54LS379FMQB

Description
D Flip-Flop, LS Series, 1-Func, Positive Edge Triggered, 4-Bit, Complementary Output, TTL, CDFP16, CERAMIC, FP-16
Categorylogic    logic
File Size831KB,7 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Download Datasheet Parametric Compare View All

54LS379FMQB Overview

D Flip-Flop, LS Series, 1-Func, Positive Edge Triggered, 4-Bit, Complementary Output, TTL, CDFP16, CERAMIC, FP-16

54LS379FMQB Parametric

Parameter NameAttribute value
Parts packaging codeDFP
package instructionDFP,
Contacts16
Reach Compliance Codeunknown
Other featuresWITH HOLD MODE
seriesLS
JESD-30 codeR-GDFP-F16
length9.6645 mm
Logic integrated circuit typeD FLIP-FLOP
Number of digits4
Number of functions1
Number of terminals16
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Output polarityCOMPLEMENTARY
Package body materialCERAMIC, GLASS-SEALED
encapsulated codeDFP
Package shapeRECTANGULAR
Package formFLATPACK
propagation delay (tpd)27 ns
Certification statusNot Qualified
Maximum seat height2.032 mm
Maximum supply voltage (Vsup)5.5 V
Minimum supply voltage (Vsup)4.5 V
Nominal supply voltage (Vsup)5 V
surface mountYES
technologyTTL
Temperature levelMILITARY
Terminal formFLAT
Terminal pitch1.27 mm
Terminal locationDUAL
Trigger typePOSITIVE EDGE
width6.604 mm
minfmax30 MHz
Base Number Matches1
