Part Number

Search

36501E5N6J

Description
1 ELEMENT, 0.0056uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0402, ROHS COMPLIANT
CategoryPassive components    inductor
File Size112KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

36501E5N6J Overview

1 ELEMENT, 0.0056uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0402, ROHS COMPLIANT

36501E5N6J Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
package instruction0402
Reach Compliance Codecompliant
ECCN codeEAR99
Factory Lead Time26 weeks
uppercase and lowercase codes0402
DC Resistance0.083 Ω
Nominal inductance(L)0.0056 µH
Inductor ApplicationsRF INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
Manufacturer's serial number3650
Number of functions1
Number of terminals2
Minimum quality factor (at nominal inductance)20
Maximum rated current0.76 A
self resonant frequency5800 MHz
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldNO
surface mountYES
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Test frequency250 MHz
Tolerance5%
Base Number Matches1
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Passive C omponents
>
Product Feature Selector
> Product Details
36501E5N6J Product Details
Live Product Chat
Inductors
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
36501E5N6J
(3-1624112-0)
T E I nternal N umber: 3 - 1 6 2 4 1 1 2 - 0
Product Highlights:
l
Inductor
l
Inductor Type = High Frequency
l
Lead Type = Surface Mount Terminals
l
Wirewound
l
Inductance = .0056 ?H
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
LOW INDUC TANC E, HIGH FREQUENC Y C HIP INDUC TOR SERIES 3650
(PDF, English)
Catalog Pages/Data Sheets:
l
Low Inductance, High Frequency C hip Inductors - Type...
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Inductor
l
Inductor Type = High Frequency
l
Element
= Wirewound
l
Shielded
= No
Electrical Characteristics:
l
Inductance (?H)
= 0.0056
l
DC Resistance (?)
= 0.083
l
C urrent, Maximum (mA)
= 760
l
Quality Factor
= 20
l
Package Type
= Taped and Reeled
l
Tolerance (%) = 5
Body Related Features:
l
Lead Type
= Surface Mount Terminals
l
Series
= 3650
l
Packaging Style
= 0402
l
Package, C omponent Size
= 1.5 x 0.5
l
Mount Style
= Surface Mount
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Reflow solder capable to 245?C ,
Reflow solder capable to 260?C
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Operation/Application:
l
Application
= High Frequency
Other:
l
Brand = Sigma Inductors
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved
