DF005S THRU DF10S
MINIATURE GLASS PASSIVATED SINGLE-PHASE SURFACE MOUNT
BRIDGE RECTIFIER
Reverse Voltage -
50 to 1000 Volts
Case Style DFS
Forward Current -
1.0 Ampere
FEATURES
0.047 (1.20)
0.040 (1.02)
0.205 (5.2)
0.195 (5.0)
0.404 (10.3)
0.386 (9.80)
0.335 (8.51)
0.320 (8.13)
45
o
0.255 (6.5)
0.245 (6.2)
♦
Plastic package has Underwriters Laboratory Flammability
Classification 94V-0
♦
This series is UL recognized under Component Index, file
number E54214
♦
Glass passivated chip junctions
♦
High surge overload rating-50 amperes peak
♦
Ideal for printed circuit boards
♦
High temperature soldering guaranteed:
260°C/10 seconds at 5 lbs. (2.3kg) tension
0.013 (0.330)
0.130 (3.3)
0.009 (0.241)
0.120 (3.05)
MECHANICAL DATA
0.060 (1.524)
0.040 (1.016)
0.013 (0.330)
0.003 (0.076)
Dimensions in inches and (millimeters)
Case:
Molded plastic body over passivated junctions
Terminals:
Plated leads solderable per MIL-STD-750,
Method 2026
Polarity:
Polarity symbols marked on body
Mounting Position:
Any
Weight:
0.04 ounce, 1.0 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
SYMBOLS
DF
005S
DF
01S
DF
02S
DF
04S
DF
06S
DF
08S
DF
10S
UNITS
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward output rectified current
at T
A
=40°C
(NOTE 2)
Peak forward surge current single half sine-wave
superimposed on rated load (JEDEC Method) T
J
=150°C
Rating for fusing (t < 8.3ms)
Maximum instantaneous forward voltage drop
per leg at 1.0A
Maximum DC reverse current
at rated DC blocking voltage per leg
Typical thermal resistance per leg
T
A
=25°C
T
A
=125°C
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
I
R
C
J
R
ΘJA
R
ΘJL
50
35
50
100
70
100
200
140
200
400
280
400
1.0
50.0
10.0
1.1
5.0
500
25.0
40.0
15.0
-55 to +150
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amp
Amps
A
2
sec
Volts
µA
pF
°C/W
°C
Typical junction capacitance per leg
(NOTE 1)
(NOTE 2)
Operating junction and storage temperature range T
J
, T
STG
NOTES:
(1) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts
(2) Units mounted on P.C.B. with 0.51 x 0.51” (13 x 13mm) copper pads
4/98
RATINGS AND CHARACTERISTICS CURVES DF005S THRU DF10S
FIG.1 - DERATING CURVE OUTPUT RECTIFIED
CURRENT
AVERAGE FORWARD OUTPUT CURRENT,
AMPERES
FIG. 2 - MAXIMUM NON-REPETITIVE PEAK FORWARD
SURGE CURRENT PER LEG
1.0
PEAK FORWARD SURGE CURRENT,
AMPERES
60 H
Z
RESISTIVE OR INDUCTIVE LOAD
60
50
40
30
1.0 CYCLE
T
J
=150°C
SINGLE SINE-WAVE
(JEDEC Method)
0.5
20
10
0
P.C.B. MOUNTED ON
0.51 x 0.51” (13 x 13mm) COPPER PADS
0
20
40
60
80
100
120
140
160
1
10
NUMBER OF CYCLES AT 60 Hz
FIG. 4 - TYPICAL REVERSE LEAKAGE
CHARACTERISTICS PER LEG
100
AMBIENT TEMPERATURE, °C
FIG. 3 - TYPICAL FORWARD CHARACTERISTICS
PER LEG
10
100
INSTANTANEOUS FORWARD CURRENT,
AMPERES
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
T
J
=25°C
PULSE WIDTH=300µs
1% DUTY CYCLE
10
T
J
=125°C
1
1
0.1
0.1
T
J
=25°C
0.01
0.4
0.6
0.8
1.0
1.2
1.4
0.01
INSTANTANEOUS FORWARD VOLTAGE,
VOLTS
0
20
40
60
80
100
PERCENT OF RATED PEAK REVERSE
VOLTAGE, %
FIG. 6 - TYPICAL TRANSIENT THERMAL
IMPEDANCE
TRANSIENT THERMAL IMPEDANCE,
°C/W
FIG. 5 -TYPICAL JUNCTION CAPACITANCE
100
JUNCTION CAPACITANCE, pF
T
J
=25°C
f=1.0 MH
Z
Vsig=50mVp-p
100
10
10
1
1
1
10
REVERSE VOLTAGE, VOLTS
100
0.1
0.01
0.1
1
t, HEATING TIME, sec.
10
100
