Polypropylene
Film Capacitors
•
•
•
•
•
PPL
Series
(Inductive)
MERITEK
F
EATURES
Low dissipation factor (DF) and high insulation resistance
High stability and reliability
ESR minimized by spot-welding of electrodes and lead wires
Epoxy resin coating enhances mechanical strength and moisture
resistance
Heat resistance: 240
o
C ±10 (5 seconds)
S
PECIFICATIONS
1. Operating temperature:
2. Capacitance range:
3. Capacitance tolerance:
4. Rated voltage:
5. Dissipation factor:
6. Insulation resistance:
-40
o
C to +85
o
C
0.001μF to 0.47μF
±5%(J), ±10%(K), ±20%(M)
50VDC, 100VDC, 200VDC, 250VDC
0.1% max. at 1KHz, 25
o
C
≥20000MΩ
(C
≤
.1μF)
≥2000MΩ • μF
(C > .1μF)
PPL
332
J
2A
PPL
P
ART
N
UMBERING
S
YSTEM
Meritek Series
Capacitance
CODE
( pF )
( nF )
(
μF
)
101
100
---
---
102
1,000
1
0.001
103
10,000
10
0.01
104
100,000
100
0.1
105
1000
1
106
are constructed with polypropylene film
dielectric, tinned copper leads, and an epoxy resin
coating. They exhibit comparatively lower dielectric
absorption and significantly lower temperature
variation in electrostatic capacitance. PPL possess a
high insulation resistance and are therefore ideal
for use in circuits wherein great importance is
placed on Q factor, e.g. in RF circuits and
computers.
10
Tolerance
CODE
Tolerance (%)
J
±5
K
± 10
M
± 20
Rated Voltage
CODE
1H
50V
2A
100V
2D
200V
2E
250V
1.5
fications
are
subject to change without notice.
Tape & Reel/Tape & Ammo available
Please contact Factory for part numbers
Dimensions in millimeters (mm)
RV
DIM.
CAP(μ F)
0.0010
0.0012
0.0015
0.0018
0.0022
0.0027
0.0033
0.0039
0.0047
0.0056
0.0068
0.0082
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
50/100VDC
W
5.8
5.8
5.8
5.8
5.8
5.8
5.8
6.0
6.0
6.0
6.0
6.5
6.5
6.5
7.5
7.5
7.8
7.8
8.0
8.0
9.3
9.7
10.0
10.5
11.5
12.0
12.0
12.0
13.5
14.0
15.5
16.0
18.0
200/250VDC
H
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
12.0
12.0
12.5
12.5
12.5
12.5
12.5
13.0
13.0
15.0
16.0
16.0
16.0
19.0
20.0
21.0
T
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.5
3.5
3.5
3.5
4.0
4.0
4.0
4.0
4.0
4.5
4.5
4.6
5.0
5.0
5.0
5.5
6.0
6.5
7.0
7.0
7.5
8.0
8.5
8.5
9.0
10.0
P ± 1
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
4.0
4.0
4.0
5.0
5.0
5.0
6.0
6.0
6.0
7.0
7.0
7.0
7.0
8.0
8.0
8.0
10.0
10.0
10.0
W
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
9.0
9.0
9.0
9.0
9.0
11.0
11.0
11.0
12.0
13.0
14.0
14.0
15.0
16.0
18.0
T
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.5
4.5
4.5
5.0
5.0
5.0
5.5
5.5
6.0
6.0
7.0
7.0
8.0
8.0
8.0
8.0
9.0
10.0
H
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
13.0
13.0
13.0
13.0
13.0
14.0
14.0
14.0
14.0
15.0
15.0
15.0
17.0
18.0
18.0
P ± 1
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
4.0
4.0
4.0
5.0
5.0
5.0
6.0
6.0
6.0
7.0
7.0
7.0
7.0
8.0
8.0
Specifications are
subject to change without notice.
rev.6a
