Linear Chokes
DLH
and
DLNP
Series, vertical housing
Nominal current:
Nominal inductance:
Max. working voltage:
Application range:
Isolation voltage:
Climatic category:
Plastic case:
Potting resin:
0.6 - 7 A @
ϑ
a 70°C
20 - 5500
µ
H /tol.
±
15%
600 VDC
up to 20 kHz
2 kV eff. / wdg.-ambient
40/125/21 acc. to IEC 60068-1
UL 94 V-0
UL 94 V-0
All types of chokes correspond to the international specifications
for radio interference chokes (EN 138100).
This range of chokes enables vertical mounting, thus reducing the
area of the PC board used. Finest quality core materials allow the
highest electrical performance with minimum component volume.
Good design with easy assembly allows good cost/performance ra-
tio. This type of choke is essential in the field of power electronics,
e.g. switching power supplies, chopper amplifiers, DC drives and
stepper motor controls.
DLH
DLNP
Linear chokes are mainly used as smoothing or RFI sup-
pression circuits.
Environmental Rating:
The
DLH and DLNP chokes
can only be used with direct current or
with low frequency alternating current (max. 400 Hz) and up to max.
1.1
•
I
N
.
They operate only as attenuation devices for HF-interference
with reduced amplitute (DI << I
N
) up to the range of their self-reso-
nance (∼f
Res
).
SMD-version upon request.
Also available in open version (DLO1).
Mountings for chokes in open version see page 23.
Technical Data
Type
DLNP-6148-D6D1
DLNP-6148-01C5
DLH1-14-0.6-500/a
DLH1-14-1.0-200/a
DLH1-14-2.0-50/a
DLH1-22-0.45-5000/a
DLH1-22-0.6-3000/a
DLH1-22-1.5-500/a
DLH1-22-1.8-300/a
DLH1-22-3.0-100/a
DLH1-22-4.5-50/a
DLH1-22-7.0-20/a
DLH1-31-0.6-5500/a
DLH1-31-1.6-800/a
DLH1-31-2.5-300/a
DLH1-31-4.0-130/a
DLH1-31-6.3-50/a
I
N
(1)
[A]
L
N
(2)
[µH]
R
cu
(3)
[mΩ]
[MHz]
∼
f
Res
Case
48-1
48-1
01-1
01-1
01-1
09-1
09-1
09-1
09-1
09-1
09-1
09-1
19-1
19-1
19-1
19-1
19-1
0.6
1.0
0.6
1.0
2.0
0.45
0.6
1.5
1.8
3.0
4.5
7.0
0.6
1.6
2.5
4.0
6.3
100
50
500
200
50
5000
3000
500
300
100
50
20
5500
800
300
130
50
600
280
750
220
50
2600
1550
280
180
70
30
12
3600
470
160
53
23
9
15
1.6
6
9
0.2
0.3
1
1.5
4
6
15
0.2
1.5
3
6
9.5
(125-ϑa)/55
Typical curves
(1)
@
ϑa
70°C; current derating over 70°C: I = I
N
x
(2)
Nominal inductance measured according to EN 138100,
(3)
Resistance @
ϑa
25°C
see introduction of this catalog, paragraph 3.4
Case 48-1
Application
Case 01-1
09-1
19-1
21
