxwell.com
|
Page 3
| Doc. # 1009361 | Rev. 4 |
MC Power Series
BOOSTCAP
®
Ultracapacitors
MC Power Series
BOOSTCAP
®
Ultracapacitors
>
Dimensions:
Weldable Version
Part Number
BCAP0650 P270 T05
BCAP1200 P270 T05
BCAP1500 P270 T05
BCAP2000 P270 T05
BCAP2600 P270 T05
BCAP3000 P270 T05
Vol
(I)
0.150
0.233
0.264
0.312
0.383
0.414
Mass
(kg)
0.20
0.30
0.32
0.40
0.46
0.55
Size (mm)
L
44.5
74.0
85.0
102.0
138.0
138.0
H
3.20
3.20
3.20
3.20
3.20
3.20
D
60.0
60.0
60.0
60.0
57.7
60.0
d
2
14.0
14.0
14.0
14.0
14.0
14.0
Product dimensions and specifications may change without notice. Please contact Maxwell Technologies
directly for any technical specifications critical to application.
>
Markings:
Capacitors are marked with the following information - Rated capacitance and rated voltage as well as
energy/power type indication in the product naming. serial number, name of manufacturer, positive and
negative terminal, warning marking.
>
Additional Technical Information:
Capacitance and esR, DC measured per document 1007239
ic= Leakage current after 72 hours, 25˚C
Rth = Thermal resistance
e
max
=
½
CV
2
3600 x
mass
lsc = short circuit current (maximum peak current)
0.12V
2
P
d
=
R (DC)
mass
V
2
P
max
=
4R
(1khz)
mass
Patent Pending
European Office
MAxweLL TeCHnOLOgies sA
CH-1728 Rossens • switzerland
PHOne:
+41 (0) 26 411 85 00
FAx:
+41 (0) 26 411 85 05
eMAiL:
info@maxwell.com
Worldwide Headquarters
MAxweLL TeCHnOLOgies
9244 Balboa Avenue • san Diego, 92123 CA, UsA
PHOne:
+(1) 858 503 3300
FAx:
+(1) 858 503 3301
eMAiL:
info@maxwell.com
www.maxwell.com
|
Page 4
| Doc. # 1009361 | Rev. 4 |
MC Power Series
BOOSTCAP
®
Ultracapacitors
MC Power Series
BOOSTCAP
®
Ultracapacitors
Disclaimer of Warranty/Limitation of Liability
for Uses in Life Support Devices or Critical Systems
Maxwell Technologies, Inc. and its Affiliates (“Maxwell”) provide no warranties of any kind either express or implied, including (without
limitation) the implied warranties of merchantability and fitness, for uses of its products as components in life support devices or critical
systems.
“Life support devices” are devices or systems, which (a) are intended for surgical implant into a living body, or (b) support or sustain life,
and whose failure to perform when properly used in accordance with the instructions provided in the labeling can be reasonably expected to
result in bodily injury to the user. An example of a life support device includes, but is not limited to, a heart pacemaker.
A “critical system” is any system whose failure to perform can affect the safety or effectiveness of a higher level system, or cause bodily or
property injury by loss of control of the higher level device or system. An example of a critical system includes, but is not limited to, aircraft
avionics.
Maxwell will not be liable to you for any loss or damages, either actual or consequential, indirect, punitive, special, or incidental, arising out
of or relating to these terms.
