New Product
DF005SA thru DF10SA
Vishay General Semiconductor
Miniature Glass Passivated Single-Phase
Surface Mount Bridge Rectifiers
FEATURES
• UL recognition, file number E54214
• Ideal for automated placement
~
~
~
• Middle surge current capability
• Meets MSL level 1, per J-STD-020,
LF maximum peak of 250 °C
• Solder dip 260 °C, 40 s
• Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
Case Style DFS
~
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
I
R
V
F
T
J
max.
1A
50 V to 1000 V
30 A
5 µA
1.1 V
150 °C
TYPICAL APPLICATIONS
General purpose use in ac-to-dc bridge full wave
rectification for SMPS, lighting ballaster, adapter,
battery charger, home appliances, office equipment,
and telecommunication applications.
MECHANICAL DATA
Case:
DFS
Epoxy meets UL 94V-0 flammability rating
Terminals:
Matte tin plated leads, solderable per
J-STD-002 and JESD22-B102
E3 suffix for consumer grade, meets JESD 201 class
1A whisker test
Polarity:
As marked on body
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Device marking code
Maximum repetitive peak
reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward output
rectified current at T
A
= 40 °C
(1)
Peak forward surge current
single half sine-wave
superimposed on rated load
Rating for fusing (t < 8.3 ms)
Operating junction and storage
temperature range
V
RRM
V
RMS
V
DC
I
F(AV)
SYMBOL
DF005SA
DFA005S
50
35
50
DF01SA
DFA01S
100
70
100
DF02SA
DFA02S
200
140
200
DF04SA
DFA04S
400
280
400
1.0
DF06SA
DFA06S
600
420
600
DF08SA
DFA08S
800
560
800
DF10SA
DFA10S
1000
700
1000
V
V
V
A
UNIT
I
FSM
I
2
t
T
J
, T
STG
30
4.5
- 55 to + 150
A
A
2
s
°C
Note:
(1) Units mounted on P.C.B. with 0.51 x 0.51" (13 x 13 mm) copper pads
Document Number: 88574
Revision: 30-Jan-08
For technical questions within your region, please contact one of the following:
PDD-Americas@vishay.com, PDD-Asia@vishay.com, PDD-Europe@vishay.com
www.vishay.com
1
New Product
DF005SA thru DF10SA
Vishay General Semiconductor
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum
instantaneous forward
voltage drop per diode
Maximum DC reverse
current at rated DC
blocking voltage per diode
Typical junction
capacitance per diode
(1)
Note:
(1) Measured at 1.0 MHz and applied reverse voltage of 4.0 V
TEST
SYMBOL DF005SA DF01SA DF02SA DF04SA DF06SA DF08SA DF10SA
CONDITIONS
1.0 A
V
F
1.1
UNIT
V
T
A
= 25 °C
T
A
= 125 °C
I
R
5.0
500
25
µA
C
J
pF
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance
(1)
Note:
(1) Units mounted on P.C.B. with 0.51 x 0.51" (13 x 13 mm) copper pads
SYMBOL DF005SA DF01SA DF02SA DF04SA DF06SA DF08SA DF10SA
R
θJA
R
θJL
40
15
UNIT
°C/W
ORDERING INFORMATION
(Example)
PREFERRED P/N
DF06SA-E3/45
DF06SA-E3/77
UNIT WEIGHT (g)
0.386
0.386
PREFERRED PACKAGE CODE
45
77
BASE QUANTITY
50
1500
DELIVERY MODE
Tube
13" diameter paper tape and reel
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
1.0
30
Average Forward Output Current (A)
Peak Forward Surge Current (A)
60 Hz
Resistive or
Inductive Load
T
J
= 150 °C
Single Sine-Wave
25
20
0.5
15
10
P.C.B. Mounted on
0.51 x 0.51" (13 x 13 mm)
Copper Pads
0
20
40
60
80
100
120
140
160
5
1.0 Cycle
0
1
10
100
Ambient Temperature (°C)
Number
of Cycles at 60 Hz
Figure 1. Derating Curve Output Rectified Current
Figure 2. Maximum Non-Repetitive Peak Forward Surge
Current Per Diode
Document Number: 88574
Revision: 30-Jan-08
www.vishay.com
2
For technical questions within your region, please contact one of the following:
PDD-Americas@vishay.com, PDD-Asia@vishay.com, PDD-Europe@vishay.com
New Product
DF005SA thru DF10SA
Vishay General Semiconductor
10
100
T
J
= 25 °C
f = 1.0 MHz
V
sig
= 50 mVp-p
Instantaneous Forward Current (A)
1
Junction Capacitance (pF)
10
0.1
T
J
= 25 °C
Pulse
Width
= 300
µs
1 % Duty Cycle
0.01
0.4
1
0.6
0.8
1.0
1.2
1.4
1
10
100
Instantaneous Forward
Voltage
(V)
Reverse
Voltage
(V)
Figure 3. Typical Forward Characteristics Per Diode
Figure 5. Typical Junction Capacitance Per Diode
100
100
10
T
J
= 125 °C
Transient Thermal Impedance (°C/W)
80
Instantaneous Reverse Current (µA)
10
1
1
0.1
T
J
= 50 °C
0.01
0
20
40
60
100
0.1
0.01
0.1
1
10
100
Percent of Rated Peak Reverse
Voltage
(%)
t - Heating Time (s)
Figure 4. Typical Reverse Leakage Characteristics Per Diode
Figure 6. Typical Transient Thermal Impedance
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
Case Style DFS
0.205 (5.2)
0.195 (5.0)
Mounting Pad La yout
0.047 (1.20)
0.040 (1.02)
0.047 MIN.
(1.20 MIN.)
0.060 MIN.
(1.52 MIN.)
0.404 (10.3)
0.386 (9.80)
0.335 (8.51)
0.320 (8.13)
45°
0.404 MAX.
(10.26 MAX.)
0.255 (6.5)
0.245 (6.2)
0.130 (3.3)
0.120 (3.05)
0.205 (5.2)
0.195 (5.0)
0.013 (0.330)
0.009 (0.241)
0.060 (1.524)
0.040 (1.016)
0.013 (0.330)
0.003 (0.076)
Document Number: 88574
Revision: 30-Jan-08
For technical questions within your region, please contact one of the following:
PDD-Americas@vishay.com, PDD-Asia@vishay.com, PDD-Europe@vishay.com
www.vishay.com
3
