D5S6M: Descriptionschottky rectifiers (sbd) (60v 5A); CategoryDiscrete semiconductor diode; File Size468KB，11 Pages; ManufacturerSHINDENGEN; Websitehttps://www.shindengen.com

Download Datasheet Parametric Compare View All

D5S6M Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	D5S6M	-	-	View	Buy Now

D5S6M Overview

schottky rectifiers (sbd) (60v 5A)

D5S6M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	SHINDENGEN
Parts packaging code	TO-220AC
package instruction	R-PSFM-T2
Contacts	3
Reach Compliance Code	unknown
ECCN code	EAR99
application	GENERAL PURPOSE
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.58 V
JEDEC-95 code	TO-220AC
JESD-30 code	R-PSFM-T2
JESD-609 code	e0
Humidity sensitivity level	2
Maximum non-repetitive peak forward current	100 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	150 °C
Maximum output current	5 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	60 V
surface mount	NO
technology	SCHOTTKY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal location	SINGLE

Preview

Download Datasheet

View All

SHINDENGEN

Schottky Rectifiers (SBD)

Single

D5S6M

60V 5A

FEATURES

●

Tj150℃

●

RRSM

avalanche

OUTLINE DIMENSIONS

Case : ITO-220

Unit : mm

guaranteed

●

Fully Isolated Molding

APPLICATION

●

Switching power supply

●

DC/DC converter

●

Home Appliances, Office Equipment

●

Telecommunication

RATINGS

●Absolute Maximum Ratings (If not specified T½

=25℃)

Item

Symbol

Conditions

Storage Temperature

Tstg

Operating Junction Temperature

Maximum Reverse Voltage

Repetitive Peak Surge Reverse Voltage

RRSM

Pulse width 0.5ms, duty1/40

Average Rectified Forward Current

50Hz sine wave, R-load, Tc=130℃

Peak Surge Forward Current

FSM

50Hz sine wave, Non-repetitive 1 cycle peak value, Tj=125℃

Repetitive Peak Surge Reverse Power

RRSM

Pulse width 10μs, Tj= 25℃

Dielectric Strength

Vdis

Terminals to case, AC 1 minute

Mounting Torque

TOR

(Recommended torque：

0.3N½m)

●Electrical Characteristics (If not specified T½

=25℃)

Item

Symbol

Conditions

Forward Voltage

=5A,

Pulse measurement

Reverse Current

RM,

Pulse measurement

Junction Capacitance

f=1MHz, V

=10V

Thermal Resistance

θjc

junction to case

θcf

case to heatsink

Ratings

-55∼150

150

100

330

1.5

0.5

Unit

℃

N½m

Ratings

Unit

Max.0.58

Max. 4.5

Typ.260

Max.4.5 ℃/W

Max.1.5
