Pacific Silicon Sensor Series 6 Data Sheet
Quad Sum and Difference Amplifier
Part Description QP50-6SD2
Order # 10-025
1.50
1.25
0.235
NO CONNECTION
Q2
Q1
0.75
PD BIAS
V(B-T)
V(L-R)
V(SUM)
V+
GND
V-
ACTIVE AREA: 4 X 11.78 mm
2
(7.80 mm DIA w/ 42 µm GAPS)
0.125
PD C
L
0.100
0.062
0.13
CHIP SURFACE
0.50
2X Ø0.100
TOOLING HOLE
PD C
L
PINS ON 0.100
CENTERS
7
0.57
0.23
1.00
Q2 Q1
Q3 Q4
Q4
1
Q3
0.125
COMMON
CATHODE
TOP VIEW
ALL DIMENSIONS IN INCHES
0.70
0.25
R
o
H
DESCRIPTION
The
QP50-6SD2
is a quad photodiode array with current-to-voltage amplifiers that provide
bottom minus top and left minus right difference signals. Additionally the
QP50-6SD2
provides a signal that is the sum of all four quadrant diode signals. The difference signals
are voltage analogs of the light intensity difference sensed by the pairs of photodiode
elements in the array. The board has a 7 pin connector attached for easy hook up.
APPLICATIONS
•
NIR & visible pulsed light
positioning and tracking
•
Laser beam centering
S
C
PLI
A
NT
OM
OPTIONS
•
Can be purchased without connector, use order # 10-031.
•
For alternate gap size, see data sheet QP50-6-18u-SD2 for 18 µm gap version.
2
2
•
Also available with quad detector active area sizes ranging from 1mm to 20 mm .
ABSOLUTE MAXIMUM RATING
SYMBOL PARAMETER
MIN
T
STG
T
OP
V
S
V
R
Storage Temp
Operating Temp
Power Supply Voltage
Recommended ±15V
Applied Bias Voltage*
-15
0
±4.5
0
SPECTRAL RESPONSE @ 22°C
MAX
+100
+70
±18
15
UNITS
°C
°C
V
RESPONSIVITY (A/W)
0.70
0.60
0.50
0.40
0.30
0.20
0.10
V
CONNECTIONS
PD BIAS
V(B-T)
V(L-R)
V(SUM)
V+
GND
V-
1
7
0.00
400
500
600
700
800
900
1000
1100
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS @ 22° C
SYMBOL
CHARACTERISTIC
TEST CONDITIONS
V
O
I
O
Output Voltage (all outputs)
Output Current Limit
Slew Rate
Theoretical noise
∆ƒ
-3dB
Bandwidth**
V
s
= ± 15 V; V
R
= 0 V
V
s
= ± 15 V; V
R
= 0 V
V
s
= ± 15 V; V
R
= 0 V
V
s
= ± 15 V; V
R
= 5 V;
λ
= 880 nm
MIN
---
---
---
---
---
---
TYP
+V
s
-3
-V
s
+3
---
---
15
250
MAX
---
---
25
10
---
---
UNITS
V
mA
V/µs
nV/√Hz
kHz
* actual bias voltage to photodiode: pad 1 voltage times 0.91. Do not apply negative voltages to pad 1.
** dependant on bias voltage
Disclaimer: Due to our policy of continued development, specifications are subject to change without notice.
9/24/2010
PAGE 1 OF 2
The
QP50-6SD2
outputs are labeled as B-T for bottom minus top, L-
R for left minus right. The output voltages are obtained by routing the
diode element currents into current-to-voltage amplifiers with a gain
4
of 10 :
V
B-T
= [(I
3,4
) - (I
1,2
)]
•
(10 ) on Pad 2.
V
L-R
= [(I
2,3
) - (I
1,4
)]
•
(10 ) on Pad 3.
V
SUM
= [(I
1,2,3,4
)
•
(10 ) on Pad 4.
I
X,Y
is the sum of the currents generated by photodiode elements
x and y. Looking down through the window of the photodiode, the
quadrants are identified in drawing on page one.
4
4
4
X0.91
i2
i3
i1
i4
V2 = i2 X 10
4
PHOTODIODE BIAS
PAD 1
X1
SUM AND
DIFFERENCE
AMPLIFIERS
(V3 +V4) - (V1 + V2)
PAD 2
(V2 +V3) - (V1 + V4)
PAD 3
V1 + V2 + V3 + V4
PAD 4
V3 = i3 X 10
4
V1 = i1 X 10
V4 = i4 X 10
4
4
QP50-6-TO8
+15V
-
+
-15V
+15V PAD 5
GROUND PAD 6
-15V PAD 7
BLOCK DIAGRAM
APPLICATION NOTES
Beam Size
The light spot applied to the QP50-6SD2 must be smaller than the diameter of the quadrant photodiode array. The detector active area has a
diameter of 7.8 millimeters. If the light spot is too large, it may be reduced to fit the photodiode array by use of a lens. A decrease in output
signal strength is observed as the light spot crosses the separation boundary of the quadrants, usually referred to as the “gap”. This effect is
more pronounced as the diameter of the light spot decreases, as a larger percentage of the light spot’s power falls within the non-active gap.
For this reason, the minimum light beam diameter should be a least one millimeter. A lens may be used to increase the beam diameter.
Photodiode Bias Operation
The QP50-6SD2 array may be operated either in the zero bias or the reverse bias mode. Pin 1 is connected, via a resistor divider, to the non-
inverting input of a voltage follower operational amplifier. This line may be left unterminated, grounded or connected to a voltage source of
zero volts to operate in the zero bias mode. If the photodiode bias line is connected to a positive voltage source (but less than Vcc), then the
photodiode elements in the array will be biased at 0.91 x VBias. Do not connect Pin 1 to negative voltages, as this will forward bias the
photodiode array, making it inoperable and possibly damaging the circuit.
Use of Sum and Difference Signals for Alignment
The sum output signal may be used to help preliminary alignment of the QP50-6SD2 to the source light beam. First, the beam or the QP50-
6SD2 is adjusted for maximum sum output signal. Second, the beam or QP50-6SD2 is adjusted until the L-R and B-T signals are at minimum.
This procedure results in the beam being centered on the quad photodiode array.
Signal Null Detector for Servo Applications
A common application for the QP50-6SD2 is a signal null detector as part of a servo system that maintains the position of a light beam. Errors
in beam position are reported by the QP50-6SD2 and may be used to adjust a positioning device that restores the beam or the beam’s source
to a null position.
Speed of Response
Increasing the photodiode bias voltage will increase the speed of the QP50-6SD2. Operating with zero reverse bias is sufficient for many
applications (-3dB is around 150 kHz at 880 nm). As noted above, Pin 1 is provided for applying positive bias voltage to the quad for higher
frequency response. Care should be taken not to exceed the circuit common mode values and the breakdown voltage of the quad photodiode.
See Absolute Maximum Ratings on page one for maximum values.
Temperature Considerations
The operation temperature must be between 0 to 70
°C.
For best resolution the temperature should be kept at or below 25
°C.
Thermal
gradients across the detector will cause position errors and should be avoided.
Offsets
Precision components are used in the circuitry but as much as 10 millivolts of dark offset may still be present in the outputs. If this causes a
problem the offsets should be removed externally.
