Metallized Polyester
Film Capacitors
F
EATURES
•
•
•
TMPE & FMPE
Series
(Axial Lead)
MERITEK
•
Non-inductive construction
Good solderability
Self-healing properties
High stability of capacitance
S
PECIFICATIONS
1. Operating temperature:
2. Capacitance range:
3. Capacitance tolerance:
4. Rated voltage:
5. Dissipation factor:
6. Insulation resistance:
-40
o
C to +85
o
C
0.01μF to 12μF
±5%(J), ±10%(K), ±20%(M)
100VDC, 250VDC, 400VDC, 630VDC
1.0% max. at 1KHz, 25
o
C
>30000MΩ (C
≤
0.33μF)
>10000MΩ •
μF
(C > 0.33
μF)
are constructed with
metallized polyester film dielectric, tinned copper
leads, polyester film tape outer wrapping, and
non-inductive epoxy resin end seals. They are ideal
for coupling and decoupling, bypassing, filtering,
and other applications. TMPE and FMPE are
frequently used in data processing equipment,
automatic
control
systems,
devices
for
telecommunication and industrial instruments.
MIN
35mm
MAX
L
MIN
35mm
MAX
OD
TMPE
&
FMPE
P
ART
N
UMBERING
S
YSTEM
Meritek Series
* TMPE / FMPE
Capacitance
CODE
( pF )
( nF )
(
μF
)
101
100
---
---
102
1,000
1
0.001
103
10,000
10
0.01
104
100,000
100
0.1
TMPE
223
J
2A
105
1000
1
106
10
Tolerance
CODE
Tolerance (%)
J
±5
K
± 10
M
± 20
d
d
2E
250V
2G
400V
2J
630V
35mm
W
2
35mm
0.05
MAX
H
T
MAX
Rated Voltage
CODE
2A
100V
Tape & Reel / Tape & Ammo available for diameter 10mm or smaller
Please contact factory for part numbers
Dimensions in millimeters (mm)
FMPE
400VDC
630VDC
L
15.0
15.0
15.0
15.0
15.0
21.0
21.0
21.0
26.0
26.0
26.0
33.0
33.0
33.0
37.0
37.0
ØD
6.0
6.5
7.0
9.0
7.5
8.5
11.0
10.5
14.0
12.0
14.0
16.5
20.0
25.0
23.0
L
15.0
15.0
15.0
15.0
21.0
21.0
21.0
26.0
26.0
33.0
33.0
33.0
37.0
37.0
47.0
W
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
21.0
21.0
21.0
26.0
26.0
26.0
33.0
33.0
33.0
100VDC
H
9.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
11.0
10.0
11.0
12.5
12.0
16.0
18.5
18.5
23.0
26.5
T
5.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
7.0
7.0
9.0
11.0
9.0
13.0
16.0
W
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
21.0
21.0
21.0
26.0
26.0
26.0
33.0
33.0
38.0
38.0
47.0
250VDC
H
9.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
8.5
10.0
11.0
11.0
14.0
16.0
18.0
20.0
25.0
27.0
30.0
T
5.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
5.0
5.0
7.0
7.0
8.0
9.0
9.5
11.0
16.0
19.0
22.0
W
15.0
15.0
15.0
15.0
15.0
15.0
21.0
21.0
21.0
26.0
26.0
33.0
33.0
33.0
38.0
38.0
38.0
400VDC
H
9.0
10.0
9.0
10.0
10.0
10.0
11.0
11.5
13.5
14.5
15.5
15.0
18.5
21.0
23.0
26.0
30.0
T
5.0
6.0
5.0
6.0
6.0
6.5
6.5
6.5
7.5
8.0
9.0
7.5
10.0
12.5
14.0
17.0
21.0
W
15.0
15.0
15.0
15.0
21.0
21.0
21.0
21.0
26.0
26.0
33.0
33.0
37.0
37.0
47.0
630VDC
H
9.0
10.0
10.0
11.0
10.0
11.0
13.0
15.0
14.5
17.0
17.5
19.0
22.0
27.0
28.0
T
5.0
6.0
6.0
7.0
6.0
7.0
8.0
10.0
8.5
10.0
9.0
11.0
13.0
17.0
19.0
Rated
Voltage
DM
I.
CAP(
μ
F)
0.010
0.015
0.022
0.033
0.047
0.068
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10.0
12.0
TMPE
100VDC
ØD
6.0
6.0
6.0
6.5
7.0
7.0
7.0
7.0
7.0
8.0
7.5
8.5
10.0
10.0
11.5
13.0
14.5
18.0
20.0
22.0
L
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
21.0
21.0
21.0
26.0
26.0
26.0
33.0
33.0
33.0
33.0
250VDC
ØD
6.0
6.0
6.0
6.5
7.0
7.0
7.0
7.0
7.0
8.0
9.0
9.0
10.5
13.0
14.0
16.5
18.0
20.5
22.0
24.0
L
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
21.0
21.0
21.0
26.0
26.0
26.0
33.0
33.0
37.0
37.0
47.0
47.0
ØD
6.0
6.0
6.0
6.5
7.0
7.0
8.0
9.0
9.5
11.0
13.0
13.5
16.0
19.0
20.0
25.0
Custom sizes available upon request
Custom values and tolerances available upon request
Specifications are
subject to change without notice.
rev.6a
