SPECIFICATIONS
Shield material:
Housing material:
Contact material:
Contact plating:
Stainless steel
Thermoplastic, UL94V-0
Phosphor bronze
Gold over nickel
A
B
B
C
C
D
D
Optional panel latch
E
PL=With latch
NPL=No latch
Series
CTL
Modular Jack
Coupler
Position
X
6,8,10
Contacts
XX
02, 04, 06, 08, 10
Type
018
Type=018
F
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
Color
XX
BK=Black
YL=Yellow
WT=White RD=Red
IV=Ivory
GN=Green
GY=Grey
BL=Blue
Plating
PX
P0=6u”
P1=15u”
P2=30u”
P3=50u”
Options
XX
Blank=None
NL=No Latch
FS=Full Shield (bk only)
5E=Cat 5E
6E=Cat 5E
E
F
G
Date
08/10/99
08/10/99
08/10/99 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
CTL-8-08-018-XX-PX-FS
7
8
9
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Modular coupler jack, 8P8C, shielded, optional panel
